If you have a flat tire, see “Flat tire” in the
“In case of emergency” section of this
manual.
TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS)
This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS) . It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit and the “Tire Pressure
Low – Add Air” warning appears in the
vehicle information display, one or more of
your tires is significantly under-inflated. If
equipped, the system also displays pres-
sure of all tires (except the spare tire) on
the display screen by sending a signal
from a sensor that is installed in each
wheel.
The TPMS will activate only when the
vehicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not de-
tect a sudden drop in tire pressure (for
example a flat tire while driving) .For more details, refer to “Low tire pres-
sure warning light” in the “Instruments and
controls” section and “Flat tire” in the “In
case of emergency” section.
Tire inflation pressure
Check the tire pressures (including the
spare) often and always prior to long dis-
tance trips. The recommended tire pres-
sure specifications are shown on the
F.M.V.S.S./C.M.V.S.S. certification label
or the Tire and Loading Information label
under the “Cold Tire Pressure” heading.
The Tire and Loading Information label is
affixed to the driver side center pillar. Tire
pressures should be checked regularly
because:
●Most tires naturally lose air over time.
●Tires can lose air suddenly when
driven over potholes or other objects
or if the vehicle strikes a curb while
parking.The tire pressures should be checked
when the tires are cold. The tires are
considered COLD after the vehicle has
been parked for 3 or more hours, or driven
less than 1 mile (1.6 km) at moderate
speeds.
The TPMS with Tire Inflation Indicator
provides visual and audible signals out-
side the vehicle for inflating the tires to the
recommended COLD tire pressure. For
more information, see “TPMS with Tire
Inflation Indicator” in the “Starting and
driving” section.
Incorrect tire pressure, including un-
der inflation, may adversely affect
tire life and vehicle handling.
WHEELS AND TIRES
8-30Maintenance and do-it-yourself

Use the following steps to mount the front license
plate:
Before mounting the license plate, confirm that
the following parts are enclosed in the plastic
bag:
Only use the recommended mounting position,
otherwise the Intelligent Cruise Control (ICC)
sensor obstruction (if so equipped) may result.
●License plate bracket
●License plate bracket (J-nut) screws x 2
●License plate screws x 2
●Screw grommets x 2
1. Park the vehicle on flat, level ground.
2. Locate the center position
Aas illustrated.
Line up the license plate bracket under the
top of the front bumper
Bwith the tabsC.
Hold the license plate bracket in place.
3. Mark the center of the hole
Dwith a felt-tip
pen.
4. Carefully drill two pilot holes using a 0.39 in
(10 mm) drill bit at the marked locations.(Be
sure that the drill only goes through the
bumper fascia.)
LTI2035
INSTALLING FRONT LICENSE PLATE
9-12Technical and consumer information

Precautions on supplemental restraint
system ....................1-53
Precautions when starting and driving....5-4
Pre-tensioner seat belt system.........1-67
Push starting...................6-12
R
Radio
Car phone or CB radio...........4-109
FM/AM/SAT radio with compact disc
(CD) player..................4-70
Steering wheel audio control switch....4-94
Rainsensor....................2-28
Readiness for inspection maintenance
(I/M) test.....................9-31
Rear power windows..............2-51
RearViewMonitor................4-24
Rear window and outside mirror defroster
switch.......................2-30
Rear window wiper and washer switches . . .2-29
Recorders
Eventdata..................9-31
Refrigerant recommendation...........9-6
Registering your vehicle in another country . . .9-9
Reporting safety defects (US only).......9-30
Roof rack.....................2-49
S
Safety
Child safety rear door lock..........3-7
Childseatbelts.....1-32,1-40,1-44,1-49
Reporting safety defects (US only).....9-30Seat adjustment
Front power seat adjustment.........1-3
Second row bench seats........1-5,1-7
Seatback pockets................2-44
Seat belt
Child safety..................1-31
Infants and small children..........1-31
Injured Person................1-26
Largerchildren................1-32
Precautions on seat belt usage.......1-23
Pregnant women...............1-26
Pre-tensioner seat belt system.......1-67
Seatbeltextenders .............1-30
Seatbeltmaintenance............1-30
Seatbelts...................1-23
Three-point type with retractor.......1-26
Seat belt warning light..............2-11
Seats
Adjustment...................1-2
Automatic drive positioner..........3-31
Frontseats...................1-2
Heatedseats..........2-35,2-36,2-38
Security indicator light..............2-13
Security system
(INFINITI vehicle immobilizer system) ,
engine start...........2-25,3-4,5-15
Self-adjusting brakes..............8-20
Service manual order form...........9-32
Servicing air conditioner.............4-53
Sparkplugreplacement.............8-17
Speedometer...................2-4
SRSwarninglabel................1-68
Starting
Before starting the engine..........5-16
Jump starting.................6-10
Precautions when starting and driving....5-4Push starting.................6-12
Starting the engine.............5-16
Steering
Heated steering wheel...........2-39
Power steering fluid.............8-12
Power steering system...........5-94
Steering wheel audio control switch......4-94
Stoplight.....................8-26
Storage......................2-43
Storagebin....................2-48
Sunglasses case.................2-44
Sunglasses holder................2-44
Sunroof (see Moonroof).............2-52
Sun visors....................3-28
Supplemental air bag warning labels......1-68
Supplemental air bag warning light . . .1-69, 2-11
Supplemental front impact air bag system . . .1-61
Supplemental restraint system
Information and warning labels.......1-68
Precautions on supplemental restraint
system....................1-53
Supplemental restraint system
(Supplemental air bag system).........1-53
Switch
Autolight switch...............2-31
Automatic power window switch......2-51
Fog light switch...............2-34
Hazard warning flasher switch........6-2
Headlightaimingcontrol ..........2-33
Headlightandturnsignalswitch......2-30
Headlight control switch..........2-31
Power door lock switch............3-6
Power inverter switch............2-41
Rear window and outside mirror defroster
switch.....................2-30
10-5
