2014 MAZDA MODEL 3 4-DOOR keyless

3–12
Before Driving
Doors and Locks
NOTE
 y When the ignition is switched to ACC
or ON, the vehicle lock-out prevention
feature prevents you from locking
yourself out of the vehicle.
 All doors and the liftgate/trunk lid will automatically unlock if they are locked
using the power door locks with any
door open.
 The vehicle lock-out prevention feature does not operate while the ignition is
switched off.
 When any door is opened from the outside while the key is inside the
vehicle, the closed doors are locked. All
the doors are automatically unlocked by
closing the open door.
 (With the advanced keyless function) The beep sound is heard for about 10 seconds to notify the driver that the key
has been left in the vehicle.
(Without the advanced keyless
function)
 The horn sound is heard twice to notify the driver that the key has been left in
the vehicle.
 y(Door unlock (control) system with
collision detection)
 This system automatically unlocks
the doors in the event the vehicle
is involved in an accident to allow
passengers to get out of the vehicle
immediately and prevent being trapped
inside. While the ignition is switched
ON and in the event the vehicle
receives an impact strong enough to
infl ate the air bags, all the doors are
automatically unlocked after about 6
seconds have elapsed from the time of
the accident.
 The doors may not unlock depending on how an impact is applied, the force of
the impact, and other conditions of the
accident.
 If door-related systems or the battery is malfunctioning, the doors will not
unlock.
Locking, Unlocking with Key
All doors and the liftgate/trunk lid lock
automatically when the driver's door is
locked with the key.
All doors and the liftgate/trunk lid unlock
when the driver's door is unlocked and the
key is held in the unlock position for one
second or longer.
Turn the key toward the front to lock,
toward the back to unlock.
Lock Unlock
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

3–13
Before Driving
Doors and Locks
NOTE
Holding the key in the unlocked position in
the driver's door lock for about a second
unlocks all doors and the liftgate/trunk lid.
To unlock only the driver's door, insert the
key into the driver's door lock and turn
the key briefl y to the unlock position and
then immediately return it to the center
position.
Locking, Unlocking with Request Switch (With the advanced keyless
function)
All doors and the liftgate/trunk lid can be
locked/unlocked by pressing the request
switch on the front doors while the key is
being carried.
(5–door)
The request switch on the liftgate can only
be used to lock all doors and the liftgate.
Front doors
Request switch
Liftgate (5–door Lock only)
Request switch
To lock
To lock the doors and the liftgate/trunk lid,
press the request switch and the hazard
warning lights will fl ash once.
A beep sound will be heard once.
To unlock
Driver's door request switch
To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
fl ash twice.
To unlock all doors and the liftgate, press
the request switch again within 3 seconds
and two more beep sounds will be heard.
Front passenger door request switch
To unlock all doors and the liftgate, press
the request switch. A beep sound will be
heard twice and the hazard warning lights
will fl ash twice.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

3–16
Before Driving
Doors and Locks
 y Auto re-lock function After unlocking with the request switch,
all doors and the liftgate/trunk lid
will automatically lock if any of the
following operations are not performed
within about 60 seconds. If your
vehicle has a theft-deterrent system,
the hazard warning lights will fl ash for
confi rmation.
 The time required for the doors to lock automatically can be changed.
 Refer to Personalization Features on page 9-12 .
 y Opening a door or the liftgate/trunk
lid.
 y Switching the ignition to any position
other than off.
Locking, Unlocking with Transmitter
All doors and the liftgate/trunk lid can be
locked/unlocked by operating the keyless
entry system transmitter, refer to Keyless
Entry System (page 3-3 ).
Locking, Unlocking with Door-Lock Switch
All doors and the liftgate/trunk lid lock
automatically when the lock side is
pressed. They all unlock when the unlock
side is pressed.
Driver's door
Unlock
Lock
Front passenger's door
Unlock Lock
To lock all the doors/liftgate/trunk lid from
an open front door, press the lock side of
the door lock switch and then close the
door.
NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

3–22
Before Driving
Doors and Locks
Opening and Closing the Liftgate/Trunk Lid
Opening the liftgate (5–door)
Using the electric liftgate opener
Unlock the doors and liftgate, then press
the electric liftgate opener on the liftgate
and raise it when the latch releases.
Electric liftgate
opener
While the ignition is switched ON, the
liftgate can only be opened when the
vehicle is stopped.
NOTE
(With the advanced keyless function)
 y  A locked liftgate can also be opened
while the key is being carried.
 y When opening the liftgate with the
doors and the liftgate locked, it may
require a few seconds for the liftgate
latch to release after the electric liftgate
opener is pressed.
 y The liftgate can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the liftgate can be
opened by pressing the electric liftgate
opener.
 y When the liftgate latch is released by
pressing the electric liftgate opener,
the liftgate raises slightly to allow
it to be opened. If the liftgate is not
operated for a certain period of time
after the electric liftgate opener has
been pressed, the liftgate cannot be
raised any more from its slightly raised
position. Press the electric liftgate
opener again to fully open the liftgate.
To close the liftgate from its slightly
raised position, open it fi rst by pressing
the electric liftgate opener, then close it
after waiting at least 1 second.
 If the liftgate is not fully closed, the driver is notifi ed by a warning indicated
in the instrument cluster.
 y  The sound of the latch may be heard for
a few seconds after the electric liftgate
opener has been pressed, however, this
does not indicate a malfunction.
Opening the trunk lid (4–door)
Using the remote release button
Push the release button.
While the ignition is switched ON, the
trunk lid can only be opened when the
vehicle is stopped.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

3–23
Before Driving
Doors and Locks
Using the electric trunk lid opener
(With the advanced keyless function)
A locked trunk lid can also be opened
while the key is being carried.
Press the electric trunk lid opener on the
trunk lid, then raise the trunk lid when the
latch releases.
Electric trunk lid
opener
While the ignition is switched ON, the
trunk lid can only be opened when the
vehicle is stopped.
NOTE
 y When opening the trunk lid with the
doors and the trunk lid locked, it may
require a few seconds for the trunk lid
latch to release after the electric trunk
lid opener is pressed.
 y The trunk lid can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the trunk lid can be
opened by pressing the electric trunk lid
opener.
Closing the liftgate/trunk lid
Lower the liftgate/trunk lid slowly using
the liftgate/trunk lid grip recess, then push
the liftgate/trunk lid closed using both
hands.
Do not slam it. Pull up on the liftgate/trunk
lid to make sure it is secure.
(5–door)
Liftgate grip
recess
(4–door)
Trunk lid grip recess
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.3–43
Before Driving
Security System
Theft-Deterrent System *
If the theft deterrent system detects an
inappropriate entry into the vehicle,
which could result in the vehicle or its
contents being stolen, the alarm alerts the
surrounding area of an abnormality by
sounding the horn and fl ashing the hazard
warning lights.
The system will not function unless it's
properly armed. So when you leave the
vehicle, follow the arming procedure
correctly.
Operation
System triggering conditions
The horn sounds intermittently and the
hazard warning lights fl ash for about 30
seconds when the system is triggered by
any one of the following:
 y  Unlocking a door with the key, door
lock switch, or an inside door-lock knob.
 y  Forcing open a door, the hood or the
liftgate/trunk lid.
 y  Opening the hood by operating the hood
release handle.
 y  Switching the ignition ON without using
the push button start.
If the system is triggered again, the lights
and horn will activate until the driver's
door or the liftgate/trunk lid is unlocked
with the transmitter.
(With advanced key)
The lights and horn can also be
deactivated by pressing the request switch
on a door.
NOTE
If the battery goes dead while the theft-
deterrent system is armed, the horn will
activate and the hazard warning lights
will fl ash when the battery is charged or
replaced.
How to Arm the System
1. Close the windows and the moonroof *
securely.
2. Press the push button start off.
3. Make sure the hood, the doors, and the liftgate/trunk lid are closed.
4. Press the lock button on the transmitter or lock the driver's door from the
outside with the auxiliary key.
The hazard warning lights will fl ash
once.
The following method will also arm the theft-deterrent system:
Press the door-lock switch “
” while
any door is open and then close all of
the doors.
(With the advanced keyless function)
Press a request switch.
The security indicator light in the instrument panel fl ashes twice per
second for 20 seconds.
5. After 20 seconds, the system is fully armed.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

3–44
Before Driving
Security System
NOTE
 y The theft deterrent system can also be
armed by activating the auto relock
function with all the doors, the liftgate/
trunk lid and the hood closed.
 Refer to Transmitter on page 3-4 . y The system will disarm if one of the
following operations takes place within
20 seconds after pressing the lock
button:
 y Unlocking any door. y Opening any door or the liftgate/
trunk lid.
 y Opening the hood. y Switching the ignition on. y (With the advanced keyless
function)
 Pressing the electric liftgate/trunk lid
opener while the key is being carried.
 To rearm the system, do the arming procedure again.
 y When the doors are locked by pressing
the lock button on the transmitter
or using the auxiliary key while the
theft-deterrent system is armed, the
hazard warning lights will fl ash once to
indicate that the system is armed.
To Turn Off an Armed System
An armed system can be turned off using
any one of the following methods:
 y  Pressing the unlock button on the
transmitter.
 y  Switching the ignition ON. y(With the advanced keyless function)
y Pressing a request switch on the doors.
The hazard warning lights will fl ash twice.
NOTE
When the doors are unlocked by pressing
the unlock button on the transmitter while
the theft-deterrent system is turned off, the
hazard warning lights will fl ash twice to
indicate that the system is turned off.
To Stop the Alarm
A triggered alarm can be turned off using
any one of the following methods:
 y  Pressing the unlock button on the
transmitter.
 y  Starting the engine with the push button
start.
 y (With the advanced keyless function)
y Pressing a request switch on the doors.y Pressing the electric liftgate/trunk lid
opener while the key is being carried.
The hazard warning lights will fl ash twice.
Theft-Deterrent Labels
A label indicating that your vehicle is
equipped with a Theft-Deterrent System is
in the glove compartment.
Mazda recommends that you affi x it to the
lower rear corner of a front door window.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–4
When Driving
Start/Stop Engine
Ignition Switch
Push Button Start Positions
The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.
Each time the push button start is pressed,
the ignition switches in the order of off,
ACC, and ON. Pressing the push button
start again from ON switches the ignition
off.
Indicator light
NOTE
 y The engine starts by pressing the push
button start while depressing the clutch
pedal (manual transaxle) or the brake
pedal (automatic transaxle). To switch
the ignition position, press the push
button start without depressing the
pedal.
 y Do not leave the ignition switched ON
while the engine is not running. Doing
so could result in the battery going
dead. If the ignition is left in ACC (For
automatic transaxle, the selector lever
is in the P position, and the ignition
is in ACC), the ignition switches off
automatically after about 25 minutes. off
The power supply to electrical devices
turns off and the push button start indicator
light (amber) also turns off.
This position is in which the steering
wheel is locked.
WARNING
Before leaving the driver's seat, always
switch the ignition off
, set the parking
brake, and make sure the selector lever
is in P (automatic transaxle) or in 1st
gear or R (manual transaxle): Leaving the driver's seat without
switching the ignition off , setting the
parking brake, and shifting the selector
lever to P (automatic transaxle) or
to 1st gear or R (manual transaxle)
is dangerous. Unexpected vehicle
movement could occur which could
result in an accident.
In addition, if your intention is to leave
the vehicle for even a short period, it
is important to switch the ignition off ,
as leaving it in another position will
disable some of the vehicle's security
systems and run the battery down.
ACC (Accessory)
Some electrical accessories will operate
and the indicator light (amber) illuminates.
NOTE
The keyless entry system does not function
while the push button start has been
pressed to ACC, and the doors will not
lock/unlock even if they have been locked
manually.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
