2014 JEEP GRAND CHEROKEE park assist

▫Headlights On Automatically With Wipers . . .173
▫ Automatic High Beam — If Equipped ......173
▫ Daytime Running Lights — If Equipped .....175
▫ Automatic Headlight Leveling —
HID Headlights Only ...................175
▫ Adaptive Bi-Xenon High Intensity Discharge
Headlights — If Equipped ...............175
▫ Headlight Delay ..................... .176
▫ Parking Lights And Panel Lights ...........176
▫ Fog Lights — If Equipped ...............176
▫ Interior Lights ....................... .177
▫ Lights-On Reminder ...................178
▫ Battery Saver ........................ .178
▫ Front Map/Reading Lights ..............179▫
Courtesy Lights ...................... .180
▫ Ambient Light ....................... .180
▫ Multifunction Lever ....................181
▫ Turn Signals ........................ .181
▫ Lane Change Assist ...................181
▫ Flash-To-Pass ....................... .182
▫ High/Low Beam Switch .................182
 WINDSHIELD WIPERS AND WASHERS ......182
▫ Windshield Wiper Operation .............183
▫ Intermittent Wiper System ...............183
▫ Windshield Washer Operation .............184
▫ Mist .............................. .185
▫ Rain Sensing Wipers — If Equipped ........186
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119

▫Overtake Aid ....................... .210
▫ ACC Operation at Stop .................210
▫ Adaptive Cruise Control (ACC) Menu .......211
▫ Display Warnings And Maintenance ........212
▫ Precautions While Driving With ACC .......215
▫ General Information ...................219
▫ Normal (Fixed Speed) Cruise Control Mode . . .219
 FORWARD COLLISION WARNING (FCW)
WITH MITIGATION — IF EQUIPPED .......223
▫ Forward Collision Warning (FCW) With
Mitigation Operation ...................223
▫ Turning FCW ON Or OFF ...............225
▫ Changing FCW And Active Braking Status. . . .226
▫ FCW Limited Warning ..................227 ▫
Service FCW Warning ..................228
 PARKSENSE® REAR PARK ASSIST —
IF EQUIPPED ........................ .228
▫ ParkSense® Sensors ....................228
▫ ParkSense® Warning Display .............229
▫ ParkSense® Display ....................229
▫ Enabling And Disabling ParkSense® ........233
▫ Service The ParkSense® Rear Park Assist
System ............................ .233
▫ Cleaning The ParkSense® System ..........234
▫ ParkSense® System Usage Precautions .......234
 PARKSENSE® FRONT AND REAR PARK
ASSIST — IF EQUIPPED .................237
▫ ParkSense® Sensors ....................237
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121

▫ParkSense® Warning Display .............238
▫ ParkSense® Display ....................238
▫ Enabling And Disabling ParkSense® ........242
▫ Service The ParkSense® Park Assist System . . .243
▫ Cleaning The ParkSense® System ..........244
▫ ParkSense® System Usage Precautions .......244
 PARKVIEW® REAR BACK UP CAMERA —
IF EQUIPPED ........................ .247
▫ Turning ParkView® On Or Off —
With Uconnect® 5.0 ....................249
▫ Turning ParkView® On Or Off —
With Uconnect® 8.4A/8.4AN .............249
 OVERHEAD CONSOLE ..................250
▫ Front Map/Reading Lights ..............250▫
Courtesy Lights ...................... .251
▫ Sunglasses Bin Door ...................252
 GARAGE DOOR OPENER — IF EQUIPPED . . .252
▫ Before You Begin Programming HomeLink® . .254
▫ Programming A Rolling Code .............254
▫ Programming A Non-Rolling Code .........257
▫ Canadian/Gate Operator Programming ......258
▫ Using HomeLink® ....................259
▫ Security ........................... .259
▫ Troubleshooting Tips ...................260
▫ General Information ....................261
 POWER SUNROOF — IF EQUIPPED ........262
▫ Opening Sunroof — Express ..............263
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Service FCW Warning
If the system turns off, and the EVIC displays:
•ACC/FCW Unavailable Service Required
• Cruise/FCW Unavailable Service Required
This indicates there is an internal system fault. Although
the vehicle is still drivable under normal conditions, have
the system checked by an authorized dealer.
PARKSENSE® REAR PARK ASSIST —
IF EQUIPPED
The ParkSense® Rear Park Assist system provides visual
and audible indications of the distance between the rear
fascia and a detected obstacle when backing up, e.g.
during a parking maneuver. Refer to ParkSense® System
Usage Precautions for limitations of this system and
recommendations. ParkSense® will retain the last system state (enabled or
disabled) from the last ignition cycle when the ignition is
changed to the ON/RUN position.
ParkSense® can be active only when the shift lever is in
REVERSE. If ParkSense® is enabled at this shift lever
position, the system will remain active until the vehicle
speed is increased to approximately 7 mph (11 km/h) or
above. When in REVERSE and above the system’s oper-
ating speed, a warning will appear in the EVIC indicating
the vehicle speed is too fast. The system will become
active again if the vehicle speed is decreased to speeds
less than approximately 6 mph (9 km/h).
ParkSense® Sensors
The four ParkSense® sensors, located in the rear fascia/
bumper, monitor the area behind the vehicle that is
within the sensors’ field of view. The sensors can detect
obstacles from approximately 12 in (30 cm) up to 79 in
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

(200 cm) from the rear fascia/bumper in the horizontal
direction, depending on the location, type and orienta-
tion of the obstacle.
ParkSense® Warning Display
The ParkSense® Warning screen will only be displayed if
Sound and Display is selected from the Customer -
Programmable Features section of the Uconnect® Sys-
tem. Refer toUconnect® Settings” in “Understanding
Your Instrument Panel” for further information.
The ParkSense® Warning screen is located within the
Electronic Vehicle Information Center (EVIC). It provides
visual warnings to indicate the distance between the rear
fascia/bumper and the detected obstacle. Refer to “Elec-
tronic Vehicle Information Center (EVIC)/Settings” in
“Understanding Your Instrument Panel” for further in-
formation.
ParkSense® Display
When the vehicle is in REVERSE, the EVIC will display
the park assist ready system status.
The system will indicate a detected obstacle by showing
a single arc in the left and/or right rear regions based on
the obstacle’s distance and location relative to the vehicle.
Park Assist Ready
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229

Enabling And Disabling ParkSense®
ParkSense® can be enabled and disabled with the
ParkSense® switch.
When the ParkSense® switch is pressed to dis-
able the system, the instrument cluster will
display the “PARKSENSE OFF” message for
approximately five seconds. Refer to “Electronic
Vehicle Information Center (EVIC)” in “Understanding
Your Instrument Panel” for further information. When the
shift lever is moved to REVERSE and the system is
disabled, the EVIC will display the “PARKSENSE OFF”
message for as long as the vehicle is in REVERSE.
The ParkSense® switch LED will be ON when ParkSense®
is disabled or requires service. The ParkSense® switch LED
will be OFF when the system is enabled. If the ParkSense®
switch is pressed, and the system requires service, the
ParkSense® switch LED will blink momentarily, and then
the LED will be ON.
Service The ParkSense® Rear Park Assist
System
During vehicle start up, when the ParkSense® Rear Park
Assist System has detected a faulted condition, the
instrument cluster will actuate a single chime, once
per ignition cycle, and it will display the “PARKSENSE
UNAVAILABLE WIPE REAR SENSORS” or the
“PARKSENSE UNAVAILABLE SERVICE REQUIRED”
message. Refer to “Electronic Vehicle Information Center
(EVIC)” in “Understanding Your Instrument Panel” for
further information. When the shift lever is moved to
REVERSE and the system has detected a faulted condi-
tion, the EVIC will display the PARKSENSE UNAVAIL-
ABLE WIPE REAR SENSORS orPARKSENSE UN-
AVAILABLE SERVICE REQUIRED message for as long
as the vehicle is in REVERSE. Under this condition,
ParkSense® will not operate.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233

PARKSENSE® FRONT AND REAR PARK
ASSIST — IF EQUIPPED
The ParkSense® Park Assist system provides visual and
audible indications of the distance between the rear
and/or front fascia and a detected obstacle when backing
up or moving forward, e.g. during a parking maneuver.
Refer to ParkSense® System Usage Precautions for limi-
tations of this system and recommendations.
ParkSense® will retain the last system state (enabled or
disabled) from the last ignition cycle when the ignition is
changed to the ON/RUN position.
ParkSense® can be active only when the shift lever is in
REVERSE or DRIVE. If ParkSense® is enabled at one of
these shift lever positions, the system will remain active
until the vehicle speed is increased to approximately
7 mph (11 km/h) or above. A display warning will
appear in the EVIC indicating the vehicle is above
ParkSense® operating speed. The system will becomeactive again if the vehicle speed is decreased to speeds
less than approximately 6 mph (9 km/h).ParkSense® Sensors
The four ParkSense® sensors, located in the rear fascia/
bumper, monitor the area behind the vehicle that is
within the sensors’ field of view. The sensors can detect
obstacles from approximately 12 in (30 cm) up to 79 in
(200 cm) from the rear fascia/bumper in the horizontal
direction, depending on the location, type and orienta-
tion of the obstacle.
The six ParkSense® sensors, located in the front fascia/
bumper, monitor the area in front of the vehicle that is
within the sensors’ field of view. The sensors can detect
obstacles from approximately 12 in (30 cm) up to 47 in
(120 cm) from the front fascia/bumper in the horizontal
direction, depending on the location, type and orienta-
tion of the obstacle.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237

ParkSense® Warning Display
The ParkSense® Warning screen will only be displayed if
Sound and Display is selected from the Customer -
Programmable Features section of the Uconnect® Sys-
tem. Refer toUconnect® Settings” in “Understanding
Your Instrument Panel” for further information.
The ParkSense® Warning screen is located within the
Electronic Vehicle Information Center (EVIC). It provides
visual warnings to indicate the distance between the rear
fascia/bumper and/or front fascia/bumper and the de-
tected obstacle. Refer to “Electronic Vehicle Information
Center (EVIC)/Settings” in Understanding Your Instru-
ment Panel” for further information.
ParkSense® Display
The warning display will turn ON indicating the system
status when the vehicle is in REVERSE or when the
vehicle is in DRIVE and an obstacle has been detected. The system will indicate a detected obstacle by showing
a single arc in the left and/or right rear regions based on
the object’s distance and location relative to the vehicle.
Park Assist Ready
