2014 HONDA INSIGHT dashboard

(seat belts, SRS, and child protection)
(main controls)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
(climate control, audio, steering wheel, security, cruise control, and other convenience items) (fuel, vehicle break-in, and cargo loading)
(engine and transmission operation) (minder, f luid checking, minor services, and vehicle storage) (f lat tire, jump starting, overheating, and f uses)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
Contents
............................................................
Driver and Passenger Saf ety .5
........................................................................\
........................................................................
Index .I
Service Inf ormation Summary ........................................................................\
.......................
Your Vehicle at a Glance .3
.......
Instruments and Controls .59
............
Features .161
.......................................................................
Bef ore Driving .243
........................................................................\
.................
Driving .261
.................................................
Maintenance .297
........................................
T aking Care of the Unexpected .347
..............................................
T echnical Inf ormation .377
..................
Warranty and Customer Relations (U.S. and Canada only) .393
........................................................................\
..........
A uthorized Manuals (U.S. only) .397
1
12/07/13 16:36:55 31TM8630_006
Owner's Identification Form
Index
Bo ok Ta ble of Contents
Chapter Ta ble of Contents
Navigation KeyYour Vehicle at a Glance
2014 Insight

A summary of the inf ormation you
need when you pull up to the f uel
pump. How to order manuals and other
technical literature.
A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
The Maintenance Minder shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them.
ID numbers, dimensions, capacities,
and technical information. This section covers several problems
motorists sometimes experience,
and details how to handle them.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
Explains the purpose of each
instrument panel indicator and gauge,
the multi-information display, and
how to use the controls on the
dashboard and steering column.
How to operate the climate control
system, the audio system, and other
convenience f eatures.
Overview of Contents
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls Bef ore Driving
Driving
Maintenance
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T echnical Inf ormation T aking Care of the Unexpected
Features
2
TM
12/07/13 16:37:13 31TM8630_007
2014 Insight

The most important things you need
to know about your airbags are:They are designed to supplement
the seat belts.
To do
their job, airbags must inf late with
tremendous f orce. So while
airbags help save lives, they can
cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly. Always wear
your seat belt properly, and sit
upright and as f ar back f rom the
steering wheel as possible while
allowing f ull control of the vehicle. A
f ront passenger should move their
seat as far back from the dashboard
as possible. The rest of this section gives more
detailed inf ormation about how you
can maximize your saf ety.
Remember, however, that no saf ety
system can prevent all injuries or
deaths that can occur in a severe
crash, even when seat belts are
properly worn and the airbags deploy.
Airbags do not replace seat belts.
A irbags of f er no prot ect ion in rearcollisions, or minor f ront al or sidecollisions.
A irbags can pose hazards. What you should do:
Your Vehicle’s Saf ety Features
11
12/07/13 16:38:14 31TM8630_016
Driver and Passenger Saf etyTOC
2014 Insight

Adjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have a f ront passenger adjust their
seat as far to the rear as possible.If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating f ront
airbag, or by striking the steering
wheel or dashboard.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that drivers
allow at least 10 inches (25 cm)
between the center of the steering
wheel and the chest. In addition to
adjusting the seat, you can adjust the
steering wheel up and down, and in
and out (see
page).
If you cannot get f ar enough away
f rom the steering wheel and still
reach the controls, we recommend
that you investigate whether some
type of adaptive equipment may help. Once a seat is adjusted correctly,
rock it back and f orth to make sure it
is locked in position.
See
page f or how to adjust the
f ront seats.
128
141
Adjust the Front Seats
2.
Protecting A dults and Teens
14
Sitting too close to a front
airbag can result in serious
injury or death if the front
airbags inflate.
Always sit as far back from the
front airbags as possible.
12/07/13 16:38:36 31TM8630_019
Driver and Passenger Saf etyTOC
2014 Insight

Your Airbag System includes:Two SRS (supplemental restraint
system) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page).
Two side airbags, one f or the
driver and one f or a f ront
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page).
Two side curtain airbags, one for
each side of the vehicle. The
airbags are stored in the ceiling,
above the side windows. The
front and rear pillars are
marked ‘‘SIDE CURTAIN
AIRBAG’’ (see page). Automatic front seat belt
tensioners (see
page).
Sensors that can detect a
moderate to severe front impact or
side impact.
Sensors that can detect whether a
child is in the passenger’s side
airbag path and signal the control
unit to turn the airbag of f (see
page ). Sensors that can detect whether
the driver’s seat belt and the f ront
passenger’s seat belt are latched
or unlatched (see
page).
A driver’s seat position sensor
that monitors the distance of the
seat from the front airbag. If the
seat is too far forward, the
airbag will inflate with less force
(see page ).
28
32
33 23
32 21
30
Additional Inf ormation About Your Airbags
26
12/07/13 16:39:58 31TM8630_031
Driver and Passenger Saf etyTOC
2014 Insight

An indicator on the instrument
panel that alerts you that the
passenger’s side airbag has been
turned of f (seepage).
An indicator on the dashboard that
alerts you that the passenger’s
f ront airbag has been turned of f
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
Weight sensors that monitor the
weight on the f ront passenger’s
seat. If the weight is about 65
lbs (29 kg) or less (the weight
of an inf ant or small child), the
passenger’s f ront airbag will be
turned of f (see
page). A sophisticated electronic
system that continually monitors
and records information about
the sensors, the control unit, the
airbag activators, the seat belt
tensioners, and driver and front
passenger seat belt use
when the ignition switch is in the
ON (II) position.
An indicator on the instrument
panel that alerts you to a possible
problem with your airbag system
components (see
page). 34
35
34
30
Additional Inf ormation About Your Airbags
27
12/07/13 16:40:04 31TM8630_032
Driver and Passenger Saf etyTOC
2014 Insight

Be aware that objects placed on the
passenger’s seat can also cause the
airbag to be turned off.
When the passenger airbag gets
turned of f by the weight sensors, a
‘‘passenger airbag of f ’’ indicator in
the center of the dashboard comes
on (seepage ).
If the weight sensors detect there is
no passenger in the f ront seat, the
airbag is automatically turned off.
However, the passenger airbag of f
indicator in this situation will not
come on. To ensure that the passenger’s
advanced front airbag system will
work properly,
This includes:
A rear passenger pushing or
pulling on the back of the f ront
passenger’s seat.
Moving the f ront seat f orcibly
back against cargo on the seat or
f loor behind it.
Hanging heavy items on the f ront
passenger seat, or placing heavy
items in the seat-back pocket.
Moving the front seat or seat-back
f orcibly back against the f olded
rear seat. Back seat passengers should not
wedge objects or intentionally
f orce their f eet under the f ront
passenger seat.
35
Additional Inf ormation About Your Airbags
do not do anyt hing
t hat would increase or decrease t he weight on the f ront passenger’s seat.
31
12/07/13 16:40:33 31TM8630_036
Driver and Passenger Saf etyTOC
2014 Insight

µ
To remind you of the passenger’s
f ront airbag hazards, and that
children must be properly restrained
in a back seat, your vehicle has
warninglabelsonthedashboard
(U.S. models) and on the f ront visors.
Please read and follow the
instructions on these labels.
Canadian Models
U.S. Models
Protecting Children General Guidelines
40
SUN VISORS
DASHBOARD
SUN VISORS
12/07/13 16:41:53 31TM8630_045
Driver and Passenger Saf etyTOC
2014 Insight
