*Some models.7–36
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep (With the advanced keyless
function)
If a key is left in the vehicle cabin and all
the doors and the trunk are locked using
a separate key, a beep sound is heard for
about 10 seconds to remind the driver
that the key has been left in the vehicle
cabin. If this happens, open the door and
remove the key. A key removed from the
vehicle this way may not function because
its functions may have been temporarily
suspended. Perform the applicable
procedure to restore the functions of the
key (page 3-8 ).
Tire Infl ation Pressure Warning
Beep*
The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tire infl ation pressures
(page 4-61 ).
Blind Spot Monitoring (BSM) System Warning Beep *
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the BSM warning light is illuminated.
NOTE
A personalized function is available to
change the BSM warning beep sound
volume.
Refer to Personalization Features on page
9-10 .
Reversing
If vehicles approach from the rear on the
left and right, the Blind Spot Monitoring
(BSM) warning beep operates.
Power Steering Warning Buzzer
If the power steering system has
a malfunction, the power steering
malfunction light turns on or fl ashes and
the buzzer operates at the same time.
Refer to Warning/Indicator Lights on page
4-16 .
Over Rev. Buzzer *
The buzzer sounds to notify the driver if
the engine speed is about to exceed the
permissible engine speed.
CAUTION
Operate the accelerator and shift gears
according to the driving conditions so
that the buzzer does not sound. If the
engine speed exceeds the permissible
engine speed, the engine could be
damaged.
.B[EB@%$&""@&EJUJPOJOEC







8–42
Customer Information and Reporting Safety Defects
Declaration of Conformity
Declaration of Conformity
Keyless Entry System/Immobilizer System
.B[EB@%$&""@&EJUJPOJOEC







9–10
Specifi cations
Personalization Features
Personalization Features
The following personalization feature is available. This setting can only be changed by an
Authorized Mazda Dealer.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Daytime running
lights The function of the daytime running lights can
be changed.
On
On/Off
The following personalization features can be changed by the vehicle own\
er.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Power door lock Changes the auto lock/unlock function setting
for all the doors according to the vehicle speed,
the vehicle power supply condition, and the
selector lever position.
Refer to Auto Lock/Unlock Function on page
3-16 .
Refer to Settings on page 5-53 . Lock: When
Driving Unlock: IGN Off Lock: Shifting from
Park Unlock: In Park/ Lock: Shifting from Park/
Lock: When Driving Unlock: IGN Off/
Lock: When Driving/ Off
Keyless entry
system The method for unlocking the doors using the
transmitter can be changed.
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-53 .
Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice: All Doors
The time required for the doors to relock
automatically after unlocking with the
transmitter can be changed.
Refer to Settings on page 5-53 . 60 seconds
90 seconds/
60 seconds/
30 seconds
.B[EB@%$&""@&EJUJPOJOEC







9–11
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Advanced keyless
entry system The volume of the answer-back beep during
advanced keyless entry system operation can
be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-12 .
Refer to Settings on page 5-53 .
Medium
High/
Medium/ Low/ Off
The function to automatically lock the doors
when leaving the vehicle while carrying the
key can be changed.
Refer to Settings on page 5-53 . Off
On/Off
The method for unlocking the doors using the
request switch/transmitter can be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-12 .
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-53 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice: All Doors
The time required for the doors to relock
automatically after unlocking with the request
switch/transmitter can be changed.
Refer to Settings on page 5-53 . 60 seconds
90 seconds/
60 seconds/
30 seconds
Illumination entry The time required for the interior lamp to turn
off automatically can be changed (prevents
battery depletion when a door is open/ajar).
Refer to Settings on page 5-53 .
30 minutes
60 minutes/
30 minutes/
10 minutes
The time required for the interior lamp to turn
off automatically after all doors are closed can
be changed.
Refer to Settings on page 5-53 . 15 seconds 60 seconds/
30 seconds/
15 seconds/
7.5 seconds
Three-fl ash turn
signal The three-time fl
ash function can be changed.
Refer to Settings on page 5-53 . On
On/Off
Auto-wiper control The auto-wiper control function can be
changed.
Refer to Settings on page 5-53 . On
On/Off
Auto headlight off
*1 The time required for headlights to turn off
after ignition is switched off can be changed.
Refer to Settings on page 5-53 . 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off
*2
Auto-light control The headlight illumination on/off timing based
on surrounding lightness/darkness can be
changed.
Refer to Settings on page 5-53 . Medium Light/
Medium Light/ Medium/
Medium Dark/ Dark
Turn indicator The turn indicator beep volume level can be
changed.
Refer to Settings on page 5-53 . High
High/Low
Lights-on reminder
*3 The volume of the lights-on reminder warning
alarm can be changed.
Refer to Settings on page 5-53 . Off
High/Low/Off
.B[EB@%$&""@&EJUJPOJOEC







10–2
Index
A
Accessory Socket .............................. 5-132
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key Advanced keyless entry system ...... 3-9
Operational range .......................... 3-10
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-34
Air Bag Systems ................................. 2-40
Ambient Temperature Display ............ 4-13
Antilock Brake System (ABS) ............ 4-50
Audio Control Switch Adjusting the Volume .................... 5-56
Mute Switch .................................. 5-56
Seek Switch ................................... 5-56
Audio System ...................................... 5-16 AUX/USB/iPod mode ................... 5-57
Antenna ......................................... 5-16
Audio Control Switch ................... 5-55
Audio Set (Type A) ....................... 5-25
Audio Set (Type B) ....................... 5-36
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-45
Automatic Transaxle ........................... 4-24 Active Adaptive Shift (AAS) ........ 4-26
Driving tips.................................... 4-32
Manual shift mode......................... 4-27
Shift-lock system ........................... 4-26
Shift position indication ................ 4-25
Warning light ................................. 4-25
B
Battery ................................................. 6-36 Maintenance .................................. 6-38
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15 Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM) System ... 4-65
BSM OFF switch........................... 4-71
BSM warning light ........................ 4-70
Blind Spot Monitoring (BSM) ...... 4-66
Care of radar sensors ..................... 4-71
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-36
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-68
Bluetooth® ........................................... 5-73
Bluetooth® Audio (Type A) ......... 5-111
Bluetooth® Audio (Type B) ......... 5-113
Bluetooth® Hands-Free (Type A) ... 5-93
Bluetooth® Hands-Free (Type B) ... 5-99
Troubleshooting .......................... 5-126
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-135
Brakes Brakes assist .................................. 4-48
Foot brake...................................... 4-46
Pad wear indicator ......................... 4-47
Parking brake ................................ 4-47
Warning light ................................. 4-47
Break-In .............................................. 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-136
Child Restraint Child-restraint precautions ............ 2-22
Installing child-restraint systems... 2-28
LATCH child-restraint systems ..... 2-36
Child Safety Locks for Rear Doors ..... 3-20
.B[EB@%$&""@&EJUJPOJOEC







10–4
Index
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-12
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-55
Fuel Economy Monitor ....................... 4-54 Ending screen display ................... 4-55
Fuel consumption display ............. 4-55
G
Gauges ................................................... 4-9
Glove Compartment .......................... 5-136
H
Hazard Warning Flasher ...................... 4-45
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-10
Headlights Control........................................... 4-33
Flashing ......................................... 4-36
High-low beam .............................. 4-36
Hill Launch Assist (HLA) ................... 4-48
Hood Release ...................................... 6-24
Horn .................................................... 4-44
I
If a Warning Light Turns On or
Flashes................................................. 7-24
Ignition Switch .............................................. 4-2
Ignition not switched off (STOP) warning
beep ..................................................... 7-35
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-19
BSM OFF ...................................... 4-71
Low engine coolant temperature ... 4-20
Wrench .......................................... 4-20
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level ... 6-31 Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
Interior Care ........................................ 6-69
Cleaning the Lap/Shoulder Belt
Webbing ........................................ 6-71
Cleaning the Upholstery and Interior
Trim ............................................... 6-69
Cleaning the Window Interiors ..... 6-71
Dashboard Precautions .................. 6-69
Interior Lights ................................... 5-130 Luggage Compartment Light ...... 5-130
Map Lights .................................. 5-130
Overhead Lights .......................... 5-130
J
Jack ....................................................... 7-4
Jump-Starting ...................................... 7-15
K
Key removed from vehicle warning
beep ..................................................... 7-35
Key Suspend Function .......................... 3-8
Key left-in-luggage compartment warning
beep (With the advanced keyless
function) .............................................. 7-35
Key left-in-vehicle warning beep (With
the advanced keyless function) ........... 7-36
Keyless Entry System ........................... 3-3
Keys ...................................................... 3-2 Key suspend function ...................... 3-8
Transmitter ...................................... 3-4
L
Label Information ................................. 9-2
Lane-Change Signals .......................... 4-38
Liftgate ................................................ 3-20
Light Bulbs Replacement .................................. 6-45
Specifi cations .................................. 9-8
.B[EB@%$&""@&EJUJPOJOEC







10–7
Index
Trunk Lid ............................................ 3-20 Inside trunk release lever .............. 3-25
V
Vanity Mirrors ................................... 5-129
Vehicle Information Labels ................... 9-2
W
Warning Lights .................................... 4-17
Warning Message Indicated on
Display ................................................ 7-33
Warning Sound is Activated ................ 7-34 Air Bag/Front Seat Belt Pretensioner
System Warning Beep ................... 7-34
Blind Spot Monitoring (BSM) System
warning beep ................................. 7-36
Ignition not switched off (STOP)
warning beep ................................. 7-35
Key left-in-luggage compartment
warning beep (With the advanced
keyless function) ........................... 7-35
Key left-in-vehicle warning beep (With
the advanced keyless function) ..... 7-36
Lights-on reminder ........................ 7-34
Over Rev. buzzer ........................... 7-36
Power steering warning buzzer ..... 7-36
Seat belt warning beep .................. 7-35
Tire infl ation pressure warning
beep ............................................... 7-36
Key removed from vehicle warning
beep ............................................... 7-35
Warranty .............................................. 8-15
Weights.................................................. 9-7
Windows Power windows ............................. 3-36
Windshield Washer ............................. 4-42
Windshield Wipers .............................. 4-39
Winter Driving .................................... 3-47 Wiper
Replacing Rear Window Wiper Blade
(5-Door)......................................... 6-34
Replacing Windshield Wiper
Blades ............................................ 6-33
.B[EB@%$&""@&EJUJPOJOEC
