2014 INFINITI Q60 CONVERTIBLE ECO mode

9 Technical and consumer information
Capacities and recommended fuel/lubricants....... 9-2
Fuel information .............................................. 9-4
Engine oil and oil filter recommendation ......... 9-6
Air conditioning system refrigerant and
lubricant recommendations ............................. 9-7
Specifications ...................................................... 9-8
Engine............................................................. 9-8
Wheels and tires ............................................. 9-9
Dimensions ................................................... 9-10
When traveling or registering your vehicle in
another country ................................................. 9-11
Vehicle identification ......................................... 9-11 Vehicle Identification Number (VIN) plate ....... 9-11
Vehicle identification number
(chassis number) ........................................... 9-11
Engine serial number .................................... 9-12
F.M.V.S.S./C.M.V.S.S. certification label .......... 9-12
Emission control information label ................ 9-12
Tire and Loading Information label ................ 9-13
Air conditioner specification label.................. 9-13 Installing front license plate .............................. 9-13
Except for INFINITI Performance Line model ... 9-14
For INFINITI Performance Line model ............ 9-16
Vehicle loading information............................... 9-17 Terms .......................................................... 9-17
Vehicle load capacity ................................... 9-18
Loading tips................................................. 9-19
Measurement of weights.............................. 9-20
Towing a trailer ................................................. 9-20 Flat towing................................................... 9-20
Uniform tire quality grading .............................. 9-21 Treadwear .................................................... 9-21
Traction AA, A, B and C................................ 9-21
Temperature A, B and C ............................... 9-21
Emission control system warranty ..................... 9-22
Reporting safety defects.................................... 9-22
Readiness for Inspection/Maintenance
(I/M) test .......................................................... 9-23
Event Data Recorders (EDR) ............................... 9-24
Owner’s manual/service manual
order information .............................................. 9-24

9-2Technical and consumer information
The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the“8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended specifications
US measure Imp measure Liter
Fuel 20 gal 16-5/8 gal 76 See“Fuel information”(P.9-4).
Engine oil Genuine NISSAN engine oil or equivalent
INFINITI recommends Genuine NISSAN Ester Engine Oil available at an
INFINITI retailer.
For additional information, see
“Engine oil”(P.8-10) for changing engine
oil.
. Engine oil with API Certification Mark
. For additional information, see “Engine oil and oil filter recommenda-
tion” (P.9-6).
. Viscosity SAE 5W-30
Drain and refill With oil filter change 5-1/8 qt
4-3/8 qt4.9
Without oil filter change 4-7/8 qt 4 qt4.6
Cooling system Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or
equivalent
Automatic transmission
model
With reservoir
9 qt7-1/2 qt 8.5
Reservoir 7/8 qt3/4 qt 0.8
Manual transmission model With reservoir
9-1/8 qt7-5/8 qt 8.6
Reservoir 7/8 qt3/4 qt 0.8
Automatic transmission fluid ———.
Genuine NISSAN Matic S ATF
. Using automatic transmission fluid other than Genuine NISSAN
Matic S ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmis-
sion, which is not covered by the INFINITI new vehicle limited
warranty.
Manual transmission gear oil ———Genuine NISSAN Manual Transmission Fluid (MTF) HQ Multi 75W-85 or
API GL-4, Viscosity SAE 75W-85
Differential gear oil ———For 7A/T 2WD models:
.
API GL-5 Synthetic Gear Oil Viscosity SAE 75W-90
. See an INFINITI retailer for service for synthetic oil.
All other models:
. Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-90 or API GL-
5, Viscosity SAE 80W-90
. For hot climates, viscosity SAE 90 is suitable for ambient
temperatures above 328F(0 8C).
CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS

STI0801
TIRE AND LOADING INFORMATION
LABEL
The cold tire pressure is shown on the Tire
and Loading Information label affixed to
the pillar as illustrated.
STI0495
AIR CONDITIONER SPECIFICATION
LABEL
The air conditioner specification label is
attached as shown.Use the following steps to mount the
license plate:
Before mounting the license plate, confirm
that the following parts are enclosed in the
plastic bag.
.
License plate bracket
. J-nut 62 (except for INFINITI Perfor-
mance Line model)
. Screw 62
. Screw grommet 62
Only use the recommended mounting
position or Intelligent Cruise Control (ICC)
sensor obstruction (if so equipped) may
result.
Technical and consumer information9-13
INSTALLING FRONT LICENSE PLATE

10 Index
A
ABS (Anti-lock Braking System) ......................... 5-55
Advanced air bag system .................................. 1-40
Air bag systemAdvanced air bag system ............................. 1-40
Door-mounted curtain side-impact
supplemental air bag system ....................... 1-45
Front passenger air bag and status light ...... 1-42
Front-seat mounted side-impact
supplemental air bag system ....................... 1-45
Air bag warning labels ...................................... 1-48
Air bag warning light ............................... 1-48, 2-14
Air cleaner housing filter ................................... 8-19
Air conditioner
Air conditioner service ................................. 4-38
Air conditioner specification label ................ 9-13
Air conditioning system refrigerant and
lubricant recommendations ................... 4-38, 9-7
Automatic climate control ............................ 4-30
In-cabin microfilter ....................................... 4-38
Alarm, How to stop alarm (see vehicle
security system) ................................................ 2-29
Alcohol, drugs and driving .................................. 5-8
Antenna ............................................................ 4-75
Anti-lock Braking System (ABS) ......................... 5-55
Anti-lock braking system (ABS) warning light .... 2-10
Appearance care Exterior appearance care ................................ 7-2
Interior appearance care ................................ 7-4
Ashtrays (See cigarette lighter and ashtrays) .... 2-44 Audible reminders ............................................ 2-17
Audio operation precautions ............................. 4-39
Audio system .................................................... 4-39
Steering wheel audio controls ...................... 4-74
Auto closure ..................................................... 3-29
Autolight system ............................................... 2-35
Automatic Automatic adjusting function
(front windows) ............................................ 2-51
Automatic climate control .................. 4-32, 4-34
Automatic transmission fluid (ATF) ............... 8-12
Climate control ............................................ 4-30
Door locks ..................................................... 3-6
Drive positioner ........................................... 3-38
Driving with automatic transmission ............ 5-13
Seat positioner ............................................ 3-38
Average fuel consumption and speed ................ 2-26
Avoiding collision and rollover ............................ 5-7
B
Battery .............................................................. 8-15
Battery saver system ................................... 2-37
Intelligent Key .............................................. 8-25
Variable voltage control system ................... 8-17
Before starting the engine ................................ 5-12
Bluetooth
®hands-free phone system
(models with navigation system) ....................... 4-77
Bluetooth
®hands-free phone system
(models without navigation system) .................. 4-87 Bluetooth
®streaming audio ............................. 4-66
Brake
Anti-lock Braking System (ABS) .................... 5-55
Brake and clutch fluid .................................. 8-13
Brake fluid ................................................... 8-14
Brake system ............................................... 5-52
Parking brake operation ............................... 5-20
Warning light ............................................... 2-11
Break-in schedule ............................................. 5-46
Brightness control Display ON/OFF button .................................. 4-9
Instrument panel ......................................... 2-38
Bulb check/instrument panel ............................ 2-10
Bulb replacement .............................................. 8-27
C
Cabin air filter ................................................... 4-38
Capacities and recommended fuel/lubricants ...... 9-2
Car phone or CB radio ...................................... 4-76
Catalytic converter, Three way catalyst ................ 5-4
CD/CF/USB memory care and cleaning ............. 4-73
Center multi-function control panel ..................... 4-3
Child restraints ................................................. 1-19 Child Restraint Lower Anchors ...................... 1-21
Precautions on child restraints ..................... 1-20
Child safety ...................................................... 1-17
Chimes, Audible reminders ............................... 2-17
Cigarette lighter and ashtrays ........................... 2-44
Circuit breaker, Fusible link............................... 8-23

10-2
Cleaning exterior and interior ....................... 7-2, 7-4
Climate control, Automatic climate control ........ 4-30
Clock ................................................................ 2-43
Closing the retractable hard top ....................... 3-24
Clutch fluid ....................................................... 8-13
Cockpit ............................................................... 2-3
Cold weather driving ......................................... 5-58
Compact Disc (CD) player (See audio system) ... 4-56
Compact spare tire ........................................... 8-39
Console box ...................................................... 2-47
Controller, Center multi-function control panel .... 4-5
ControlsControl panel button ...................................... 4-3
INFINITI Controller .......................................... 4-5
Coolant Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine coolant ............................... 8-9
Checking engine coolant level ........................ 8-9
Corrosion protection ........................................... 7-7
Cruise control ................................................... 5-21 Fixed speed cruise control (on ICC system) ... 5-41
Intelligent cruise control (ICC) system .......... 5-23
Cup holders ...................................................... 2-45
Current fuel consumption .................................. 2-26
D
Daytime running light system ........................... 2-37
Defroster switch, Rear window and outside mirror
defroster switch ................................................ 2-34
Dimensions ....................................................... 9-10 Distance to empty ............................................. 2-26
Door/trunk open warning .................................. 2-21
Dot matrix liquid crystal display ....................... 2-17
Drive belt .......................................................... 8-18
Drive positioner ................................................ 3-38
Driving
Cold weather driving .................................... 5-58
Driving with automatic transmission ............ 5-13
Driving with manual transmission ................ 5-18
Precautions when starting and driving ........... 5-3
DS (Drive Sport) mode ...................................... 5-15
DVD player operation ........................................ 4-57
E
Economy, Fuel ................................................... 5-47
Elapsed time ..................................................... 2-26
Elapsed time and trip odometer ........................ 2-26
Emergency tire puncture repair kit ...................... 6-8
Emission control information label .................... 9-12
Emission control system warranty ..................... 9-22
Engine Before starting the engine ........................... 5-12
Break-in schedule ........................................ 5-46
Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine coolant ............................... 8-9
Changing engine oil and filter ...................... 8-10
Checking engine coolant level ........................ 8-9
Checking engine oil level ............................. 8-10
Coolant temperature gauge ............................ 2-8
Emergency engine shut off ........................... 5-11 Engine block heater ..................................... 5-59
Engine compartment check locations ............. 8-7
Engine cooling system ................................... 8-8
Engine oil .................................................... 8-10
Engine oil and oil filter recommendation ........ 9-6
Engine oil replacement indicator .................. 2-24
Engine oil viscosity ........................................ 9-7
Engine serial number ................................... 9-12
Engine specifications ..................................... 9-8
Engine start operation indicator (Automatic
Transmission models) .................................. 2-20
Engine start operation indicator (Manual
Transmission models) .................................. 2-21
If your vehicle overheats .............................. 6-16
Starting the engine ...................................... 5-12
Event Data Recorders (EDR) ............................... 9-24
Exhaust gas (carbon monoxide) .......................... 5-3
F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-12
Filter
Air cleaner housing filter .............................. 8-19
Changing engine oil and filter ...................... 8-10
Flashers (See hazard warning flasher switch) ...... 6-2
Flat tire ............................................................... 6-3 Changing flat tire (with spare tire) ................. 6-4
Repairing flat tire (with emergency tire
puncture repair kit) ........................................ 6-8
Flat towing ........................................................ 9-20
Floor mat cleaning .............................................. 7-5

FluidAutomatic transmission fluid (ATF) ............... 8-12
Brake and clutch fluid .................................. 8-13
Brake fluid ................................................... 8-14
Capacities and
recommended fuel/lubricants ........................ 9-2
Engine coolant ............................................... 8-8
Engine oil .................................................... 8-10
Power steering fluid ..................................... 8-13
Window washer fluid ................................... 8-14
FM-AM-SAT radio with Compact Disc
(CD) player ........................................................ 4-53
Fog light switch ................................................ 2-39
Front passenger air bag and status light ........... 1-42
Front power seat adjustment ............................... 1-3
Front seat, Front seat adjustment ........................ 1-3
Front-seat active head restraints ....................... 1-10
Fuel Capacities and
recommended fuel/lubricants ........................ 9-2
Fuel economy............................................... 5-47
Fuel economy information (display) .............. 4-11
Fuel octane rating .......................................... 9-4
Fuel recommendation ..................................... 9-4
Fuel-filler cap ............................................... 3-31
Fuel-filler door ............................................. 3-31
Gauge ............................................................ 2-9
LOOSE FUEL CAP warning ............................. 3-33
Fuel Efficient Driving Tips .................................. 5-46
Fuses ................................................................ 8-22
Fusible links ..................................................... 8-23G
Garage door opener HomeLink®Universal Transceiver ................. 2-54
Gas cap ............................................................ 3-31
Gauge ................................................................. 2-6
Engine coolant temperature gauge ................. 2-8
Fuel gauge ..................................................... 2-9
Odometer....................................................... 2-7
Speedometer ................................................. 2-7
Tachometer .................................................... 2-8
Trip computer .............................................. 2-26
General maintenance .......................................... 8-2
Glove box ......................................................... 2-47
H
Hands-free phone system, Bluetooth®
(models with navigation system) ....................... 4-77
Hands-free phone system, Bluetooth®
(models without navigation system) .................. 4-87
Hard top If the top does not open or close ................. 3-24
Indicators for retractable hard top
(dot matrix) ......................................... 2-23, 3-22
Initializing .................................................... 3-25
Operating using the Intelligent Key .............. 3-25
Retractable hard top operation .................... 3-18
Hazard warning flasher switch ............................ 6-2
Head restraints ................................................... 1-7 Headlights
Bulb replacement ......................................... 8-27
Headlight switch .......................................... 2-35
Xenon headlights ......................................... 2-34
Heated seats .................................................... 2-39
Heater Automatic climate control ............................ 4-30
Engine block heater ..................................... 5-59
HomeLink
®Universal Transceiver ...................... 2-54
Hood release .................................................... 3-17
Horn ................................................................. 2-39
I
Ignition switch (Push-button) ................................................. 5-9
Manual transmission models ....................... 5-18
Immobilizer system ........................................... 2-30
In-cabin microfilter ............................................ 4-38
Indicator Dot matrix display ....................................... 2-17
Lights .......................................................... 2-15
INFINITI Vehicle Immobilizer System .................. 2-30
INFINITI voice recognition system .................... 4-101
INFO button ........................................................ 4-9
Inside mirror ..................................................... 3-35
Inspection/maintenance (I/M) test .................... 9-23
Instrument brightness control ........................... 2-38
Instrument panel ................................................ 2-4
Intelligent cruise control (ICC) system ............... 5-23 Preview function .......................................... 5-45
10-3

MirrorInside mirror ................................................ 3-35
Outside mirrors ............................................ 3-36
Vanity mirror ................................................ 3-37
Monitor, Rearview monitor ................................ 4-23
N
New vehicle break-in ......................................... 5-46
No key warning ................................................. 2-20
O
Odometer............................................................ 2-7
Off-road recovery ................................................ 5-7
Oil Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine oil and filter ...................... 8-10
Checking engine oil level ............................. 8-10
Engine oil .................................................... 8-10
Engine oil viscosity ........................................ 9-7
Oil filter replacement indicator ..................... 2-24
Opening the retractable hard top ............. 3-23, 3-25
Operating the retractable hard top .................... 3-18
Operation, Indicators for operation ................... 2-20
Outside air temperature .................................... 2-27
Outside mirrors ................................................. 3-36
Overheat, If your vehicle overheats ................... 6-16
Owner’s Manual/Service Manual
order information .............................................. 9-24
P
Panic alarm ...................................................... 3-15
Parking Brake break-in ............................................. 5-52
Parking brake operation ............................... 5-20
Parking brake release warning ..................... 2-21
Parking on hills ........................................... 5-48
Phone
Bluetooth
®hands-free phone system
(models with navigation system) .................. 4-77
Bluetooth
®hands-free phone system (models
without navigation system) .......................... 4-87
Car phone or CB radio ................................. 4-76
Pop-up roll bar system ..................................... 1-49 Power
Front seat adjustment .................................... 1-3
Power door lock ............................................. 3-5
Power outlet ................................................ 2-43
Power steering fluid ..................................... 8-13
Power steering system ................................. 5-51
Power windows ............................................ 2-49
Precautions Audio operation ........................................... 4-39
Braking precautions ..................................... 5-52
Child restraints ............................................ 1-20
Cruise control .............................................. 5-21
Maintenance .................................................. 8-5
Seat belt usage ........................................... 1-11Supplemental restraint system ..................... 1-35
When starting and driving .............................. 5-3 Pre-crash seat belts .......................................... 1-13
Predictive course line settings .......................... 4-28
Preview function ............................................... 5-53
Preview function (for Intelligent cruise
control system) ................................................. 5-45
Preview Function warning light .......................... 2-14
Push starting .................................................... 6-16
Push warning (Automatic
Transmission models) ....................................... 2-20
Push-button ignition switch ....................... 5-9, 5-10R
Radio ................................................................ 4-39
Car phone or CB radio ................................. 4-76
FM-AM-SAT radio with Compact Disc
(CD) player ................................................... 4-53
Rain-sensing auto wiper system ........................ 2-33
Rapid air pressure loss ....................................... 5-7
Readiness for inspection/maintenance
(I/M) test .......................................................... 9-23
Rear window and outside mirror
defroster switch ................................................ 2-34
Rearview monitor .............................................. 4-23
Recorders, Event data ....................................... 9-24
Registering your vehicle in another country ...... 9-11
Remote keyless entry system ............................ 3-14
Repairing flat tire (with emergency tire puncture
repair kit) ........................................................... 6-8 Reporting safety defects ................................... 9-22
Retractable hard top ......................................... 3-18
Roadside assistance program ............................. 6-2
10-5

T
Tachometer ......................................................... 2-8
Temperature gauge, Engine coolant
temperature gauge .............................................. 2-8
Theft (INFINITI Vehicle Immobilizer System),
Engine start ...................................................... 2-30
Thigh extension .................................................. 1-5
Three-way catalyst .............................................. 5-4
Tilt/telescopic steering ...................................... 3-34
TirePressure, Low tire pressure warning light .... 2-12
Sealant .......................................................... 6-8
Tire replacement indicator ............................ 2-24
Tires
Emergency tire puncture repair kit ................. 6-8
Flat tire .......................................................... 6-3
Low tire pressure warning system .................. 5-4
Spare tire .................................................... 8-39
Tire and Loading Information label ...... 8-32, 9-13
Tire chains ................................................... 8-37
Tire dressing .................................................. 7-4
Tire pressure................................................ 8-30
Tire pressure monitoring
system (TPMS) ....................................... 5-4, 6-3
Tire rotation ................................................. 8-37
Types of tires ............................................... 8-36
Uniform tire quality grading ......................... 9-21
Wheel/tire size .............................................. 9-9
Wheels and tires .......................................... 8-30
Top, Retractable hard top .................................. 3-18 Touch screen system ........................................... 4-5
Towing
Flat towing ................................................... 9-20
Tow truck towing .......................................... 6-17
Towing a trailer ............................................ 9-20
TPMS, Tire pressure monitoring system .............. 5-4
TPMS, Tire pressure warning system ................... 6-3
Trailer towing .................................................... 9-20
Transceiver HomeLink
®Universal Transceiver ................. 2-54
Transmission Automatic transmission fluid (ATF) ............... 8-12
Driving with automatic transmission ............ 5-13
Driving with manual transmission ................ 5-18
Transmission shift lever lock release ............ 5-17
Transmitter (See remote keyless entry system) ... 3-14
Traveling or registering your vehicle in
another country ................................................ 9-11
Trip computer ................................................... 2-26
Trip odometer ................................................... 2-26
Trunk Interior trunk lid release .............................. 3-30
Light ............................................................ 2-53
Trunk lid ...................................................... 3-28
Trunk lid release switch ............................... 3-28
Trunk open request switch ........................... 3-28
Trunk release power cancel switch ............... 3-29
Turn signal switch ............................................. 2-38
U
Underbody cleaning ............................................ 7-3
Uniform tire quality grading .............................. 9-21
USB memory operation ..................................... 4-61
V
Vanity mirror ..................................................... 3-37
Vanity mirror lights ........................................... 2-53
Variable voltage control system ........................ 8-17
Vehicle
Dimensions .................................................. 9-10
Identification number (VIN) .......................... 9-11
Loading information ..................................... 9-17
Recovery (freeing a stuck vehicle) ................ 6-19
Security system ........................................... 2-28
Vehicle dynamic control (VDC) off switch ...... 2-42
Vehicle dynamic control (VDC) system .......... 5-56
Vehicle dynamic control (VDC)
warning light ............................................... 2-15
Vehicle information and settings (display) ...... 4-9
Ventilators ........................................................ 4-30
Voice command (Bluetooth
®Hands-Free
Phone System) .................................................. 4-93
Voice command (INFINITI voice
recognition system) ............................. 4-108, 4-117
Voice recognition system ................................ 4-101
Voice recognition, Alternate command mode ... 4-114
Voice recognition, Standard mode ................... 4-101
10-7
