CAUTION!(Continued)
the vehicle’s battery will discharge sufficiently to
degrade battery life and/or prevent the engine from
starting.
FREEING A STUCK VEHICLE
If your vehicle becomes stuck in mud, sand or snow, it can
often be moved using a rocking motion. Turn the steering
wheel right and left to clear the area around the front
wheels. For vehicles with automatic transmission, press
and hold the lock button on the shift lever. Then shift back
and forth between DRIVE and REVERSE (with automatic
transmission) or 2nd gear and REVERSE (with manual
transmission), while gently pressing the accelerator.
NOTE:For vehicles with automatic transmission: shifts
between DRIVE and REVERSE can only be achieved at
wheel speeds of 5 mph (8 km/h) or less. Whenever the
transmission remains in NEUTRAL for more than two
seconds, you must press the brake pedal to engage
DRIVE or REVERSE.
Use the least amount of accelerator pedal pressure that
will maintain the rocking motion without spinning the
wheels or racing the engine.
NOTE: Press the “ESC Off” switch (if necessary), to place
the Electronic Stability Control (ESC) system in “Partial
Off” mode, before rocking the vehicle. Refer to “Elec-
tronic Brake Control” in “Starting And Operating” for
further information. Once the vehicle has been freed,
press the ESC Off switch again to restore “ESC On”
mode.
582 WHAT TO DO IN EMERGENCIES

CAUTION!
•Racing the engine or spinning the wheels may lead
to transmission overheating and failure. Allow the
engine to idle with the transmission in NEUTRAL
for at least one minute after every five rocking-
motion cycles. This will minimize overheating and
reduce the risk of clutch or transmission failure
during prolonged efforts to free a stuck vehicle.
• When “rocking” a stuck vehicle by shifting be-
tween DRIVE/2nd gear and REVERSE, do not spin
the wheels faster than 15 mph (24 km/h), or drive-
train damage may result.
• Revving the engine or spinning the wheels too fast
may lead to transmission overheating and failure.
It can also damage the tires. Do not spin the wheels
above 30 mph (48 km/h) while in gear (no trans-
mission shifting occurring).
WARNING!
Fast spinning tires can be dangerous. Forces gener-
ated by excessive wheel speeds may cause damage, or
even failure, of the axle and tires. A tire could
explode and injure someone. Do not spin your vehi-
cle’s wheels faster than 30 mph (48 km/h) or for
longer than 30 seconds continuously without stop-
ping when you are stuck and do not let anyone near
a spinning wheel, no matter what the speed.
RECOVERY STRAP — IF EQUIPPED
Your vehicle may be included with a recovery strap.
Recovery straps do not act like traditional tow straps,
chains, or winch cables.
6
WHAT TO DO IN EMERGENCIES 583

SHIFT LEVER OVERRIDE
If a malfunction occurs and the shift lever cannot be
moved out of the PARK position, you can use the
following procedure to temporarily move the shift lever:
1. Turn the engine OFF.
2. Apply the parking brake.
3. Using a screwdriver or similar tool, carefully separatethe shifter bezel and boot assembly from the center
console bezel.
4. Press and maintain firm pressure on the brake pedal.
5. Insert a small screwdriver or similar tool down into the shift lever override access hole (at the right front
corner of the shift lever assembly), and push and hold
the override release lever down. 6. Move the shift lever to the NEUTRAL position.
7. The vehicle may then be started in NEUTRAL.
8. Reinstall the shift lever boot.
TOWING A DISABLED VEHICLE
This section describes procedures for towing a disabled
vehicle using a commercial towing service. If the trans-
mission and drivetrain are operable, disabled 4x4 ve-
hicles may also be towed as described under “Recre-
ational Towing” in the “Starting And Operating” section.
6
WHAT TO DO IN EMERGENCIES 585

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 2.4L ..........593
 ENGINE COMPARTMENT — 3.2L ..........594

ONBOARD DIAGNOSTIC SYSTEM — OBD II . . .595
▫ Loose Fuel Filler Cap Message ............596
 EMISSIONS INSPECTION AND
MAINTENANCE PROGRAMS .............596
 REPLACEMENT PARTS ..................598
 DEALER SERVICE ..................... .598
 MAINTENANCE PROCEDURES ...........598
▫ Engine Oil ......................... .600▫
Engine Oil Filter ..................... .603
▫ Engine Air Cleaner Filter ................603
▫ Maintenance-Free Battery ...............604
▫ Air Conditioner Maintenance .............605
▫ A/C Air Filter — If Equipped ............607
▫ Body Lubrication .....................607
▫ Windshield Wiper Blades ...............607
▫ Adding Washer Fluid ..................609
▫ Exhaust System ..................... .610
▫ Cooling System ..................... .612
7

▫Brake System ....................... .619
▫ Automatic Transmission ................621
▫ Appearance Care And Protection From
Corrosion .......................... .623
 FUSES ............................. .629
▫ Power Distribution Center ...............630
▫ Interior Fuses ....................... .640
 VEHICLE STORAGE ....................642
 REPLACEMENT BULBS .................642
 BULB REPLACEMENT ..................643
▫ Low Beam And High Beam Headlamps .....643▫
Front Turn Signals ....................645
▫ Front Fog Lamp ..................... .645
▫ Front Fog Lamp (Trailhawk) .............646
▫ Rear Turn Signal Lamp .................646
▫ Back-up Lamp ...................... .647
▫ License Plate Lamp ....................647
 FLUID CAPACITIES ....................648
 FLUIDS, LUBRICANTS AND GENUINE
PARTS ............................. .649
▫ Engine ............................ .649
▫ Chassis ........................... .650
592 MAINTAINING YOUR VEHICLE

ENGINE COMPARTMENT — 2.4L
1 — Air Cleaner Filter5 — Power Distribution Center (Fuses)
2 — Engine Coolant Pressure Cap 6 — Battery
3 — Oil Fill Cap 7 — Washer Fluid Reservoir
4 — Brake Fluid Reservoir 8 — Engine Oil Dipstick
7
MAINTAINING YOUR VEHICLE 593

ENGINE COMPARTMENT — 3.2L
1 — Engine Coolant Reservoir5 — Washer Fluid Reservoir
2 — Engine Oil Filter Access Cover 6 — Engine Oil Dipstick
3 — Brake Fluid Reservoir 7 — Engine Oil Fill
4 — Power Distribution Center (Fuses) 8 — Air Cleaner Filter
594 MAINTAINING YOUR VEHICLE

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light (MIL).” It
will also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your authorized dealer for service as
soon as possible.
CAUTION!
•Prolonged driving with the MIL on could cause
further damage to the emission control system. It
could also affect fuel economy and driveability.
The vehicle must be serviced before any emissions
tests can be performed.
• If the MIL is flashing while the engine is running,
severe catalytic converter damage and power loss
will soon occur. Immediate service is required.
7
MAINTAINING YOUR VEHICLE 595
