2014 Lexus IS250 air filter

TABLE OF CONTENTS6
IS350/250_U (OM53758U)
7-1. Maintenance and careCleaning and protecting the vehicle exterior ................ 384
Cleaning and protecting the vehicle inte rior.................. 387
7-2. Maintenance Maintenance requirements ............................ 390
General maintenance.............. 393
Emission inspection and maintenance (I/M)
programs .................................... 396
7-3. Do-it-yourself maintenance Do-it-yourself service precautions.................................397
Hood ............................................... 399
Positioning a floor jack.............400
Engine compartment ................ 401
Tires..................................................... 411
Tire inflation pressure ............... 420
Wheels ........................................... 423
Air conditioning filter ............... 425
Electronic key battery...............427
Checking and replacing fuses.............................................. 429
Light bulbs .................................... 432 8-1. Essential information
Emergency flashers .................. 446
If your vehicle has to be stopped in
an emergency ...........................447
8-2. Steps to take in an emergency
If your vehicle needs to be towed................................ 448
If you think something is wrong....................................... 453
Fuel pump shut off system ...... 454
If a warning light turns on or a warning buzzer
sounds ......................................... 455
If a warning message is displayed .................................. 461
If you have a flat tire ...................475
If the engine will not start ........ 485
If the shift lever cannot be shifted from P ..................... 487
If the electronic key does not operate properly .............488
If the vehicle battery is discharged............................. 490
If your vehicle overheats ......... 494
If the vehicle becomes stuck .............................................. 497
7Maintenance and care8When trouble arises

3486-1. Using the air conditioning system
IS350/250_U (OM53758U)
With a navigation system Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tem-
perature setting
Display the option control screen
( P. 3 4 8 )
Tu r n t h e f a n o f f
Select to set auto mode on/off
To adjust or select settings, move the Remote Touch knob to select the screen
button, and then press the Remote Touch knob to enter the selected function.
■Option control screen
The functions can be switched on and off.
Cooling and dehumidification
function
Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode) ( P. 3 4 9 )
Removing pollen from the air
(Micro dust and pollen filter)
( P. 3 4 9 )
1
2
3
4
5
6
7
1
2
3

3496-1. Using the air conditioning system
6
Interior features
IS350/250_U (OM53758U)
Press , or select “AUTO” on the air conditioning control screen.
Adjust the temperature setting.
To stop the operation, press or select “OFF” on the air conditioning
control screen.
■If the system is operated manually in automatic mode
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automati c mode for functions other than that
operated are maintained.
■Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:
●Press .
●Select “DUAL” on the option control screen.
●Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is set at the right-
hand side temperature setting.
■Switching between outside air and recirculated air modes
Press to change to recirculated air mode.
Press to change to outside air mode.
The indicator above the selected button comes on.
■Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.
Select on the option control screen.
When the micro dust and pollen filter is on, is displayed on the air condition-
ing control screen.
In order to prevent the windshield from fo gging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.
Using automatic mode
Other functions
1
2
3

3536-1. Using the air conditioning system
6
Interior features
IS350/250_U (OM53758U)
■When the outside temperature falls to nearly 32F (0 C)
The dehumidification function may not operate even when is pressed or “A/C” is
selected.
■Air conditioning odors
●During use, various odors from inside and outside the vehicle may enter into and accu-
mulate in the air conditioning system. This may then cause odor to be emitted from the
vents.
●To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior to turning the vehicle off.
• The start timing of the blower may be dela yed for a short period of time immediately
after the air conditioning system is started in automatic mode.
■Air conditioning filter
 P. 4 2 5
■Customization
Settings (e.g. A/C Auto switch operation) can be changed.
(Customizable features P. 5 3 1 )
CAUTION
■To prevent the windshield from fogging up
●Do not use during cool air operation in extremely humid weather. The differ-
ence between the temperature of the outside air and that of the windshield can cause
the outer surface of the windshield to fog up, blocking your vision.
■To prevent burns
●Do not touch the rear view mirror surfaces when the outside rear view mirror defog-
gers are on.
●Do not touch the glass at lower part of the wi ndshield or to the side of the front pillars
when the windshield wiper de-icer is on.
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is
stopped.
●Do not place anything on the instrument
panel which may cover th e air outlets. Other-
wise, air flow may be obstructed, preventing
the windshield defoggers from defogging.

383
Maintenance and care7
IS350/250_U (OM53758U)
7-1. Maintenance and careCleaning and protecting the vehicle exterior.................384
Cleaning and protecting the vehicle interior .................. 387
7-2. Maintenance Maintenance requirements.............................390
General maintena nce .............. 393
Emission inspection and maintenance (I/M)
programs .................................... 396
7-3. Do-it-yourself maintenance Do-it-yourself service precautions ................................ 397
Hood ............................................... 399
Positioning a floor jack ............ 400
Engine compartment ................ 401
Tires ..................................................... 411
Tire inflation pressure ............... 420
Wheels ........................................... 423
Air conditioning filter ............... 425
Electronic key battery ...............427
Checking and replacing fuses .............................................. 429
Light bulbs..................................... 432

3987-3. Do-it-yourself maintenance
IS350/250_U (OM53758U)
CAUTION
The engine compartment contains many mechanisms and fluids that may move suddenly,
become hot, or become electrically energized. To avoid death or serious injury, observe
the following precautions.
■When working on the engine compartment
●Keep hands, clothing and tools away from the moving fan and engine drive belt.
●Be careful not to touch the engine, radiator, exhaust manifold, etc. right after driving
as they may be hot. Oil and other fluids may also be hot.
●Do not leave anything that may burn easily, such as paper and rags, in the engine
compartment.
●Do not smoke, cause sparks or expose an open flame to fuel or the battery. Fuel and
battery fumes are flammable.
●Be extremely cautious when working on the battery. It contains poisonous and corro-
sive sulfuric acid.
■When working near the electric cooling fans or radiator grille
Be sure the engine switch is off.
With the engine switch in IGNITION ON mode, the electric cooling fans may auto-
matically start to run if the air conditioning is on and/or the coolant temperature is high.
(  P. 4 0 6 )
■Safety glasses
Wear safety glasses to prevent flying or fallin g material, fluid spray, etc. from getting in
your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear due to dirt
in the air.

4257-3. Do-it-yourself maintenance
7
Maintenance and care
IS350/250_U (OM53758U)
Turn the engine switch off.
Open the glove box. Lift up the side
with the stay, disconnect the stay
tabs and remove the partition by
pulling horizontally.
Press the tabs and remove the filter
cover.
Press the tabs and remove the filter
case.
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air condi-
tioning efficiency.
Removal method
1
2
3
4

4267-3. Do-it-yourself maintenance
IS350/250_U (OM53758U)
Remove the air conditioning filter
from the filter case and replace it
with a new one.
The “ UP” marks shown on the filter
and the filter case should be pointing up.
■Checking interval
Inspect and replace the air conditioning filt er according to the maintenance schedule. In
dusty areas or areas with heavy traffic flow, early replacement may be required. (For
scheduled maintenance informat ion, please refer to the “Owner’s Manual Supplement”
or “Scheduled Maintenance”.)
■If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
5
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the system.
