2014 HONDA FIT turn signal bulb

70
uuIndicatorsu
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Turn Signal
Indicators
●The turn signal indicators blink when you
operate the turn signal lever.●If you press the hazard warning button,
both indicators and all turn signals blink
at the same time.
●Does not blink or blinks rapidly - A turn signal
light bulb has blown. Change the bulb immediately.
2Replacing Light Bulbs P. 213, 216
High Beam Indicator
●Comes on when the high beam
headlights are on.●Comes on with reduced brightness when
DRL (daytime running lights) are on.
—
Lights On Indicator
●Comes on whenever the light switch is
on when the exterior lights are on.
●If you remove the key from the ignition switch while
the lights are on, a chime sounds when the driver’s
door is opened.
Fog Light Indicator
*
●Comes on when the fog lights are on.
—
Immobilizer System
Indicator
●Comes on briefly when you turn the
ignition switch to ON
(w, then goes off.
●Comes on if the immobilizer system
cannot recognize the key information.
●Blinks - You cannot start the engine. Turn the
ignition switch to LOCK
(0, pull the key out, and
then insert the key and turn it to ON
(w again.
●Repeatedly blinks - The system may be
malfunctioning. Have the vehicle checked by a
dealer.●Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.
* Not available on all models

213
uuReplacing Light BulbsuFront Turn Signal Light Bulbs
Maintenance
5.Reinstall the hold-down wire. Hook the end
of the wire on the knob in the slot.
uYou can see if the hold-down wire is in
the right place from the inspection
window.
6.Reinstall the rubber weather seal.
7.Insert the coupler into the connector of the
bulb.
Front Turn Signal Light BulbsWhen replacing, use the following bulbs.
1.Turn the socket to the left and remove it.
2.Push in the old bulb, rotate to the left until
it unlocks, and remove.
3.Insert a new bulb.
Hold-Down WireInspection Window
Front Turn Signal Light: 21 W (Amber)
Bulb
Socket

216
uuReplacing Light BulbsuBrake Light, Taillight, Back-Up Light and Rear Turn Signal Light Bulbs
Maintenance
Brake Light, Taillight, Back-Up Light and Rear Turn Signal Light BulbsWhen replacing, use the following bulbs.
1.Pry on the edge of the cover using a flat-tip
screwdriver to remove the cover.
uWrap the flat-tip screwdriver with a cloth
to prevent scratches.
2.Turn the socket to the left and remove it.
Remove the old bulb.
3.Insert a new bulb.Brake/Taillight: 21/5 W
Back-Up Light: 16 W
Rear Turn Signal Light: 21 W (Amber)
CoverBulb Socket

268Information
Specifications■Vehicle SpecificationsModel
Honda Fit
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating
U.S.: 3,512 lbs (1,594 kg)
Canada: 1,594 kg
Gross Axle Weight
Rating (Front)
U.S.: 1,921 lbs (872 kg)
Canada: 872 kg
Gross Axle Weight
Rating (Rear)
U.S.: 1,619 lbs (735 kg)
Canada: 735 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 13.1 – 14.8 oz (370 – 420 g)
Lubricant Type SP-10
■Engine Specifications
■Fuel
■Battery
■Washer FluidDisplacement
91.3 cu-in (1,497 cm
3)
Spark PlugsNGK IZFR6K13
DENSO
SKJ20DR-M13
Fuel:
Type
Unleaded gasoline, Pump octane number
of 87 or higher
Fuel Tank Capacity 10.6 US gal (40 ℓ)
Capacity/Type
32AH(5)/40AH(20)
34AH(5)/40AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
■Light Bulbs*1: Sport models
*2: Not available on all modelsHeadlights (High/Low Beam)
60/55W (HB2)
Fog Lights
*1
55W (H11)
Parking/Side Marker Lights
3.8W (Amber)
Front Turn Signal Lights 21W (Amber)
Brake/Taillights
21/5W
Back-Up Lights 16W
Rear Turn Signal Lights
21W (Amber)
High-Mount Brake Light LED
Rear License Plate Light
5W
Cargo Area Light 5W
Center Console Light
*2
1.4W
Interior Lights
Map Lights
*2
8W
Ceiling Light 8W

280Index
Bulb Replacement..................................... 212
Brake Light, Taillight, Back-Up Light and
Rear Turn Signal Lights........................... 216
Fog Lights ................................................ 214
Headlights ............................................... 212
High-Mount Brake Light .......................... 217
Rear License Plate Light............................ 217
Bulb Specifications.................................... 268CCarbon Monoxide Gas................................ 61
Cargo Floor Box........................................ 115
Cargo Hooks.............................................. 117
Carrying Cargo.................................. 155, 157
CD Player................................................... 129
Certification Label.................................... 270
Changing Bulbs......................................... 212
Charging System Indicator................. 65, 256
Child Safety................................................. 49
Childproof Door Locks ............................... 83
Child Seat.................................................... 49
Booster Seats ............................................. 60
Child Seat for Infants ................................. 51
Child Seat for Small Children ..................... 52
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 56
Larger Children .......................................... 59
Rear-facing Child Seat ............................... 51
Selecting a Child Seat ................................ 53
Childproof Door Locks................................ 83Cleaning the Exterior............................... 235
Cleaning the Interior................................ 234
Clock............................................................ 76
Clutch Fluid............................................... 210
Coat Hook................................................. 116
Compact Spare Tire.......................... 239, 269
Controls....................................................... 75
Coolant (Engine)...................................... 206
Adding to the Radiator ............................ 207
Adding to the Reserve Tank..................... 206
High Temperature Indicator ....................... 67
Low Temperature Indicator........................ 67
Overheating ............................................ 254
Creeping (Automatic Transmission)........ 164
Cruise Control........................................... 173
Indicator.................................................... 71
Cup Holders.............................................. 114
Customer Service Information................. 278
DDaytime Running Lights............................ 96
Dead Battery............................................. 251
Defrosting the Windshield and
Windows................................................. 120
Devices that Emit Radio Waves............... 271
Dimming
Headlights ................................................. 95
Rearview Mirror....................................... 102
Dipstick (Engine Oil)................................. 202
Directional Signals (Turn Signal)............... 95Door Mirrors............................................. 102
Doors.......................................................... 77
Auto Door Locking.................................... 84
Auto Door Unlocking ................................ 84
Door and Tailgate Open Indicator ....... 25, 68
Keys.......................................................... 77
Locking/Unlocking the Doors from the
Inside ...................................................... 82
Locking/Unlocking the Doors from the
Outside ................................................... 79
Lockout Prevention System ....................... 81
DOT Tire Quality Grading........................ 225
Driving...................................................... 153
Automatic Transmission .......................... 164
Braking ................................................... 181
Cruise Control ........................................ 173
Shifting Gear .......................... 165, 167, 171
Starting the Engine ................................. 161
Dust and Pollen Filter.............................. 233
EElectric Power Steering (EPS) System
Indicator ........................................... 68, 258
Electronic Stability Control (ESC)............ 176
Emergency................................................ 264
Emissions Testing (Readiness Codes)...... 273
Engine....................................................... 270
Coolant .................................................. 206
Jump Starting ......................................... 251
Oil .......................................................... 201

282Index
Heating and Cooling System.................... 118
Cooling ................................................... 120
Defrosting the Windshield and
Windows ............................................... 120
Dust and Pollen Filter ............................... 233
Heating ................................................... 119
HFL (HandsFreeLink®)............................... 140
High-Beam Indicator.................................. 70IIdentification Numbers............................ 270
Engine and Transmission.......................... 270
Vehicle Identification ............................... 270
Ignition Switch............................................ 94
Illumination Control................................... 99
Knob ......................................................... 99
Immobilizer System.................................... 90
Indicator .................................................... 70
Indicators..................................................... 64
ABS (Anti-lock Brake System) ..................... 67
Charging System ............................... 65, 256
CRUISE CONTROL .............................. 71, 174
CRUISE MAIN .................................... 71, 173
Daytime Running Lights ............................. 71
Door and Tailgate Open....................... 25, 68
EPS (Electric Power Steering) System .. 68, 258
Fog Light ................................................... 70
High Temperature...................................... 67
High-Beam ................................................ 70
Immobilizer System .................................... 70Lights On .................................................. 70
Low Fuel ................................................... 66
Low Oil Pressure ................................ 64, 256
Low Temperature ...................................... 67
Low Tire Pressure .............................. 69, 178
Maintenance Minder
TM...................... 71, 195
Malfunction Indicator Lamp............... 65, 257
Parking Brake and Brake System ........ 64, 258
Seat Belt Reminder .............................. 27, 66
Security System Alarm ............................... 71
Shift Position ............................................. 65
Side Airbag Off ................................... 47, 69
Supplemental Restraint System ............ 45, 67
TPMS ................................................ 69, 180
Transmission ............................................. 66
Turn Signal ................................................ 70
VSA® (Vehicle Stability Assist)
System ............................................ 68, 176
VSA® OFF .......................................... 68, 177
Washer Level ............................................. 71
Information.............................................. 267
Information Display................................... 73
Instrument Panel........................................ 63
Brightness Control..................................... 99
Interior Lights........................................... 111
Interior Rearview Mirror.......................... 102
JJack (Wheel Nut Wrench)................ 238, 242
Jump Starting........................................... 251
KKeyless Lockout Prevention....................... 81
Keys............................................................. 77
Lockout Prevention ................................... 81
Rear Door Won’t Open ............................. 83
Remote Transmitter .................................. 79
Types and Functions.................................. 77
Won’t Turn ............................................... 17
Kickdown (Automatic Transmission)...... 164LLATCH (Child Seats)................................... 54
Lights.................................................. 95, 212
Bulb Replacement ................................... 212
Daytime Running Lights ............................ 96
Fog Lights ................................................. 96
High-Beam Indicator ................................. 70
Interior.................................................... 111
Light Switches........................................... 95
Lights On Indicator.................................... 70
Turn Signals .............................................. 95
Load Limits............................................... 157
Locking/Unlocking..................................... 77
Auto Door Locking/Unlocking ................... 84
Childproof Door Locks .............................. 83
From Inside ............................................... 82
From Outside ............................................ 79
Keys.......................................................... 77
Lockout Prevention System ....................... 81
Using a Key............................................... 80
