2014 MAZDA MODEL 3 4-DOOR display

5–118
Interior Features
Bluetooth®
How to Use the Bluetooth ® Audio System
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded to a Bluetooth
® audio device, switch to the
Bluetooth® audio mode to operate the audio device using the audio system control p\
anel.
Any Bluetooth ® audio device must be programmed to the vehicle's Bluetooth ® unit before it
can be used.
Refer to Bluetooth
® Preparation (Type B) on page 5-92 .
1. Turn on the Bluetooth
® audio device's power.
2. Switch the ignition to ACC or ON.
3. Select the
icon on the home screen and display the Audio screen.
4. When Bluetooth ® is selected, switches to the Bluetooth ® audio mode to begin playback.
NOTE
 y  If the Bluetooth ® audio device does not begin playback, select the icon. y If the mode is switched from Bluetooth ® audio mode to another mode (radio mode), audio
playback from the Bluetooth ® audio device stops.
Playback
To listen to a Bluetooth
® audio device over the vehicle's speaker system, switch the mode to
Bluetooth® audio mode. (Refer to “Switching to Bluetooth ® audio mode”)
After switching to the Bluetooth ® audio mode, the following icons are displayed in the
lower part of the display. Icons which can be used differ depending on the version of the
Bluetooth
® audio device which you are currently using.
Icon Function
Displays the Audio menu. Use to switch to a different audio source.
(AVRCP Ver. 1.4 only)
Displays the top level folder/fi le list.
Select the folder which you want to select.
The fi les in the selected folder are displayed.
Select the fi le you want to play.
(AVRCP Ver. 1.3 or higher)
Replays the song currently being played repeatedly.
When selected again, the songs in the folder are played repeatedly.
Select it again to cancel.
Icons change when the song is repeated or the folder is repeated.
(AVRCP Ver. 1.3 or higher)
Plays songs in the folder in random order.
When selected again, the songs on the device are played in random order.
Select it again to cancel.
Icons change during folder shuffl e or device shuffl e.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–119
Interior Features
Bluetooth®
Icon Function
Scans the titles in a folder and plays the beginning of each song to aid\
in fi nding a desired
song.
When selected again, the beginning of each song on the device is played.\
When selected again, the operation is canceled and the song currently be\
ing played
continues.
Returns to the beginning of the previous song.
Long-press to fast reverse. It stops when you remove your hand from the \
icon or the
commander knob.
Plays the Bluetooth ® audio. When selected again, playback is temporarily stopped.
Advances to the beginning of the next song.
Long-press to fast forward. It stops when you remove your hand from the \
icon or the
commander knob.
Adjusts the audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
Example of use (When searching for a
song from the top level of a device)
1. Select the
icon and display the
folder/fi le list at the top level.
2. When the folder is selected, folders/fi le
lists in the folder are displayed.
When the playlist is selected, the fi le
list is displayed.
3. Select the desired song.
NOTE
Select the icon to move to a folder one
level higher.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–120
Interior Features
Bluetooth®
Bluetooth ® Audio Device
Information Display
If a Bluetooth ® audio device is connected,
the following information is displayed in
the audio display.
AVRCP
Ver. lower than 1.3 AVRCP
Ver. 1.3 AVRCP
Ver. 1.4 or higher
Device name X X X
Remaining
battery
charge of
device X X X
Song name — X X
Artist name — X X
Album name — X X
Playback
time — X X
Genre name — X X
X: Available
—: Not available
NOTE
Some information may not display
depending on the device, and if the
information cannot be displayed,
“Unknown - - -” is indicated.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.5–121
Interior Features
Bluetooth®
How to Use Pandora ®*
What is Pandora ® ?
Pandora
® is free personalized Internet radio. Simply enter a favorite artist, tr\
ack, genre,
and Pandora ® will create a personalized station that plays their music and more like\
it.
Rate songs by giving thumbs-up and thumbs-down feedback to further refi\
ne your station,
discover new music and help Pandora
® play only music you like.
* Pandora ® , the Pandora ® logo, and the Pandora ® trade dress are trademarks or registered
trademarks of Pandora Media, Inc., used with permission.
NOTE
To operate Pandora ® from your Bluetooth ® device, perform the following in advance:
 y  Create Pandora ® account on the Web. y Create Pandora ® station using Pandora ® application. y Install Pandora ® application on your device.
Playback
Select the
icon on the home screen and display the Audio screen. When icon is
selected, the following icons are indicated in the bottom part of the au\
dio display.
Icon Function
Displays the Audio menu. Use to switch to a different audio source.
Displays the station list.
Use to switch to other stations.
Thumbs-Down
Press the
icon to tell Pandora ® not to play this track.
Thumbs-Up
Press the
icon to tell Pandora ® “you like this track” and it helps to bring in more tracks
like it to your station.
Bookmarking
Bookmarks the song or artist currently being played.
Plays the track. When selected again, playback is temporarily stopped.
Goes to the next song.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–122
Interior Features
Bluetooth®
Icon Function
Adjusts the audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
NOTE
 y The skip function may not be available
depending on the device.
 y The number of skips is limited by
Pandora® . y If the icon is selected when the skip
song function is running, the next song
is skipped.
Selection from station list
Selection can be made from a programmed
radio station list.
1. Select the
icon.
2. Select the desired radio station.
NOTE
When is selected, songs randomly
selected from the radio station list are
played.
Selecting the sort method
The displayed order of the station list can
be changed.
1. Select the
icon.
2. Select the
icon.
3. Select the
icon to display in the
order starting from the newly created
station.
4. Select the
icon to display in
alphabetical order.
NOTE
The displayed order of cannot be
changed.
Bookmarking
You can bookmark song or artist to check
out later on the Web.
1. Select the
icon.
2. Select
to bookmark the
song.
3. Select
to bookmark the
artist.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.5–123
Interior Features
Bluetooth®
How to Use Aha™*
Aha is an application which can be accessed easily by personalizing vari\
ous Internet content
such as Internet radio and podcasts.
Stay connected to your friends activities by getting updates from Facebo\
ok and Twitter.
Your travel is assisted by locating surrounding restaurants or cafes, or \
acquiring traffi c
information in real time using the Location Based Services.
For details on Aha, refer to “http://www.aharadio.com/”.
* Aha, the Aha logo, and the Aha trade dress are trademarks or registered trademarks of Harman International Industries, Inc., used with permission.
NOTE
 y  The service content provided by Aha varies depending on the country in which the user
resides.
 y To operate Aha from your Bluetooth ® device, perform the following in advance:
 y Install the Aha application to your device. y Create an Aha account for your device. y Log onto Aha using your device. y Select the preset station on your device.
Playback
Select the
icon on the home screen and display the Audio screen. When the icon is
selected, the following icons are displayed at the bottom of the audio d\
isplay. The displayed
icon differs depending on the selected station.
In addition, icons other than these icons may be displayed.
Icon Function
Displays the Audio menu. Use to switch to a different audio source.
Displays the main menu.
Use to switch to other stations.
Displays the content list.
Use to switch to other desired content on the station.
Reverses for 15 seconds.
Fast-forwards for 30 seconds.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–124
Interior Features
Bluetooth®
Icon Function
Like/Thumbs-Up*
Evaluates the current content as “Like”.
Dislike/Thumbs-Down*
Evaluates the current content as “Dislike”.
Shout
Records voice.
Records voice and posts it as playable audio to Facebook and other socia\
l stations.
Map (Only navigation-equipped vehicles)
Sets the destination of the navigation to the location searched using th\
e Location Based
Services.
Call
A call can be made to the telephone number of a shop searched using the L\
ocation Based
Services. Can be used only when the connected device is connected as Han\
ds-Free.
Returns to the previous content.
Pauses playback of the content. When selected again, playback resumes.
Goes to the next content.
Adjusts the audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
* Some stations may use alternate variations of Like and Dislike, based on\
station type or
provider.
Main menu
Select the
icon.
Switch the tab and select the station category.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–125
Interior Features
Bluetooth®
Tab Function
Presets Displays the preset station list set on the device.
Select the preset station name to play the station content.
Location Based Services Select the desired station.
Guidance is provided to the searched destination near the vehicle's posi\
tion.
You can designate desired categories previously set using the fi
lter setting
on your device.
NOTE
The available Location Based Services may differ because the services de\
pend on the
content provided by Aha™.
