2014 MAZDA MODEL 3 4-DOOR stop start

5–68
Interior Features
Audio System
How to use iPod mode (Type A)
Media/Scan buttonList down button List up button Play/Pause button
Random button
Repeat button Audio display
Text button
Track down/Reverse button
Track up/Fast-forward button Category down button
Category up button
An iPod may not be compatible depending
on the model or OS version. In this case,
an error message is displayed.
NOTE
The iPod functions on the iPod cannot
be operated while it is connected to the
unit because the unit controls the iPod
functions.
Playback
1. Switch the ignition to ACC or ON.
2. Press the power/volume dial to turn the
audio system on.
3. Press the media button (
) to
switch to the iPod mode and start
playback.
NOTE
 y  When an iPod is not connected, the
mode does not switch to the iPod mode.
 y When there is no playable data in the
iPod, “ NO CONTENTS ” is fl ashed.
 y Do not remove the iPod while in the
iPod mode. Otherwise, the data could
be damaged.
Pause
To stop playback, press the play/pause
button ( 4 ).
Press the button again to resume playback.
Fast-forward/Reverse
Press and hold the fast-forward button (
)
to advance through a track at high speed.
Press and hold the reverse button (
) to
reverse through a track at high speed.
Track search
Press the track up button (
) once to skip
forward to the beginning of the next track.
Press the track down button (
) within a
few seconds (depends on iPod software
version) after playback begins to track
down to the beginning of the previous
track.
Press the track down button (
) after a
few seconds (depends on iPod software
version) have elapsed to start playback
from the beginning of the current track.
Category search
Press the category down button ( 5 ) to
select the previous category and press the
category up button ( 6 ) to select the next
category.
NOTE
The types of categories include Playlist,
Artist, Album, Song, Podcast, Genre,
Composer, and Audio book.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–72
Interior Features
Audio System
How to use USB mode (Type B)
Type Playable data
USB mode MP3/WMA/AAC/OGG fi le
This unit does not support a USB 3.0 device. In addition, other devices \
may not be
supported depending on the model or OS version.
Playback
1. Select the
icon on the home screen and display the Audio screen.
2. Select the
icon or icon to switch the USB mode. The following icons are
displayed in the lower part of the audio display.
Icon Function
Displays the Audio menu. Use to switch to a different audio source.
Current track list is displayed.
Select a desired track to play it.
Category list is displayed.
Tracks in the current track list are played repeatedly.
Select it again to play the current track repeatedly.
Select it again to cancel.
Tracks in the current track list are played randomly.
Select it again to cancel.
Tracks similar to the current track are searched in the device and a play\
list can be created
using Gracenote's More Like This™. A playlist is created based on track information such
as artist, genre, and age.
If selected within a few seconds from the beginning of a song which has \
started to play, the
previous song is selected.
If more than a few seconds have elapsed, the song currently being played\
is replayed from
the beginning.
Long-press to fast reverse. It stops when you remove your hand from the \
icon or the
commander knob.
Track is played. When selected again, playback is temporarily stopped.
Advances to the beginning of the next song.
Long-press to fast forward.
Adjusts the audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.5–75
Interior Features
Bluetooth®
Bluetooth ® (Type A/Type B) *
Bluetooth ® Hands-Free outline
When a Bluetooth
® device (mobile phone) is connected to the vehicle's hands-free unit
via radio wave transmission, a call can be made or received using the ta\
lk button, pick-up
button and hang-up button, or by operating the panel. For example, even \
if a device (mobile
phone) is in your coat pocket, a call can be made without taking the de\
vice (mobile phone)
out and operating it directly.
Bluetooth
® audio outline
When a portable audio unit equipped with the Bluetooth
® communication function is
programmed to the vehicle, you can listen to music stored on the program\
med portable
audio device from the vehicle's speakers. It is not necessary to connect\
the portable audio
device to the vehicle's external input terminal. After programming, operate the vehicle audio
control panel to play/stop the audio.
NOTE
 y  For your safety, a device can be paired (programmed) only when the vehicle is parked. If
the vehicle starts to move, the pairing procedure will end. Park the vehicle in a safe place
before pairing.
 y The communication range of a Bluetooth ® equipped device is about 10 meters (32 ft) or
less.
CAUTION
Some Bluetooth ® mobile devices are not compatible with the vehicle. Consult an
Authorized Mazda Dealer, Mazda's call center or Web support center for information
regarding Bluetooth
® mobile device compatibility:



5–115
Interior Features
Bluetooth®
NOTE
Some Bluetooth ® audio devices need a
certain amount of time before the “
”
symbol is displayed.
3. Press the media button (
) to
switch to the Bluetooth ® audio mode
and start playback.
If the current device version is lower
than AVRCP Ver. 1.3: “ BT Audio ” is
displayed.
If the current device is AVRCP Ver. 1.3:
The playback time is displayed.
NOTE
 y  If the Bluetooth ® audio device does not
begin playback, press the Play/Pause
button (4).
 y  If a call is received on a hands-free
mobile phone during playback from
the Bluetooth
® audio device, the
playback is stopped. Playback from the
Bluetooth
® audio device resumes after
the call ends.
Playback
1. To listen to a Bluetooth
® audio device
over the vehicle's speaker system,
switch the mode to Bluetooth
®
audio mode. (Refer to “Switching to
Bluetooth® audio mode”)
2. To stop playback, press the Play/Pause button (4).
3. Press the button again to resume playback.
Selecting a fi le (track)
Selects the next fi le (track)
Short-press the track up button (
).
Selects the beginning of the current fi le
(track)
Short-press the track down button (
).
Fast-forward/Reverse (AVRCP Ver. 1.3)
Fast-forward
Press and hold the fast-forward button
(
).
Reverse
Press and hold the reverse down button
(
).
Switching the display (only AVRCP Ver.
1.3)
For fi les with a song title and other
information that have been input, the
display switches between display of the
song title and other information each
time the text button (3) is pressed during
playback.
Album title
Song title
Artist name
Playback time
NOTE
 y
 If title information is not available,
“ NO TITLE ” is displayed.
 y This unit cannot display some
characters. Characters which cannot be
displayed are indicated by an asterisk
(
).
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–126
Interior Features
Bluetooth®
Example of use (Location Based
Services)
1. Select the desired station from the location base service tab on the main
menu.
The destination name or address playback starts in the order of the
destination name list.
2. Select the icon and display the
content list. Other cafes can be
selected.
Selection of other destinations from the list can be made.
3. When the icon is selected, the
location of the currently displayed
destination is displayed on the
navigation (only with navigation
system).
4. When the
icon is selected, a phone
call is placed to the currently displayed
destination.
Shout
Some social stations, such as Facebook or
Caraoke, support the ability to record and
share voice messages using the “Shout”
function.
1. Select the
icon and start the
countdown (3, 2, 1, 0). Recording starts
when the countdown reaches zero.
2. Records voice.
3. Select the
icon and store/post the
recording.
NOTE
 y  A maximum of 30 seconds can be
recorded.
 y Recording is stopped automatically
after 30 seconds have elapsed from
when the recording started. You can
then store or delete the recording.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–130
Interior Features
Bluetooth®
Symptom Cause Solution method
Pairing cannot
be performed
again The pairing
information
programmed
to the
Bluetooth
®
unit or
device is not
recognized
correctly. Perform
pairing using
the following
procedure.y Clear “Mazda”
stored in the
device.
y Perform pairing again.
Unable to
perform pairing The
Bluetooth
®
function
and the Find
Mode/Visible
setting
*1 on
the device
may turn off
automatically
after a period
of time has
elapsed
depending on
the device. Check whether
the Bluetooth
®
function and
the Find Mode/
Visible setting
*1
on the device
are turned on
and pairing or
reconnect.
Does not
connect
automatically
when starting
the engine
Automatically
connects,
but then
disconnects
suddenly
Disconnects
intermittently
The device is
in a location
in which
radio wave
interference
can occur
easily, such
as inside a
bag in a rear
seat, in a rear
pocket of a
pair of pants. Move the device
to a location in
which radio wave
interference is
less likely to
occur.
Does not
connect
automatically
when starting
the engine The
programmed
pairing
information is
updated when
the device OS
is updated.
Perform pairing
again.
*1 Setting which detects the existence of a device external to the Bluetooth
® unit
NOTE
 y When you update the operating
system of your mobile device (such
as Windows/Android/iOS) the pairing
information may be invalidated.
Therefore, the device may need to be
reprogrammed to the hands-free unit.
 y If you pair your phone which has
already been paired to your vehicle
more than once in the past, you need to
delete “Mazda” on your mobile device.
Then, execute the Bluetooth
® search
on your mobile device once again, and
pair to a newly detected “Mazda”.
 y  Before you pair your device, make sure
that Bluetooth ® is “ON”, both on your
phone and on the vehicle.
Voice recognition related problems
Symptom Cause Solution
method
Poor voice
recognition
y Excessive, slow speech.
y Excessive, forceful speech
(shouting).
y Speaking before the beep sound
has ended.
y Loud noise (speaking or
noise from
outside/inside
vehicle).
y Airfl ow from
A/C is blowing
against the
microphone.
y Speaking in off-standard
expressions
(dialect). Regarding the
causes indicated
on the left, be
careful with
how you speak.
In addition,
when numbers
are spoken in
a sequence,
recognition
ability will
improve if no
stop is placed
between the
numbers.
False
recognition
of numbers
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–19
If Trouble Arises
Overheating
Overheating
If the High engine coolant temperature
warning light illuminates, the vehicle loses
power, or you hear a loud knocking or
pinging noise, the engine is probably too
hot.
WARNING
Switch the ignition to off and make
sure the fan is not running before
attempting to work near the cooling
fan: Working near the cooling fan when it
is running is dangerous. The fan could
continue running indefi nitely even if
the engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.

Do not remove either cooling
system cap when the engine and
radiator are hot: When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.

Open the hood ONLY after steam is no
longer escaping from the engine: Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.
If the High engine coolant temperature
warning light illuminates:
1. Drive safely to the side of the road and park off the right-of-way.
2. Put a vehicle with an automatic transaxle in park (P), a manual
transaxle in neutral.
3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is escaping from the engine compartment.
If steam is coming from the engine compartment:
Do not go near the front of the vehicle. Stop the engine.
Wait until the steam dissipates, then open the hood and start the engine.
If neither coolant nor steam is escaping:
Open the hood and idle the engine until it cools.
CAUTION
If the cooling fan does not operate
while the engine is running, the engine
temperature will increase. Stop the
engine and call an Authorized Mazda
Dealer.
6. Make sure the cooling fan is operating, then turn off the engine after the
temperature has decreased.
7. When cool, check the coolant level.
If it is low, look for coolant leaks from the radiator and hoses.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–24
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
If a Warning Light Turns On or Flashes
If any warning light turns on/fl ashes, take appropriate action for each light. There is no
problem if the light turns off, however if the light does not turn off or turns on/fl ashes again,
consult an Authorized Mazda Dealer.
(Vehicles with type B Audio)
The warning contents can be verifi ed on the audio.
1. Select the (
) icon on the home screen to display the Applications screen.
2. Select the Warning Guidance.
Stop Vehicle in Safe Place Immediately
If any of the following warning lights turns on, the system may have a m\
alfunction. Stop the
vehicle in a safe place immediately and contact an Authorized Mazda Dealer.
Signal Warning
Brake System Warning
Light
This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the parking brake is applied with the ignitio\
n switched to
START or ON. It turns off when the parking brake is fully released.
Low brake fl uid level warning
If the brake warning light remains illuminated even though the parking b\
rake is
released, the brake fl uid may be low or there could be a problem with the brake system.
Park the vehicle in a safe place immediately and contact an Authorized Mazda Dealer.
WARNING
Do not drive with the brake system warning light illuminated. Contact an
Authorized Mazda Dealer to have the brakes inspected as soon as possible: Driving with the brake system warning light illuminated is dangerous. It indicates
that your brakes may not work at all or that they could completely fail at any
time. If this light remains illuminated, after checking that the parking brake is fully
released, have the brakes inspected immediately.

CAUTION
In addition, the eff ectiveness of the braking may diminish so you may need to
depress the brake pedal more strongly than normal to stop the vehicle.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
