2014 HONDA INSIGHT TPMS

Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off. In certain unusual conditions when
your vehicle gets stuck in shallow
mud or f resh snow, it may be easier
to free it with the VSA temporarily
switched of f . When the VSA system
is of f , the traction control system is
alsooff.Youshouldonlyattemptto
f ree your vehicle with the VSA of f if
you are not able to f ree it when the
VSA is on. VSA is turned on every time you
start the engine, even if you
turned it off the last time you drove
the vehicle.
When VSA is off, the VSA activation
indicator comes on as a reminder.
Press and hold the switch again. It
turns the system back on. This switch is under the driver’s
side vent. To turn the VSA system
on and off, press and hold it until
you hear a beep.
If the low tire pressure/TPMS
indicator comes on (seepage),
or the multi-information display
shows a ‘‘CHECK TPMS SYSTEM’’
message with the indicator flashing
(see
page ), the VSA system
automatically turns on even if the
VSA system is turned off with the
VSA OFF switch. In this case, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement. 289
290
On U.S. models
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
VSA OFF Switch
294
VSA OFF
SWITCH
12/07/13 17:14:34 31TM8630_299
Bef ore DrivingTOC
2014 Insight

To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.Keeping the tires properly
inflated provides the best
combination of handling,
tread life, and riding comfort.
Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
The tire pressure monitoring system
(TPMS) warns you when a tire
pressure is low. See pagef or
more inf ormation. Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
Use a gauge to measure the air
pressure in each tire at least once a
month. Even tires that are in good
condition may lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf /cm ) per
month. Remember to check the
sparetireatthesametime.
Check the air pressures when the
tires are cold. This means the
vehicle has been parked for at least
3 hours, or driven less than 1 mile
(1.6 km). Add or release air, if
needed, to match the recommended
cold tire pressures.
We recommend that you visually
check your tires every day. If you
think a tire might be low, check it
immediately with a tire gauge. 289
On U.S. models On U.S. models
On all Canadian models
T ires Inf lation Guidelines
Tires
338
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
12/07/13 17:19:53 31TM8630_343
Maint enanceTOC
2014 Insight

To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the multi-information display. Move
the tires to the positions shown in
the illustration each time they are
rotated. If you purchase directional
tires, rotate only front-to-back.Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Replacement wheels are available at
your dealer. Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system work by
comparing the speed of each wheel.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the system to activate.
On U.S. models
CONT INUED
T ire Rotation
Replacing T ires and Wheels
Tires
341
FrontFront
(Front Non-directional
Tires and Wheels) (Front Directional
Tires and Wheels)
12/07/13 17:20:23 31TM8630_346
Maint enanceTOC
2014 Insight

Check the air pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:Replace the tire when you can see
the tread wear indicator bars. The
replacement tire should be the same
size and design, mounted on the
samewheel.Thesparetireisnot
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Follow these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving. Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel. Do not mount snow chains on the
compact spare tire.
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on
while driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on
again. You will also see a ‘‘CHECK
TPMS SYSTEM’’ message on the
multi-inf ormation display. This is
normal; the system cannot
monitor the spare tire pressure.
Manually check the spare tire
pressure to be sure it is correct.
On U.S. models
Compact Spare Tire
348
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)
12/07/13 17:21:13 31TM8630_353
T aking Care of t he Unexpect edTOC
2014 Insight

µ
µ
µ
µ
µ
Î
Î
No. No. Amps.
Amps. Circuits Protected
Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
10 A
10 A
10 A
30 A
20 A
10 A
30 A
7.5 A 10 A
20 A
10 A
15 A
15 A
30 A
15 A
15 A
10 A
7.5 A
7.5 A
15 A
(7.5 A) 20 A
10 A
10 A
10 A
7.5 A
7.5 A
7.5 A 10 A
20 A
7.5 A
7.5 A 10 A
20 A
20 A
20 A
15 A
15 A
7.5 A Hazard
Stop/Horn
Not Used
LAF
Door Lock Main
Headlight Main
Small Light
Radiator Fan Motor
IGPS
Right Headlight Low Beam
IG Coil
Left Headlight Low Beam
Door Lock Motor 2 (Lock)
Door Lock Motor 1 (Lock)
ABS/VSA FSR
Selectable Door Lock
IGP
Not Used
Not Used
IMA 1
MG Clutch
STS
Back Up
TPMS
Driver’s Power Window
Not Used
Back Up Light
SRS
T ransmission SOL
OPDS
Not Used
A/C
ABS/VSA
IMA
ACC Socket
Accessory
Daytime Running Light
Rear Wiper
Front Passenger’s Power
Window
Rear Passenger’s Side
Power Window
Rear Driver’s Side Power
Window
Fuel Pump
Washer
Meter
: U.S. models
Fuse Locations
372
INTERIOR FUSE BOX
12/07/13 17:23:54 31TM8630_377
T aking Care of t he Unexpect edTOC
2014 Insight

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers . 378
................................
Specif ications .380
DOT Tire Quality Grading ......................
(U.S. Vehicles) .382
Unif orm Tire Quality ..................................
Grading .382
.................................
Treadwear .382
......................................
Traction .382
.............................
Temperature .383
.................................
Tire Labeling .383
Tire Pressure Monitoring System (TPMS) Required Federal ............................
Explanation .385 .......................
Emissions Controls .387
.....................
The Clean Air Act .387
Crankcase Emissions Control ....................................
System .387
Evaporative Emissions Control ....................................
System .387
Onboard Ref ueling Vapor ................................
Recovery .387
...
Exhaust Emissions Controls . 388
....................
PGM-FI System .388
Ignition Timing Control ................................
System .388
Exhaust Gas Recirculation ...................
(EGR) System . 388
Three Way Catalytic ...........................
Converter .388
....................
Replacement Parts . 388
..
Three Way Catalytic Converter . 389
........................
Emissions Testing .390
..
Devices that Emit Radio Waves . 392
T echnical Inf ormation
377
12/07/13 17:24:28 31TM8630_382
2014 Insight

µ
µµ
µ µ
As an added safety
feature, your vehicle
has been equipped
with a tire pressure monitoring
system (TPM S) that illuminates a
low tire pressure telltale when one
or more of your tires is
significantly under- inflated.
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure.
Maximum Load Rating Means the
load rating for a tire at the maximum
permissible inf lation pressure f or
that tire.
Recommended Inf lation Pressure
The cold tire inf lation pressure
recommended by the manuf acturer.
Treadwear Indicators (TWI)
Means the projections within the
principal grooves designed to give a
visual indication of the degrees of
wear of the tread.
Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.)
CONT INUED
U.S. models only
Tire Labeling, Tire Pressure Monitoring System (TPMS) Required Federal Explanation
Tire Pressure Monitoring System
(T PMS) Required Federal
Explanation
385
12/07/13 17:25:55 31TM8630_390
Technical Inf ormationTOC
2014 Insight

µ
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Always check the TPMS
malfunction telltale after
replacing one or more tires or
wheels on your vehicle to ensure
that the replacement or alternate
tires and wheels allow the TPMS
to continue to function properly.
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is combined
with the low tire pressure telltale.
When the system detects a
malf unction, the telltale will f lash f or
approximately one minute and then
remain continuously illuminated.
This sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.
When the malf unction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
386
12/07/13 17:26:00 31TM8630_391
Technical Inf ormationTOC
2014 Insight
