501-1. For safe use
GX460_OM_OM60K80U_(U)
CAUTION
■Front passenger occupant classification system precautions
●Do not recline the front passenger seatback so far that it touches the rear seat. This
may cause the “AIR BAG OFF” indicator light to be illuminated, which indicates that
the SRS airbags for the front passenger will no t activate in the event of a severe acci-
dent. If the seatback touches the rear seat, return the seatback to a position where it
does not touch the rear seat. Keep the fron t passenger seatback as upright as possi-
ble when the vehicle is moving. Reclining the seatback excessively may lessen the
effectiveness of the seat belt system.
●If an adult sits in the front passenger seat , the “AIR BAG ON” indicator light is illumi-
nated. If the “AIR BAG OFF” indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn correctly. If
the “AIR BAG OFF” indicator still remains illuminated, either ask the passenger to
move to the rear seat, or if that is not possible, move the front passenger seat fully
rearward.
●When it is unavoidable to install a forward- facing child restraint system on the front
passenger seat, install the child restraint sy stem on the front passenger seat in the
proper order. ( P. 5 6 )
●Do not modify or remove the front seats.
●Do not kick the front passenger seat or subj ect it to severe impact. Otherwise, the
SRS warning light may come on to indicat e a malfunction of the front passenger
occupant classification system. In this ca se, contact your Lexus dealer immediately.
●Child restraint systems installed on the rear seat should not contact the front seat-
backs.
●Do not use a seat accessory, such as a cu shion and seat cover, that covers the seat
cushion surface.
●Do not modify or replace the upholstery of the front seat.

GX460_OM_OM60K80U_(U)
1253-3. Adjusting the seats
3
Operation of each component
■Returning the third seatsPress and hold .
Two beeps sound and seatback
and seat cushion begin to move.
When operating is completed,
two beeps sound again.
Lift the head restraints up until
they lock.
■The third power seats can be operated when
●The engine switch is off.
●The shift lever is in P position with th e engine switch in IGNITION ON mode.
■During third power seat stowing operation
Do not remove your hand from the switch un til the operation stops automatically. If you
remove your hand from the switch, the operat ion will stop and the buzzer will sound con-
tinuously. The seat cannot be used in this state. The buzzer will stop when the switch is
pressed again.
1
2

GX460_OM_OM60K80U_(U)
1273-3. Adjusting the seats
3
Operation of each component
CAUTION
■When folding the seatbacks down
Observe the following precautions. Failure to do so may result in death or serious
injury.
●Do not fold the seatbacks down while driving.
●Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
●Do not allow anyone to sit on a folded seatback or in the luggage compartment while
driving.
●Do not allow children to enter the luggage compartment.
■Seat adjustment
Observe the following precautions. Failure to do so may result in death or serious
injury.
●To reduce the risk of sliding under the lap belt during a collision, do not recline the
seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shoulder belt, increasing the
risk of death or serious injury in the event of an accident.
Adjustments should not be made while dr iving as the seat may unexpectedly move
and cause the driver to lose control of the vehicle.
●Be careful not to get hands or feet pinc hed between the rear console box and the
second seat when folding down the rear seatback.
■When stowing the third seats
Observe the following precautions. Failure to do so may result in death or serious
injury.
●Check that there is no luggage and that there are no other people around the seat
before stowing operation.
●Do not insert hands or feet into the moving parts of the seat.
●Do not allow children to operate the seat.
■After returning the seatbacks to the upright position
Observe the following precautions. Failure to do so may result in death or serious
injury.
●Make sure the seatback is securely locked by pushing it forward and rearward on the
top.
●Check that the seat belts are not twisted or caught in the seatback.
NOTICE
■When returning the third seat (vehicles with a luggage cover)
If the luggage cover is installed in the luggage compartment, make sure you remove it
before returning the third seat. ( P. 404) The luggage cover may be damaged by the
seat.

GX460_OM_OM60K80U_(U)
1333-3. Adjusting the seats
3
Operation of each component
■Removing the head restraints
Front and second seats
Third seats
The head restraint cannot be removed.
■Installing the head restraints (front and second seats)
■Adjusting the height of the head re straints (front and second seats)
■Using the second center seat head restraint
■Using the third seats
Always lift the head restraints up until they lock when using.
Pull the head restraint up
while pressing the lock
release button.
Align the head restrain t with the installation
holes and push it down to the lock position.
Make sure that the head restraints are adjusted
so that the center of the head restraint is closest
to the top of your ears.
Always raise the head restraint one level from
the stowed position when using.
Lock release button

134
GX460_OM_OM60K80U_(U)3-3. Adjusting the seats
CAUTION
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to do so may
result in death or serious injury.
●Use the head restraints designed for each respective seat.
●Adjust the head restraints to the correct position at all times.
●After adjusting the head restraints, push down on them and make sure they are
locked in position.
●Do not drive with the head restraints removed.

GX460_OM_OM60K80U_(U)
3775-1. Using the air conditioning system and defogger
5
Interior features
■Adjusting the temperature setting
Press to increase the temperature and to decrease the tempera-
ture.
■Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan speed.
Press the “OFF” button to turn the fan off.
■Changing the air flow mode
Select an air outlet switch.
■Option control screen
Touch on the climate screen to display the option control screen. The
functions can be switched on and off.
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for driver
and passenger seats separately
(“DUAL” mode)/driver, passen-
ger and rear seats separately (“3-
ZO N E ” m o d e ) ( P. 3 7 8 )
Prevent ice from building up on
the windshield and wiper blades
(if equipped) ( P. 3 8 1 )
Remove pollen from the air ( P. 3 8 1 )
1
2
3
4

609Alphabetical index
GX460_OM_OM60K80U_(U)
Bottle holders ......................................... 399
BrakeFluid............................................................ 561
Parking brake.......................................... 191
Warning light ...................................... 507
Brake assist ...............................................341
Break-in tips............................................. 150
Brightness control Instrument panel light control ..................................................... 78
BSM (Blind Spot Monitor)................ 347
Care ................................................ 434, 437 Aluminum wheels ..............................434
Exterior....................................................434
Interior ..................................................... 437
Seat belts ............................................... 438
Cargo hooks .......................................... 402
Center differential................................ 332
CD player
*
Chains ....................................................... 366
Child restraint system............................ 52 Booster seats, definition ....................53
Booster seats, installation....................61
Convertible seats, definition ............ 53
Convertible seats, installation ............................................. 58
Installation with LATCH system ..................................................... 57
Installing CRS with seat belts ......... 58
Installing CRS with top straps..................................... 62 Infant seats, definition.......................... 53
Infant seats, installation....................... 58
Child safety .................................................. 51 Airbag precautions...............................37
Back door precautions...................... 101
Battery precautions ..............460, 547
Child restraint system......................... 52
Glass hatch precaution ................... 105
How your child should wear the seat belt .......................................... 30
Installing child restraints .................... 56
Moon roof precautions ....................148
Power window lock switch............. 142
Power window precautions ........... 144
Rear door child-protectors ............. 95
Removed key battery precautions ...................................... 480
Seat belt precautions ............................ 31
Seat heater precautions .................390
Child-protectors ..................................... 95
Cleaning Aluminum wheels .............................. 434
Exterior ................................................... 434
Interior ..................................................... 437
Seat belts................................................438
Coat hooks ............................................... 417
Compass ................................................... 419
Condenser...............................................457
Console box ........................................... 396
Cool box .................................................. 409
Cooling system ..................................... 455 Engine overheating ..........................548
Conversation mirror............................. 412
C
*:For vehicles with a navigation system or a multimedia system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIMEDIA OWNER’S MANUAL”.
