2014 LEXUS LX570 language

5263-3. Using the audio system
LX570_OM_OM60L21U_(U) ■ DVD video discs
● The DVD player conforms to NT SC/PAL color TV formats. DVD
video discs conforming to anot her format such as SECAM cannot
be used.
● Region code: Some DVD video disc s have a region code indicating
the region in which yo u can use the DVD video disc. If the DVD
video disc is not labeled as “ALL” or “1”, you cannot use it on this
DVD player. If you attempt to play an inappropriate DVD video disc
on this player, “Region Code Error” appears on the screen. Even if
the DVD video disc does not have a region code, you may not be
able to use it. ■
Symbols shown on DVD video discs
Symbol Meaning
NTSC/PAL Indicates NTSC/PAL format of color TV
Indicates the number of audio tracks
Indicates the number of language subtitles
Indicates the number of angles
Indicates the screen display ratios available
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s region code
ALL: in all countries
Number: region code

5283-3. Using the audio system
LX570_OM_OM60L21U_(U) ■
DVD video disc information ●
DVD video discs
A DVD video disc is a Digital Versatile Disc that holds video. DVD video discs
have adopted “MPEG2”, one of the wo rld standards of digital compression
technologies. The picture data is compressed by 1 /40 on average and stored.
Variable rate encoded technology in which the volume of data assigned to the
picture is changed depending on the pi cture format has also been adopted.
Audio data is stored using PCM and Dolby Digital, which enables higher quality
of sound. Furthermore, multi-angle and multi-language features will also help
you enjoy the more advanced technology of DVD video. ●
Viewer restrictions
This feature limits what can be viewed in conformity with the level of restrictions
of the country. The level of restrictions varies depending on the DVD video disc.
Some DVD video discs cannot be played at all, or violent scenes are skipped or
replaced with other scenes.
Level 1: DVD video discs for children can be played.
Level 2-7: DVD video discs for children and G-rated movies can be played.
Level 8: All types of DVD video discs can be played. ●
Multi-angle option
You can enjoy the same scene from different angles. ●
Multi-language option
You can select the subtitle and audio languages. ●
Region codes
The region codes are provided on DVD players and DVD discs. If the DVD
video disc does not have the same regi on code as the DVD player, you cannot
play the disc on the DVD player. (  P. 5 2 6 )●
Audio
This DVD player can play linear PCM, Dolby Digital and MPEG audio format
DVDs. Other decoded types cannot be played. ●
Title and chapter
Video and audio programs stored in DVD video discs are divided into parts by
title and chapter.
Title: The largest unit of the video and audio programs stored on DVD video discs.
Usually, one movie, one album, or one audio program is assigned as a title.
Chapter: A title is comprised of one or more chapters.

5973-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) ■ Control icon screen
Press the “OPTION” button on the controller if no icons are shown
while watching a DVD video, and the following screen appears.
Hide the buttons
Setting screen appears
(  P. 6 0 1 )
Menu screen appears
Rewind
Stop
Play/pause
Fast forward
If appears on the screen when you select an icon, the operation
relevant to that control is not permitted.
■ Settings screen
Select “Settings” on the control icon screen, the following screen
appears.
Change initial setting
Return to previous screen
Search by title
Display the predetermined
scene and start playing from
there
Change audio language
Change subtitle language
Change angle

5993-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Returning to the previous screen
Select “Return” to return to the pre vious screen. For the operation of the
menu screen, see the separate manual for the DVD disc.
Searching for a desired screen
■ Searching by title
Select “Search” on the control icon screen.
Input the desired title number and then select “OK”. : Deletes the last input number
: Returns to the previous screen
■ Searching by chapter
Press or to select a chapter.
Changing the subtitle language
Select “Subtitle” on the settings screen.
Select “Subtitle”. Each time you select “Subtitle”, the
next available language is selected.
“Hide”: Hides the control icons
: Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

6003-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Changing the audio language
Select “Audio” on the setting screen.
Select “Audio”. Each time you select “Audio”, the
next available language is selected.
: Returns to the previous
screen
Changing the angle (If the angle option is available)
Select “Angle” on the setting screen.
Select “Angle”. Each time you select “Angle”, the
next available angle is selected.
: Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

6023-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) ■ Setting audio language
Select “Audio Language”.
Select the language you want to hear on the “Audio Language”
screen. If you cannot find the desired lang uage, select “Other” and input the
desired language code. (  P. 6 0 3 )
■ Setting subtitle language
Select “Subtitle Language”.
Select a language you want to read on the “Sub title Language”
screen. If you cannot find the desired lang uage, select “Other” and input the
desired language code. (  P. 6 0 3 )
■ Setting menu language
Select “DVD Language”.
Select the language you want to read on the “DVD Language”
screen. If you cannot find the desired lang uage, select “Other” and input the
desired language code. (  P. 6 0 3 )
■ Setting angle mark
If the DVD has angle options, you can turn the angle mark on or off.
Select “Angle Mark”.
Select “ON” or “OFF”. STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2

6033-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) ■ Parental lock
Select “Parental Lock”.
Enter the 4-digit personal code on the “Enter Key Code” screen.If you enter wrong numbers, select to delete the numbers.
Select a parental level (1 - 8). (  P. 5 2 8 )
■ Setting sound dynamic range
The difference between the lowest volume and the highest volume can
be adjusted.
Select “Sound Dynamic Range”.
Select “MAX”, “STD” or “MIN”.
■ Entering a language code
If you select “Other” on the “A udio Language” screen, “Subtitle
Language” screen or “DVD Language” screen, you can select a
language by entering the 4-digit la nguage code if that language is
available.
Enter the 4-digit language code. (  P. 522)If you enter wrong numbers, select to delete the numbers.
Select “OK”. STEP 1
STEP 2
STEP 3
STEP 1
STEP 2
STEP 1
STEP 2

7243-8. Other interior features
LX570_OM_OM60L21U_(U) ■
Safety Connect Services Information ●
Phone calls using the vehicles Bluetooth ®
technology will not be possible dur-
ing Safety Connect. ●
Safety Connect is available beginning Fall 2009 on select Lexus models. Con-
tact with the Safety Connect response center is dependent upon the telematics
device being in operative condition, ce llular connection availability, and GPS
satellite signal reception, which can limit the ability to reach the response center
or receive emergency service support. Enrollment and Telema tics Subscription
Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected. ●
Automatic Collision Notification, Emergency Assistance and Stolen Vehicle
Location will function in the United States, including Hawaii and Alaska, and in
Canada, and Enhanced Roadside Assistance will function in the United States
(except Hawaii) and in Canada. No Safety Connect services will function out-
side of the United States in countries other than Canada.●
Safety Connect services ar e not subject to section 255 of the Telecommunica-
tions Act and the device is not TTY compatible.■
Languages
The Safety Connect response center will offer support in multiple languages. The
Safety Connect system will offer voice prompts in English and Spanish. Please indi-
cate your language of choice when enrolling. ■
When contacting th e response center
You may be unable to contact the response center if the network is busy. ■
Safety Connect backup battery depletion
An exclusive backup battery is built in to assist the Automatic Collision Notification,
which is activated when impact above a certain level is applied to the vehicle, or
when the airbags operate. This battery is a primary battery, and cannot be
recharged. The red LED indicator will flash to indicate that the battery should be
replaced.
The backup battery will need to be replaced if the Automatic Collision Notification
operates for 60 seconds or more. For re placement, consult your Lexus dealer.
