first drive features
Automatic Climate Controls
01 AUt O BU tt ON
The automatic mode may be used year-round. Press the AU t O button to turn the system
on. The system will automatically control the inside temperature (autom\
atic cooling and/
or dehumidified heating), air flow distribution and fan speed.
02 CLIMA t E BU tt ON
Press the
CLIMA t E button to adjust your automatic climate controls using the climate
settings on the control panel display screen.
03 DRIVER’S SIDE t EMPERA t URE CON t ROL BU tt ONS
Press the driver’s side temperature control buttons up for warmer air or down for
cooler air.
04 DRIVER’S SIDE MANUAL AIR FLOW CON t ROL BU tt ON
Press the driver’s side manual air flow button to manually control th\
e driver’s side air
flow modes.
The following air flow indicator modes will display on the control panel\
display screen:
Air flows from the center and side vents.
Air flows from the center, side and foot vents.
Air flows mainly from the foot vents.
Air flows from the defroster and foot vents.
05 PASSENGER’S SIDE t EMPERA t URE CON t ROL BU tt ONS
To manually adjust the passenger’s side temperature, press the passen\
ger’s side
temperature control buttons up
for warmer air or down for cooler air.
06 PASSENGER’S SIDE MANUAL AIR FLOW CON t ROL BU tt ON
Press the passenger’s side manual air flow button to manually control\
the passenger’s
side air flow modes.
The following air flow indicator modes will display on the control panel\
display screen:
Air flows from the center and side vents.
Air flows from the center, side and foot vents.
Air flows mainly from the foot vents.
Air flows from the defroster and foot vents.
0406
0809120701101102
0305
1276459_14_M_Hybrid_QRG_112213.indd 1611/22/13 9:39 AM
27
HomeLink® Universal Transceiver
The HomeLink system can learn
and consolidate the functions of
up to 3 different hand-held
transmitters, operating items
such as garage doors, property
gates, outdoor and indoor lights
or alarm systems.
To program the HomeLink® Universal Transceiver:
•
Position
the
handheld
transceiver 1-3 in (26-76 mm) away from the HomeLink surface,
keeping the HomeLink indicator light in view.
•
Press
and
hold
the
desired HomeLink button and the handheld transmitter button
simultaneously until the HomeLink indicator light flashes slowly and the\
n rapidly.
•
Both
buttons
may
be
released when the indicator light flashes rapidly.
To verify the programming is complete, press and hold the HomeLink button and observe
the indicator light:
•
A
solid, continuous light indicates the programming is complete, and the HomeLink
button will activate your device.
•
A
blinking light that turns to a solid continuous light after 2 seconds indicates
additional steps are required to complete the programming.
An additional person may make the remaining steps easier. To complete the programming process:
•
At
the receiver of the device that you are programming to the HomeLink button, press
and release the learn or smart button (the name may vary by manufacture\
r but it is
usually located near where the hanging antenna wire is attached to the u\
nit). You have
approximately 30 seconds to initiate the following step.
•
Press
and hold the programmed HomeLink button for 2 seconds and release.
You may have to repeat the previous 2 steps up to 3 times to complete th\
e programming
process. HomeLink should now activate your device.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website at
www.homelink.com or call 1-800-355-3515.
HOMeLINk
system guide
