5769-2. Customization
IS300h_EE(OM53C61E)
■Door lock (→P. 136, 143, 544)
■Smart entry & start system and wireless remote control (→P. 136, 143)
FunctionDefault settingCustomized setting
Unlocking using a mechani-
cal keyAll doors
unlocked in
one stepDriver's door
unlocked in one
step, all doors
unlocked in two
steps
———O
Speed-detecting automatic
door lock functionOnOffO—OO
Shifting gears to position
other than P locks all doorsOffOnO—OO
Shifting gears to P unlocks
all doorsOffOnO—OO
Opening driver's door
unlocks all doorsOnOffO—OO
Locking/unlocking of the
trunk when all doors are
locked/unlockedOnOff———O
1234
FunctionDefault settingCustomized setting
Operation signal
(Emergency flashers)OnOffO—OO
Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being
unlocked
30 seconds
60 seconds
——OO120 seconds
Open door warning buzzerOnOff———O
1234
IS300h_EE_OM53C61E.book 576 ページ ２０１４年５月２０日　火曜日　午後５時４０分

577
9 9-2. Customization
Vehicle specifications
IS300h_EE(OM53C61E)
■Smart entry & start system (→P. 136, 143, 149)
*: If equipped
■Wireless remote control (→P. 136, 143)
■Driving position memory* (→P. 1 6 8 )
*: If equipped
FunctionDefault settingCustomized setting
Smart entry & start systemOnOffO—OO
Smart door unlocking*All the doorsDriver's doorO—OO
Number of consecutive
door lock operations*As many as
desired2 times———O
1234
FunctionDefault settingCustomized setting
Wireless remote controlOnOff———O
Unlocking operationAll doors
unlocked in
one stepDriver's door
unlocked in one
step, all doors
unlocked in two
steps
O—OO
Trunk unlocking operationPress and hold
(short)
One short press
———O
Push twice
Press and hold
(long)
Off
1234
FunctionDefault settingCustomized setting
Driver's seat movement
when exiting the vehicleStandardOffO—OOPa r t i a l
Doors linked to the driving
position memory recall
functionDriver's doorAll doors———O
1234
IS300h_EE_OM53C61E.book 577 ページ ２０１４年５月２０日　火曜日　午後５時４０分

5789-2. Customization
IS300h_EE(OM53C61E)
■Outside rear view mirrors (→P. 1 8 0 )
*: If equipped
■Powe r w i n d ows (→P. 1 8 4 )
■Moon roof* (→P. 1 8 7 )
*: If equipped
FunctionDefault settingCustomized setting
Automatic mirror folding
and extending operation
*
Linked to the
locking/
unlocking of
the doorsOff
———OLinked to operation
of the power switch
1234
FunctionDefault settingCustomized setting
Mechanical key linked oper-
ationOffOn———O
Wireless remote control
linked operationOffOn———O
1234
FunctionDefault settingCustomized setting
Mechanical key linked oper-
ationOffOn———O
Linked operation of compo-
nents when mechanical key
is used (open only)Slide onlyTilt only———O
Wireless remote control
linked operationOffOn———O
Linked operation of compo-
nents when wireless remote
control is used (open only)Slide onlyTilt only———O
1234
IS300h_EE_OM53C61E.book 578 ページ ２０１４年５月２０日　火曜日　午後５時４０分

5829-2. Customization
IS300h_EE(OM53C61E)
■Vehicle customization
●When the speed-detecting automatic door lock and shift-linked automatic door lock
are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will be locked.
• If the vehicle is started with all doors locked, the speed-detecting automatic door
lock will not operate.
• If the vehicle is started with any door unlocked, the speed-detecting automatic door
lock will operate.
●When the smart entry & start system is off, the entry unlock function cannot be custom-
ized.
●When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational signal (Emergency flashers) function set-
tings.
■When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent 12-volt battery discharge, leave the hybrid system operating while customiz-
ing the features.
CAUTION
■During customization
As the hybrid system needs to be operating during customization, ensure that the vehi-
cle is parked in a place with adequate ventilation. In a closed area such as a garage,
exhaust gases including harmful carbon monoxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is operating while
customizing features.
IS300h_EE_OM53C61E.book 582 ページ ２０１４年５月２０日　火曜日　午後５時４０分

593Alphabetical index
IS300h_EE(OM53C61E)
Child-protectors ................................... 140
Cleaning ....................................... 426, 430
Aluminum wheels .............................. 427
Exterior.................................................... 426
Interior .....................................................430
Seat belts..................................................431
Clock .........................................................420
Coat hooks .............................................. 424
Condenser ............................................. 446
Console box ............................................ 414
Coolant ..................................................... 444
Capacity ................................................ 565
Checking ............................................... 444
Preparing and checking
before winter ....................................... 311
Cooling system...................................... 444
Engine overheating ..........................552
Hybrid system overheating ..........552
Cruise control
Cruise control ..................................... 245
Dynamic radar cruise control ..... 249
Cup holders ............................................. 415
Current fuel consumption.................... 116
Curtain shield airbags ........................... 43
Customizable features ....................... 574DAB (Digital Audio Broadcast) ..... 339
Daytime running light system ..........227
Defogger
Front windshield................................. 404
Outside rear view mirrors ............ 404
Rear window........................................ 404
Differential............................................... 567
Digital Audio Broadcast (DAB) ..... 339
Dimensions ............................................. 560
Display
Drive information...................................116
Dynamic radar cruise control ..... 249
LDA (Lane Departure Alert) .......262
Multi-information display...................115
Warning message ............................509
Distance ...................................................... 117
Do-it-yourself maintenance ............. 435
Door courtesy lights
Location ..................................................... 411
Wattage ................................................. 570
Door lock
Doors......................................................... 136
Smart entry & start system ............. 149
Wireless remote control ................. 130D
IS300h_EE_OM53C61E.book 593 ページ ２０１４年５月２０日　火曜日　午後５時４０分

599Alphabetical index
IS300h_EE(OM53C61E)
Inside door handle lights ....................... 411
Inside rear view mirror ........................ 178
Instrument panel light control ............ 112
Interior lights .............................................. 411
Wattage..................................................570
Intrusion sensor and tilt sensor .......... 99
ISOFIX rigid anchors............................. 69
Jack
Positioning the jack...........................438
Vehicle-equipped jack ...................459
Jack handle .............................................. 459
Jam protection function
Moon roof .............................................. 188
Power window ..................................... 185Keyless entry
Smart entry & start
system..........................................136, 143
Wireless remote control .......136, 143
Keys............................................................. 130
Battery-Saving Function ..................150
Electronic key........................................130
If the electronic key does not
operate properly ............................ 544
Key number plate ................................130
Keyless entry................................136, 143
Mechanical key ...................................... 131
Power switch ....................................... 209
Replacing the battery ........................ 471
Warning buzzer................................... 137
Wireless remote control ................. 130
Knee airbags ............................................. 43
J
K
IS300h_EE_OM53C61E.book 599 ページ ２０１４年５月２０日　火曜日　午後５時４０分

607Alphabetical index
IS300h_EE(OM53C61E)
Stop lights
Emergency brake signal ................ 287
Replacing light bulbs....................... 490
Storage feature....................................... 413
Stuck
If the vehicle becomes stuck ....... 556
Sun visors ................................................. 420
Sun shade
Rear .......................................................... 422
Roof ........................................................... 188
switch settings ................................... 117Switches
ASC (Active Sound Control)......225
Audio remote control
switches ...............................................322
Automatic High Beam switch......229
BSM (Blind Spot Monitor)
switch ................................................... 299
Cruise control
switch ....................................... 245, 249
Door lock switches............................. 139
Driving mode select switch.......... 283
Driving position memory
switches ................................................168
Emergency flashers switch........... 494
EV drive mode switch ...................... 214
Fog light switch................................... 233
Heated steering wheel
switch ................................................... 409
Ignition switch ..................................... 209
LDA (Lane Departure Alert)
switch ....................................................262
Lexus parking assist-sensor
switch ....................................................267
Light switch............................................226
Meter control switches.......................116
Moon roof switches ........................... 187
IS300h_EE_OM53C61E.book 607 ページ ２０１４年５月２０日　火曜日　午後５時４０分

609Alphabetical index
IS300h_EE(OM53C61E)
Tires ............................................................450
Chains ....................................................... 312
Checking .............................................. 450
Emergency tire puncture
repair kit ..............................................526
If you have a flat tire ............. 526, 540
Inflation pressure............................... 568
Replacing ...............................................459
Rotating tires ....................................... 450
Size........................................................... 568
Snow tires ................................................313
Tire inflation pressure display
function ..................................................451
Tire pressure warning system .......451
Warning light ...................................... 505
Tools ........................................................... 459
Top strap ..................................................... 74
Towing ....................................................... 496
Emergency towing............................496
Towing capacity ................................ 560
Towing eyelet ......................................499
Trailer towing ........................................ 201
Traction battery (hybrid battery).......83
Traction Control (TRC) ..................... 286
Traction motor (electric motor) ........ 79
Trailer towing .......................................... 201Transmission.............................................216
Driving mode select switch.......... 283
Hybrid transmission ........................... 216
If the shift lever cannot be
shifted from P................................... 543
Paddle shift switches.......................... 218
S mode ..................................................... 219
TRC (Traction Control) ..................... 286
Trip meters ............................................... 109
Trunk ............................................................143
Luggage security system ................ 145
Smart entry & start system ............. 143
Trunk features ....................................... 417
Trunk grip................................................ 144
Trunk light ............................................... 146
Trunk opener main switch .............. 145
Trunk opener switch.......................... 143
Wireless remote control ................. 144
Trunk light .................................................. 146
Trunk light ............................................... 146
Wattage ................................................. 570
Turn signal lights ................................... 222
Replacing light bulbs
........................... 480, 482, 483, 490
Turn signal lever.................................. 222
Wattage ................................................. 570
IS300h_EE_OM53C61E.book 609 ページ ２０１４年５月２０日　火曜日　午後５時４０分
