2014 INFINITI Q60 COUPE keyless

SSI0806
1. Hood (P.3-17)
2. Headlight and turn signal—Operation (P.2-34)
— Bulb replacement (P.8-27)
3. Windshield wiper and washer —Operation (P.2-31) —
Maintenance (P.8-21)
4. Moonroof (if so equipped) (P.2-52)
5. Power windows (P.2-50)
6. Recovery hook (P.6-14)
7. Fog light (P.2-39)
8. Tires —
Wheel and tires (P.8-30, P.9-9)
— Flat tire (P.6-3)
— Tire pressure monitoring system
(TPMS) (P.2-15, P.5-4)
9. Outside mirrors (P.3-26)
10. Doors —Keys (P.3-2)
— Door locks (P.3-4)
— Intelligent Key system (P.3-6)
— Remote keyless entry system
(P.3-14)
Illustrated table of contents0-3
EXTERIOR FRONT

0-4Illustrated table of contents
SSI0685
1. High-mounted stop light (model witha rear spoiler) (Bulb replacement)
(P.8-27)
2. High-mounted stop light (model with- out a rear spoiler) (Bulb replacement)
(P.8-27) 3. Rear window defroster (P.2-34)
4. Satellite antenna (P.4-40)
5. Rear view camera (if so equipped)
(P.4-23)
6. Trunk —Intelligent Key system (P.3-6) —
Remote keyless entry system
(P.3-14)
— Trunk lid (P.3-18)
7. Sonar system (if so equipped) (P.5-51)
8. Rear combination light (Bulb replace- ment) (P.8-27)
9. Fuel-filler door —Operation (P.3-21)
— Fuel recommendation (P.9-4)
EXTERIOR REAR

3 Pre-driving checks and adjustments
Keys.................................................................... 3-2
Intelligent Key ................................................. 3-2
Valet hand-off.................................................. 3-3
Doors .................................................................. 3-4 Locking with mechanical key ........................... 3-4
Opening and closing windows with the
mechanical key................................................ 3-4
Locking with inside lock knob ......................... 3-5
Locking with power door lock switch ............... 3-5
Automatic door locks....................................... 3-5
Intelligent Key system ......................................... 3-6 Intelligent Key operating range ....................... 3-8
Door locks/unlocks precaution ....................... 3-8
Intelligent Key operation ................................. 3-9
Battery saver system ..................................... 3-11
Warning signals............................................. 3-12
Troubleshooting guide ................................... 3-13
Remote keyless entry system............................. 3-14 How to use remote keyless entry system....... 3-14
Hood ................................................................. 3-17 Trunk lid ........................................................... 3-18
Trunk lid release switch ............................... 3-18
Trunk open request switch ........................... 3-18
Trunk release power cancel switch ............... 3-19
Interior trunk lid release .............................. 3-19
Unique front and rear parts (INFINITI Performance
Line model) ....................................................... 3-20
Fuel-filler door................................................... 3-21 Opening the fuel-filler door.......................... 3-21
Fuel-filler cap............................................... 3-21
Tilt/telescopic steering ...................................... 3-23 Manual operation (if so equipped) ............... 3-24
Electric operation (if so equipped) ............... 3-24
Sun visors......................................................... 3-24
Mirrors ............................................................. 3-25 Inside mirror................................................ 3-25
Outside mirrors............................................ 3-26
Vanity mirror................................................ 3-27
Automatic drive positioner (if so equipped) ....... 3-28 Seat synchronization function ..................... 3-28
Memory storage........................................... 3-29
System operation......................................... 3-30

3-4Pre-driving checks and adjustments
WARNING
.Always have the doors locked while
driving. Along with the use of seat belts,
this provides greater safety in the event
of an accident by helping to prevent
persons from being thrown from the
vehicle. This also helps keep children
and others from unintentionally opening
the doors, and will help keep out
intruders.
. Before opening any door, always look for
and avoid oncoming traffic.
. Do not leave children unattended inside
the vehicle. They could unknowingly
activate switches or controls. Unat-
tended children could become involved
in serious accidents.
SPA2527
LOCKING WITH MECHANICAL KEY
The power door lock system allows you to
lock or unlock all doors simultaneously
using the mechanical key.
.Turning the driver’s door key cylinder to
the front of the vehicle
*1will lock all
doors.
. Turning the driver’s door key cylinder
once to the rear of the vehicle
*2will
unlock the driver’s door. After returning
the key to the neutral position
*3,
turning it to the rear again within 60
seconds will unlock all doors. .
You can switch the lock system to the
mode that allows you to open all the
doors when the key is turned once.
(See “How to use SETTING button” (P.4-
14).)
OPENING AND CLOSING WINDOWS
WITH THE MECHANICAL KEY
The driver’s door key operation also allows
you to open and close the window that is
equipped with the automatic open/close
function. (See “Power windows” (P.2-50).)
To open the window, turn the driver’s door
key cylinder to the rear of the vehicle for
longer than 1 second. The door is unlocked
and the window keeps opening while
turning the key.
This function can also be performed by
pushing and holding the door UNLOCK
button of the Intelligent Key. (See “Remote
keyless entry system” (P.3-14).)
To close the window, turn the driver’s door
key cylinder to the front of the vehicle for
longer than 1 second. The door is locked
and the window keeps closing while turn-
ing the key.
DOORS

3-14Pre-driving checks and adjustments
WARNING
The Intelligent Key transmits radio waves
when the buttons are pushed. The FAA
advises that the radio waves may affect
aircraft navigation and communication sys-
tems. Do not operate the Intelligent Key
while on an airplane. Make sure the buttons
are not operated unintentionally when the
unit is stored during a flight.
It is possible to lock/unlock all doors, fuel-
filler door, activate the panic alarm and
open the windows by pushing the buttons
on the Intelligent Key from outside the
vehicle.
Before locking the doors, make sure the
Intelligent Key is not left in the vehicle.
The LOCK/UNLOCK button on the Intelli-
gent Key can operate at a distance of
approximately 33 ft (10 m) from the
vehicle. (The effective distance depends
upon the conditions around the vehicle.)
As many as 4 Intelligent Keys can be used
with one vehicle. For information concern-
ing the purchase and use of additional
Intelligent Keys, contact an INFINITI retai-
ler.The lock and unlock buttons on the
Intelligent Key will not operate when:
.
the distance between the Intelligent Key
and the vehicle is over 33 ft (10 m).
. the Intelligent Key battery is dis-
charged.
After locking with the remote keyless entry
function, pull the door handle to make sure
the doors are securely locked.
The LOCK/UNLOCK operating range varies
depending on the environment. To securely
operate the lock and unlock buttons,
approach the vehicle to about 3 ft (1 m)
from the door.SPA2100
1. LOCK button
2. UNLOCK button
3. TRUNK button
4. PANIC button
HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM
When you lock or unlock the doors or the
trunk lid, the hazard indicator will flash
and the horn (or the outside chime) will
sound as a confirmation. For details, see
“Setting hazard indicator and horn mode”
(P.3-16).
REMOTE KEYLESS ENTRY SYSTEM

3-16Pre-driving checks and adjustments
.Any of the buttons on the IntelligentKey are pushed. (Note: Panic button
should be pushed for more than 1
second.)
Setting hazard indicator and horn
mode
This vehicle is set in hazard indicator and
horn mode when you first receive the
vehicle.
In hazard indicator and horn mode, when
the LOCK
button*1is pushed, the
hazard indicator flashes twice and the horn
chirps once. When the UNLOCK
button
*2is pushed, the hazard indicator flashes
once.
If horns are not necessary, the system can
be switched to the hazard indicator mode.
In hazard indicator mode, when the LOCK
button is pushed, the hazard indicator
flashes twice. When the UNLOCK
button is pushed, neither the hazard
indicator nor the horn operates. Hazard indicator and horn mode:
DOOR LOCK
DOOR UNLOCK TRUNK UNLOCK
Intelligent Key system
(Using door handle or trunk request switch) HAZARD -
twice
OUTSIDE CHIME - twiceHAZARD -
once
OUTSIDE CHIME - onceHAZARD - none
OUTSIDE CHIME -
4
times
Remote keyless entry system
(Using
,orbutton) HAZARD -
twice
HORN - once HAZARD -
once
HORN - none HAZARD - none
HORN - none
Hazard indicator mode:
DOOR LOCK
DOOR UNLOCK TRUNK UNLOCK
Intelligent Key system
(Using door handle or trunk request switch) HAZARD -
twice
OUTSIDE CHIME - none HAZARD - none
OUTSIDE CHIME - noneHAZARD - none
OUTSIDE CHIME - none
Remote keyless entry system
(Using
,orbutton) HAZARD -
twice
HORN - none HAZARD - none
HORN - noneHAZARD - none
HORN - none

3-18Pre-driving checks and adjustments
WARNING
.Do not drive with the trunk lid open. This
could allow dangerous exhaust gases to
be drawn into the vehicle. See “Exhaust
gas (carbon monoxide)” (P.5-3) of this
manual.
. Closely supervise children when they are
around cars to prevent them from play-
ing and becoming locked in the trunk
where they could be seriously injured.
Keep the car locked, with the trunk
closed, when not in use, and prevent
children’s access to Intelligent Keys.
SPA2307
TRUNK LID RELEASE SWITCH
The trunk lid release switch*Ais located
on the instrument panel.
To open the trunk lid, push the release
switch down as illustrated. To close, push
the trunk lid down.
You can open the trunk lid with Intelligent
Key. (See “Intelligent Key system” (P.3-6)
or “Remote keyless entry system” (P.3-14).)
SPA2404
TRUNK OPEN REQUEST SWITCH
The trunk lid can be opened by pushing the
trunk open request switch when the
Intelligent Key is within the operating
range of the trunk lock/unlock function
regardless of the inside lock knob position.
(See“Intelligent Key system” (P.3-6).)
TRUNK LID

10-4
Intelligent Cruise Control (ICC) system
warning light .................................................... 2-14
Intelligent Key ..................................................... 3-2
Intelligent Key battery discharge indicator ........ 2-22
Intelligent Key insertion indicator ...................... 2-22
Intelligent Key removal indicator ....................... 2-22
Intelligent Key system ......................................... 3-6
Battery replacement ..................................... 8-25
Key operating range ....................................... 3-8
Key operation ................................................ 3-9
Warning light ............................................... 2-15
Warning signals ........................................... 3-12
Intelligent Key warning light ............................. 2-15
Interior light control switch ............................... 2-54
Interior light replacement .................................. 8-28
Interior lights .................................................... 2-54
Interior trunk lid release ................................... 3-19
iPod
®player operation ..................................... 4-71
ISOFIX child restraint ........................................ 1-23
J
Jump starting ...................................................... 6-8
K
Keyless entry (See remote keyless
entry system) .................................................... 3-14
Keys ................................................................... 3-2 For Intelligent Key system .............................. 3-6
L
Labels
Air bag warning labels ................................. 1-51
Air conditioner specification label ................ 9-12
Emission control information label ............... 9-11
Engine serial number ................................... 9-11
F.M.V.S.S./C.M.V.S.S. certification label ........ 9-11
Tire and Loading Information label ...... 8-32, 9-12
Vehicle identification number (VIN) .............. 9-10
LATCH system ................................................... 1-23
License plate, Installing front license plate ....... 9-13
Light
Air bag warning light ................................... 1-51
Bulb replacement ......................................... 8-27
Fog light switch ........................................... 2-39
Headlight switch .......................................... 2-35
Headlights bulb replacement ....................... 8-28
Indicator lights ............................................ 2-17
Interior light control switch .......................... 2-54
Interior lights ............................................... 2-54
Map lights ................................................... 2-54
Replacement ................................................ 8-27
Trunk light ................................................... 2-56
Vanity mirror lights ...................................... 2-55
Warning/indicator lights and
audible reminders ........................................ 2-12
Xenon headlights ......................................... 2-34
Lights, Exterior and interior light replacement ... 8-28
Loading information (See vehicle
loading information) ......................................... 9-16 Lock
Automatic door locks ..................................... 3-5
Door locks ..................................................... 3-4
Power door lock ............................................. 3-4
Trunk lid ...................................................... 3-18
Locking with mechanical key ............................... 3-4
Low fuel warning .............................................. 2-23
Low tire pressure warning light ......................... 2-15
Low tire pressure warning system
(See tire pressure monitoring system (TPMS)) ..... 5-4
Low washer fluid warning ................................. 2-23
M
Maintenance Battery ......................................................... 8-15
General maintenance ..................................... 8-2
Indicators for maintenance ........................... 2-24
Inside the vehicle .......................................... 8-3
Maintenance precautions ............................... 8-5
Maintenance requirements ............................. 8-2
Outside the vehicle ........................................ 8-2
Seat belt maintenance ................................. 1-19
Malfunction indicator light (MIL) ....................... 2-18
Map lights ........................................................ 2-54
Master warning light ......................................... 2-16
Mechanical key (Intelligent Key system) .............. 3-3
Memory storage, Automatic drive positioner ..... 3-29
Meter, Trip computer ......................................... 2-26
Meters and gauges ............................................. 2-6
Instrument brightness control ...................... 2-38
