2014 Lexus GS250 run flat

1092. Instrument cluster
2
Instrument cluster
GS350_250_OM_OM30E16E_(EE)
■Tire inflation pressure (if equipped)
●It may take a few minutes to display the tire inflation pressure after the engine
switch is turned to IGNITION ON mode. It may also take a few minutes to display
the tire inflation pressure after inflation pressure has been adjusted.
●“---” may be displayed if the tire position information cannot be determined due to
unfavorable radio wave conditions.
●Tire inflation pressure changes with temperature. The displayed values may also be
different from the values measured using a tire pressure gauge.
■Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is character-
istic of liquid crystal displays, and there is no problem continuing to use the display.
■Customization
Setting of available languages can be changed. (Customizable features: →P. 6 5 2 )
CAUTION
■The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal informa-
tion display. At extremely low temperatures, the information display monitor may
respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number
appearing on the display. This lag could cause the driver to downshift again, caus-
ing rapid and excessive engine braking and possibly an accident resulting in death
or injury.
■Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such as a
garage, exhaust gases including harmful carbon monoxide (CO) may collect and
enter the vehicle. This may lead to death or a serious health hazard.
NOTICE
■During setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the
display features.
GS350_250_OM_OM30E16E_(EE).book Page 109 Tuesday, July 8, 201 4 7:11 PM

3114-5. Using the driving support systems
4
Driving
GS350_250_OM_OM30E16E_(EE)
■After the vehicle has been parked in the sun
The LKA system functions may not be available and a warning message (→P. 5 6 3 )
will be displayed for a while after driving has started. In such cases, turn the LKA sys-
tem off and turn it on again after normal temperature returns. When the temperature
in the cabin decreases and the temperature around the camera sensor ( →P. 3 0 5 )
becomes suitable for its operation, the functions will begin to operate.
■If there are lane markers on only one side of the vehicle
The lane keeping assist function will not operate. Also, the lane departure warning
will not operate for the side on which lane markers could not be recognized.
■Conditions in which the function may not operate correctly
In the following conditions, the LKA system functions may not operate, or it may not
be possible to ensure adequate performance. Also, the camera sensor may be
unable to recognize lane lines causing the lane departure warning function to oper-
ate incorrectly, or the lane keeping assist function may not operate properly. How-
ever, this does not indicate a malfunction.
●When driving through an area with no lane markers, such as a tollbooth, a crossing
or before a ticket checkpoint
●When driving on a sharp curve
●When lanes are extremely narrow or extremely wide
●When the vehicle leans to one side an unusual amount due to a heavy load or
improper tire inflation pressure
●When the following distance between your vehicle and the vehicle ahead is
extremely short
●When the lane markers are yellow (These may be more difficult for the system to
recognize compared to white markers.)
●When the lane markers are broken, “Raised pavement marker” or stones
●When lane markers are obscured or partially obscured by sand, dirt, etc.
●When there are shadows on the road running parallel with lane markers, or if a
shadow covers the lane markers
●When driving on a particularly bright road surface, such as concrete
●When driving on a road surface that is bright due to reflected light
●When driving in a location where the light level changes rapidly, such as the
entrance to or exit from a tunnel
●When sunlight or the headlights of oncoming vehicles are shining directly into the
camera lens
●When driving on roads that are branching or merging
GS350_250_OM_OM30E16E_(EE).book Page 311 Tuesday, July 8, 201 4 7:11 PM

4726-3. Do-it-yourself maintenance
GS350_250_OM_OM30E16E_(EE)
■Low profile tires (except 225/50R17 tires)
Generally, low profile tires will wear more rapidly and tire grip performance will be
reduced on snowy and/or icy roads when compared to standard tires. Be sure to use
snow tires or tire chains on snowy and/or icy roads and drive carefully at a speed
appropriate for road and weather conditions. (→P. 3 5 6 )
■If the tread on snow tires wears down below 4 mm (0.16 in.)
The effectiveness of the tires as snow tires is lost.
■Situations in which the tire pressure warning system may not operate properly
(vehicles with the tire pressure warning system)
●In the following cases, the tire pressure warning system may not operate properly.
• If non-genuine Lexus wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equipment) tire.
• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• Lock nuts are equipped.
• An auxiliary-supported run-flat tire is equipped.
• If a window tint that affects the radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the wheels or
wheel housings.
• If the tire inflation pressure is extremely higher than the specified level.
• If the spare tire is in a location subject to poor radio wave signal reception.
*
• If a large metallic object which can interfere with signal reception is put in the trunk.
*
*
: Vehicles with a full-size spare tire only
●Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio station, large display, airport or other facility that generates strong radio waves or electrical noise
• When carrying a portable radio, cellular phone, cordless phone or other wire- less communication device
Vehicles with the tire inflation pressure display function: If tire position information
is not correctly displayed due to the radio wave conditions, the display may be cor-
rected by driving and changing the radio wave conditions.
●When the vehicle is parked, the time taken for the warning to start or go off could
be extended.
●When tire inflation pressure declines rapidly for example when a tire has burst, the
warning may not function.
GS350_250_OM_OM30E16E_(EE).book Page 472 Tuesday, July 8, 201 4 7:11 PM

5367-2. Steps to take in an emergency
GS350_250_OM_OM30E16E_(EE)
If your vehicle needs to be towed
The following may indicate a problem with your transmission. Contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional or commercial towing service before towing.
●The engine is running but the vehicle will not move.
●The vehicle makes an abnormal sound.
If towing is necessary, we recommen d having your vehicle towed by any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional or commercial towing service, using a wheel-lift
type truck or flatbed truck.
Use a safety chain system for all to wing, and abide by all state/provin-
cial and local laws.
Situations need to contact dealers before towing
GS350_250_OM_OM30E16E_(EE).book Page 536 Tuesday, July 8, 201 4 7:11 PM

5427-2. Steps to take in an emergency
GS350_250_OM_OM30E16E_(EE)
If you think something is wrong
●Fluid leaks under the vehicle.
(Water dripping from the air conditioning after use is normal.)
●Flat-looking tires or uneven tire wear
●Engine coolant temperature gauge needle continually points higher
than normal.
●Changes in exhaust sound
●Excessive tire squeal when cornering
●Strange noises related to the suspension system
●Pinging or other noises related to the engine
●Engine missing, stumbling or running roughly
●Appreciable loss of power
●Vehicle pulls heavily to one side when braking
●Vehicle pulls heavily to one side when driving on a level road
●Loss of brake effectiveness, spongy feeling, pedal almost touches the
floor
If you notice any of the following symptoms, your vehicle probably
needs adjustment or repair. Contact any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional as soon as
possible.
Visible symptoms
Audible symptoms
Operational symptoms
GS350_250_OM_OM30E16E_(EE).book Page 542 Tuesday, July 8, 201 4 7:11 PM

6047-2. Steps to take in an emergency
GS350_250_OM_OM30E16E_(EE)
With the compressor switch off, disconnect the hose from the valve on
the tire and then pull out the power plug from the power outlet socket.
Some sealant may leak when the hose is removed.
Install the valve cap onto the valve of the emergency repaired tire.
Attach the air release cap to the
end of the hose.
If the air release cap is not attached,
the sealant may leak and the vehicle
may get dirty.
Temporarily store the bottle in the trunk while it is connected to the
compressor.
To spread the liquid sealant evenly within the tire, immediately drive
safely for about 5 km (3 miles) below 80 km/h (50 mph).
After driving for about 5 km
(3 miles), stop your vehicle in a
safe place on a hard, flat surface
and remove the air release cap
from the hose before reconnect-
ing the repair kit.
13
14
15
16
17
18
GS350_250_OM_OM30E16E_(EE).book Page 604 Tuesday, July 8, 2014 7:11 PM

685Alphabetical index
GS350_250_OM_OM30E16E_(EE)
Tire pressure warning reset switch....................................................469
Trunk closer switch .............................176
Trunk opener switch ..........................175
Trunk opener main switch .............. 176
Vehicle-to-vehicle distance button ................................................... 292
VSC OFF switch ............................... 322
Window lock switch.........................204
Windshield wipers
and washer switch ..........................272
Tachometer........................................99, 112
Tail lights ...................................................259 Light switch ........................................... 259
Replacing light bulbs....................... 530
Welcome light illumination
control.................................................... 127
Talk switch
*
Telephone switches*
Theft deterrent system
Alarm ..........................................................86
Double locking system ......................85
Engine immobilizer system..............80
Intrusion sensor and tilt sensor ......89
Tire inflation pressure .........................483 Maintenance data..............................645
Tire inflation pressure display function ................................................. 105
Warning light ...................................... 548
Warning message................ 567, 568 Tire pressure warning system ......... 468
Function.................................................. 468
Initializing ............................................... 469
Installing tire pressure warning
valves and transmitters ............... 468
Registering ID codes....................... 470
Tire pressure warning reset switch ................................................... 469
Warning light....................................... 548
Warning message ............... 567, 568
Tires............................................................ 466 Chains ..................................................... 356
Checking ............................................... 466
Emergency tire puncture
repair kit.............................................. 592
If you have a flat tire.............. 577, 592
Inflation pressure ............................... 645
Replacing................................................577
Rotating tires ........................................ 467
Size ........................................................... 645
Snow tires..............................................358
Spare tire ................................................577
Tire inflation pressure display function .................................................105
Tire pressure warning system..... 468
Warning light....................................... 548
Warning message ............................ 567
Tools............................................... 578, 593
Top strap ......................................................75
T
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
sec_10-02.fm Page 685 Friday, July 11, 2014 7:03 PM

688
GS350_250_OM_OM30E16E_(EE)GAS STATION INFORMATION
Auxiliary catch leverTrunk openerFuel filler door
P. 4 5 0 P. 1 7 5 P. 2 8 2
Hood lock release leverTire inflation pressure
P. 4 5 0
P. 6 4 5
Fuel tank capacity
(Reference) 66 L (17.4 gal., 14.5 Imp.gal.)
Fuel typeEU area: Unleaded gasoline conforming to European
standard EN228 only
Except EU area: Unleaded gasoline only
P. 280, 634
Cold tire inflation
pressure P. 6 4 5
Engine oil capacity
(Drain and refill —
reference)L (qt., Imp.qt.)
GS250 GS350
With filter 6.2 (6.6, 5.5) 6.4 (6.8, 5.6)
Without filter 5.9 (6.2, 5.2) 6.0 (6.3, 5.3)
Engine oil type “Toyota Genuine Motor Oil” or equivalent
P. 6 3 5
GS350_250_OM_OM30E16E_(EE).book Page 688 Tuesday, July 8, 201 4 7:11 PM
