If Trouble Arises
Flat Tire
2. Put a vehicle with an automatic transaxle in Park (P), a manual
transaxle in Reverse (R) or 1, and turn
off the engine.
3. Turn on the hazard warning fl asher.
4. Have everyone get out of the vehicle and away from the vehicle and traffi c.
5. Remove the jack, tool, and spare tire (page 7-3 ).
6. Block the wheel diagonally opposite the fl at tire. When blocking a wheel,
place a tire block both in front and
behind the tire.
NOTE
When blocking a tire, use rocks or wood
blocks of suffi cient size if possible to hold
the tire in place.
Removing a Flat Tire
1. If your vehicle is equipped with a wheel cover, pry off the wheel cover
with the beveled end of the jack lever.
NOTE
Force the end of the jack lever fi rmly
between wheel and cover, or removal will
be diffi cult.
2. Loosen the lug nuts by turning them counterclockwise one turn each, but do
not remove any lug nuts until the tire
has been raised off the ground.
3. Place the jack on the ground.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–9
If Trouble Arises
Flat Tire
WARNING
Use only the front and rear jacking
positions recommended in this manual: Attempting to jack the vehicle
in positions other than those
recommended in this manual is
dangerous. The vehicle could slip off
the jack and seriously injure or even kill
someone. Use only the front and rear
jacking positions recommended in this
manual.

Do not jack up the vehicle in a position
other than the designated jack-up
position or place any objects on or
under the jack: Jacking up the vehicle in a position
other than the designated jack-up
position or placing objects on or
under the jack is dangerous as it could
deform the vehicle body or the vehicle
could fall off the jack resulting in an
accident.

Use only the jack provided with your
Mazda: Using a jack that is not designed for
your Mazda is dangerous. The vehicle
could slip off the jack and seriously
injure someone.

Never place objects under the jack: Jacking the vehicle with an object
under the jack is dangerous. The jack
could slip and someone could be
seriously injured by the jack or the
falling vehicle. 7. Insert the jack lever and attach the lug
wrench to tire jack.
8. Turn the jack handle clockwise and raise the vehicle high enough so that
the spare tire can be installed. Before
removing the lug nuts, make sure your
Mazda is fi rmly in position and that it
cannot slip or move.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.7–10
If Trouble Arises
Flat Tire
WARNING
Do not jack up the vehicle higher than is
necessary: Jacking up the vehicle higher than
is necessary is dangerous as it could
destabilize the vehicle resulting in an
accident.

Do not start the engine or shake the
vehicle while it is jacked up: Starting the engine or shaking
the vehicle while it is jacked up is
dangerous as it could cause the vehicle
to fall off the jack resulting in an
accident.

Never go under the vehicle while it is
jacked up: Going under the vehicle while it is
jacked up is dangerous as it could
result in death or serious injury if the
vehicle were to fall off the jack.
9. Remove the lug nuts by turning them counterclockwise; then remove the
wheel and center cap.
Locking Lug Nuts *
If your vehicle has Mazda optional
antitheft wheel lug nuts, one on each
wheel will lock the tires and you must use
a special key to unlock them. This key will
attach to the lug wrench and can be stored
with the spare tire. Register them with
the lock manufacturer by fi lling out the
card provided in the glove compartment
and mailing it in the accompanying
envelope. If you lose this key, consult an
Authorized Mazda Dealer or use the lock
manufacturer's order form, which is with
the registration card.
Special key
Antitheft lug nut
To remove an antitheft lug nut
1. Obtain the special key for the antitheft
lug nut.
2. Place the special key on top of the antitheft lug nut, and be sure to hold
the key square to it. If you hold the key
at an angle, you may damage both key
and nut. Do not use a power impact
wrench.
3. Place the lug wrench on top of the key and apply pressure. Turn the wrench
counterclockwise.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–11
If Trouble Arises
Flat Tire
To install the antitheft lug nut
1. Place the special key on top of the nut, and be sure to hold the key square to
it. If you hold the key at an angle, you
may damage both key and nut. Do not
use a power impact wrench.
2. Place the lug wrench on top of the special key, apply pressure, and turn it
clockwise.
Nut tightening torque
N·m (kgf·m, ft·lbf) 108—147
(12—14, 80—108)
Mounting the Spare Tire
1. Remove dirt and grime from the
mounting surfaces of the wheel and
hub, including the hub bolts, with a
cloth.
WARNING
Make sure the mounting surfaces of
the wheel, hub and lug nuts are clean
before changing or replacing tires: When changing or replacing a tire,
not removing dirt and grime from the
mounting surfaces of the wheel, hub
and hub bolts is dangerous. The lug
nuts could loosen while driving and
cause the tire to come off , resulting in
an accident.
2. Mount the spare tire.
3. Install the lug nuts with the beveled edge inward; tighten them by hand.
WARNING
Do not apply oil or grease to lug nuts
and bolts and do not tighten the
lug nuts beyond the recommended
tightening torque: Applying oil or grease to lug nuts and
bolts is dangerous. The lug nuts could
loosen while driving and cause the tire
to come off , resulting in an accident.
In addition, lug nuts and bolts could
be damaged if tightened more than
necessary.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–12
If Trouble Arises
Flat Tire
4. Turn the lug wrench counterclockwise and lower the vehicle. Use the lug
wrench to tighten the nuts in the order
shown.
If you are unsure of how tight the nuts should be, have them inspected at an
Authorized Mazda Dealer.
Nut tightening torque
N·m (kgf·m, ft·lbf) 108—147
(12—14, 80—108)
WARNING
Always securely and correctly tighten
the lug nuts:
Improperly or loosely tightened lug
nuts are dangerous. The wheel could
wobble or come off . This could result
in loss of vehicle control and cause a
serious accident.

Be sure to reinstall the same nuts you
removed or replace them with metric
nuts of the same confi guration:
Because the wheel studs and lug nuts
on your Mazda have metric threads,
using a non-metric nut is dangerous.
On a metric stud, it would not secure
the wheel and would damage the stud,
which could cause the wheel to slip off
and cause an accident.
5. Open the trunk/luggage compartment mat.
Trunk/Luggage compartment mat
6. Remove the belt for securing the fl at
tire.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

7–40
If Trouble Arises
When Liftgate/Trunk Lid Cannot be Opened
When Liftgate/Trunk Lid
Cannot be Opened
If the vehicle battery is dead or there is a
malfunction in the electrical system and
the liftgate/trunk lid can not be opened,
perform the following procedure as an
emergency measure to Open it:
(5–door)
1. Remove the cap on the interior surface of the liftgate with a fl athead
screwdriver.
Cap
2. Turn the lever to the right to unlock the liftgate.
Lever
Cap
(4–door)
1. Open the cover.
2. Open the cap.
Cover
Cap
3. Turn the screw counterclockwise and remove it, and then remove the cap.
Screw
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–3
Index
Child Safety Locks for Rear Doors ..... 3-20
Climate Control System ........................ 5-2 Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-8
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-30
Collision warning ................................ 7-39
Control Status Display ........................ 4-87
Cruise Control ................................... 4-100 Cruise Control Switch ................. 4-100
Cruise Control Set Vehicle Speed
Display ................................................ 4-17
Cup Holder ........................................ 5-137
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-16
Daytime Running Lights ..................... 4-47
Defroster Mirror ............................................ 4-57
Rear window ................................. 4-56
Dimensions ........................................... 9-6
Direct Mode Automatic transaxle ...................... 4-39
Door Locks .......................................... 3-11
Drive selection .................................... 4-88
Driving In Flooded Area ..................... 3-49 Driving Tips
Automatic transaxle ...................... 4-40
Break-in ......................................... 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Money-saving suggestions ............ 3-45
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-81 DSC OFF Indicator Light.............. 4-82
DSC OFF Switch........................... 4-82
TCS/DSC Indicator Light ............. 4-81
E
Emergency Starting Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-87
Engine Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-5
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-63 Aluminum Wheel Maintenance .... 6-68
Bright-Metal Maintenance ............ 6-67
Maintaining the Finish .................. 6-65
Plastic Part Maintenance ............... 6-69
