2014 HONDA FIT child restraint

7Quick Reference Guide
Safe Driving
(P 21)
Airbags
(P34)
●Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.
Child Safety
(P49)
●All children 12 and younger should be seated in the rear seat.
●Smaller children should be properly restrained in a forward-facing child seat.
●Infants must be properly restrained in a rear-facing child seat.
Exhaust Gas Hazard
(P61)
●Your vehicle emits dangerous exhaust gases that contain
carbon monoxide. Do not run the engine in confined spaces
where carbon monoxide gas can accumulate.
Before Driving Checklist
(P154)
●Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.
Seat Belts
(P26)
●Fasten your seat belt and sit upright well
back in the seat.
●Check that your passengers are wearing
their seat belts correctly.
Fasten your lap belt as
low as possible.* Not available on all models

25
uuFor Safe DrivinguYour Vehicle’s Safety Features
Safe Driving
For the safety of you and your passengers, make a habit of checking these items
each time before you drive.
•After everyone has entered the vehicle, be sure all doors and the tailgate are
closed and locked. Locking the doors and the tailgate helps prevent an occupant
from being ejected and an outsider from unexpectedly opening a door or the
tailgate.
2Locking/Unlocking the Doors from the Inside P. 82
•Adjust your seat to a position suitable for driving. Be sure the front seats are
adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.
2Adjusting the Seats P. 103
•Adjust head restraints to the proper position. Head restraints are most effective
when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.
2Adjusting the Head Restraints P. 105
•Always wear your seat belt, and make sure you wear it properly. Confirm that any
passengers are properly belted as well.
2Fastening a Seat Belt P. 29
•Protect children by using seat belts or child seats according to a child’s age, height
and weight.
2Child Safety P. 49
■Safety Checklist
1Safety Checklist
If the door and tailgate open indicator is on, a door
and/or the tailgate is not completely closed. Close all
doors and the tailgate tightly until the indicator goes
off.
2Door and Tailgate Open Indicator P. 68

35
uuAirbagsuAirbag System Components
Continued
Safe Driving
The front, front side, and side curtain
airbags are deployed according to the
direction and severity of impact. The airbag
system includes:aTwo SRS (Supplemental Restraint System)
front airbags. The driver’s airbag is stored
in the center of the steering wheel; the
front passenger’s airbag is stored in the
dashboard. Both are marked SRS
AIRBAG.bTwo side airbags, one for the driver and
one for a front passenger. The airbags are
stored in the outer edges of the seat-
backs. Both are marked SIDE AIRBAG.cTwo side curtain airbags, one for each
side of the vehicle. The airbags are stored
in the ceiling, above the side windows.
The front and rear pillars are marked
SIDE CURTAIN AIRBAG.
dAn electronic control unit that continually
monitors and records information about
the sensors, the airbag activators, the
seat belt tensioners, and driver and front
passenger seat belt use when the ignition
switch is in ON
(w.
eAutomatic front seat belt tensioners. The
driver’s and front passenger’s seat belts
incorporate sensors that detect whether
or not they are fastened.fA driver’s seat position sensor. If the seat
is too far forward, the airbag will inflate
with less force.gWeight sensors in the front passenger’s
seat. The front passenger’s airbag will be
turned off if the weight on the seat is 65
lbs (29 kg) or less (the weight of an infant
or small child).
hImpact sensors that can detect a
moderate-to-severe front or side
collision.iAn indicator on the dashboard that alerts
you that the front passenger’s front
airbag has been turned off.jSensors that can detect if a child or small
statured adult is in the deployment path
of the front passenger’s side airbag.kAn indicator on the instrument panel that
alerts you to a possible problem with your
airbag system or seat belt tensioners.lAn indicator on the instrument panel that
alerts you that the front passenger’s side
airbag has been turned off.

Continued
55
uuChild SafetyuSafety of Infants and Small Children
Safe Driving
3.Put the head restraint to its upright, then
route the tether strap between the head
restraint legs, and secure the tether strap
hook onto the anchor.
4.Tighten the tether strap as instructed by the
child seat maker.
5.Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.
6.Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.
Flexible Type
1Installing a LATCH-Compatible Child Seat
For your child’s safety, when using a child seat
installed using the LATCH system, make sure that the
seat is properly secured to the vehicle. A child seat
that is not properly secured will not adequately
protect a child in a crash and may cause injury to the
child or other vehicle occupants.
Anchor
Tether Strap Hook

58
uuChild SafetyuSafety of Infants and Small Children
Safe Driving
■Using an outer anchor
1.Put the head restraint to its upright, then
route the tether strap through the head
restraint legs. Make sure the strap is not
twisted.
2.Secure the tether strap hook onto the
anchor.
3.Tighten the tether strap as instructed by the
child seat manufacturer.■Using the center anchor
1.Lower the head restraint to its lowest
position.
2.Open the anchor cover.
3.Route the tether strap over the head
restraint.
Make sure the strap is not twisted.
4.Secure the tether strap hook onto the
anchor.
5.Tighten the tether strap as instructed by the
child seat manufacturer.
Anchor
Tether Strap HookAnchor
Anchor Cover

Index
279Index
Index
AABS (Anti-lock Brake System).................. 183
Accessories and Modifications................ 190
Accessory Power Socket........................... 115
Active Head Restraints............................. 107
Additives
Coolant .................................................. 206
Engine Oil ............................................... 201
Washer ................................................... 211
Additives, Engine Oil............................... 201
Adjusting
Armrest .................................................. 110
Front Seats.............................................. 103
Head Restraints ....................................... 105
Headlights .............................................. 212
Mirrors.................................................... 102
Rear Seats ............................................... 108
Steering Wheel ....................................... 101
Air Conditioning System (Heating and
Cooling System)...................................... 118
Cooling................................................... 120
Defrosting the Windshield and
Windows .............................................. 120
Dust and Pollen Filter .............................. 233
Heating................................................... 119
Air Pressure...................................... 223, 269
Airbags....................................................... 34
Advanced Airbags ..................................... 40
After a Collision ........................................ 38
Airbag Care .............................................. 48
Event Data Recorder ................................. 19Front Airbags (SRS) .................................... 37
Indicator ........................................ 45, 67, 69
Passenger Airbag Off Indicator .................. 46
Sensors...................................................... 34
Side Airbag Cutoff System ......................... 43
Side Airbag Off Indicator ........................... 47
Side Airbags .............................................. 41
Side Curtain Airbags .................................. 44
Anti-lock Brake System (ABS).................. 183
Indicator .................................................... 67
Armrest..................................................... 110
Audio System............................................ 122
Adjusting the Sound ................................ 126
Auxiliary Input Jack .................................. 123
Error Messages ........................................ 135
General Information ................................ 137
MP3/WMA/AAC ...................................... 133
Recommended CDs ................................. 137
Recommended Devices ............................ 139
Remote Controls ......................................... 3
Security Code .......................................... 124
Theft Protection....................................... 124
USB Adapter Cable .................................. 123
USB Flash Drives ...................................... 139
Authorized Manuals................................. 277
Auto Door Locking/Unlocking................... 84
Customize ................................................. 85
Automatic Transmission........................... 164
Creeping ................................................. 164
Fluid ........................................................ 208
Kickdown ................................................ 164Operating the Shift Lever........... 13, 166, 168
Sequential Shift Mode ............................. 169
Shift Lever Does Not Move ...................... 253
Shifting ........................................... 165, 167
Auxiliary Input Jack.................................. 123
Average Fuel Economy.............................. 74
BBattery...................................................... 231
Charging System Indicator................. 65, 256
Jump Starting .......................................... 251
Maintenance (Checking the Battery) ........ 231
Maintenance (Replacing) ......................... 232
Belts (Seat).................................................. 26
Beverage Holders..................................... 114
Bluetooth® HandsFreeLink®..................... 140
Booster Seats (For Children)...................... 60
Brake System............................................ 181
Anti-lock Brake System (ABS)................... 183
Brake Assist System ................................. 184
Fluid ........................................................ 210
Foot Brake............................................... 182
Indicator............................................ 64, 258
Parking Brake .......................................... 181
Brightness Control (Instrument Panel)...... 99

282Index
Heating and Cooling System.................... 118
Cooling ................................................... 120
Defrosting the Windshield and
Windows ............................................... 120
Dust and Pollen Filter ............................... 233
Heating ................................................... 119
HFL (HandsFreeLink®)............................... 140
High-Beam Indicator.................................. 70IIdentification Numbers............................ 270
Engine and Transmission.......................... 270
Vehicle Identification ............................... 270
Ignition Switch............................................ 94
Illumination Control................................... 99
Knob ......................................................... 99
Immobilizer System.................................... 90
Indicator .................................................... 70
Indicators..................................................... 64
ABS (Anti-lock Brake System) ..................... 67
Charging System ............................... 65, 256
CRUISE CONTROL .............................. 71, 174
CRUISE MAIN .................................... 71, 173
Daytime Running Lights ............................. 71
Door and Tailgate Open....................... 25, 68
EPS (Electric Power Steering) System .. 68, 258
Fog Light ................................................... 70
High Temperature...................................... 67
High-Beam ................................................ 70
Immobilizer System .................................... 70Lights On .................................................. 70
Low Fuel ................................................... 66
Low Oil Pressure ................................ 64, 256
Low Temperature ...................................... 67
Low Tire Pressure .............................. 69, 178
Maintenance Minder
TM...................... 71, 195
Malfunction Indicator Lamp............... 65, 257
Parking Brake and Brake System ........ 64, 258
Seat Belt Reminder .............................. 27, 66
Security System Alarm ............................... 71
Shift Position ............................................. 65
Side Airbag Off ................................... 47, 69
Supplemental Restraint System ............ 45, 67
TPMS ................................................ 69, 180
Transmission ............................................. 66
Turn Signal ................................................ 70
VSA® (Vehicle Stability Assist)
System ............................................ 68, 176
VSA® OFF .......................................... 68, 177
Washer Level ............................................. 71
Information.............................................. 267
Information Display................................... 73
Instrument Panel........................................ 63
Brightness Control..................................... 99
Interior Lights........................................... 111
Interior Rearview Mirror.......................... 102
JJack (Wheel Nut Wrench)................ 238, 242
Jump Starting........................................... 251
KKeyless Lockout Prevention....................... 81
Keys............................................................. 77
Lockout Prevention ................................... 81
Rear Door Won’t Open ............................. 83
Remote Transmitter .................................. 79
Types and Functions.................................. 77
Won’t Turn ............................................... 17
Kickdown (Automatic Transmission)...... 164LLATCH (Child Seats)................................... 54
Lights.................................................. 95, 212
Bulb Replacement ................................... 212
Daytime Running Lights ............................ 96
Fog Lights ................................................. 96
High-Beam Indicator ................................. 70
Interior.................................................... 111
Light Switches........................................... 95
Lights On Indicator.................................... 70
Turn Signals .............................................. 95
Load Limits............................................... 157
Locking/Unlocking..................................... 77
Auto Door Locking/Unlocking ................... 84
Childproof Door Locks .............................. 83
From Inside ............................................... 82
From Outside ............................................ 79
Keys.......................................................... 77
Lockout Prevention System ....................... 81
Using a Key............................................... 80

284Index
Remote Transmitter.................................... 79
Replacement
Battery..................................................... 232
Bulbs ....................................................... 212
Fuses ............................................... 260, 261
Tires ........................................................ 228
Wiper Blade Rubber ......................... 218, 220
Reporting Safety Defects......................... 272
Resetting a Trip Meter............................... 73SSafe Driving................................................. 21
Safety Check................................................ 25
Safety Labels............................................... 62
Safety Message........................................... 20
Seat Belts..................................................... 26
Adjusting the Shoulder Anchor .................. 30
Automatic Seat Belt Tensioners .................. 28
Checking ................................................... 33
Detachable Anchor .................................... 31
Fastening ................................................... 29
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 56
Pregnant Women ...................................... 32
Reminder ................................................... 27
Warning Indicator ................................ 27, 66
Seats.......................................................... 103
Adjusting ................................................. 103
Front Seats .............................................. 103
Rear Seats................................................ 108Seat Under Box ....................................... 116
Security System........................................... 90
Immobilizer System Indicator ..................... 70
Security System Alarm Indicator................. 71
Select Lever................................. 13, 165, 171
Operation.......................... 13, 166, 167, 168
Releasing................................................. 253
Won’t Move ............................................ 253
Select/Reset Knob....................................... 73
Selecting a Child Seat................................. 53
Selector Knob (Audio).............................. 125
Sequential Shift Mode............................. 169
Setting the Clock........................................ 76
Shift Lever........................... 13, 165, 167, 171
Shift Position Indicator.............. 65, 166, 168
Shifting (Transmission)............. 165, 167, 171
Shoulder Anchor........................................ 30
Side Airbags................................................ 41
Cutoff System ........................................... 43
Off Indicator.............................................. 43
Side Curtain Airbags.................................. 44
Snow Tires................................................. 230
Spare Tire.......................................... 239, 269
Spark Plugs............................................... 268
Specifications............................................ 268
Specified Fuel................................... 186, 268
Speedometer.............................................. 72
SRS Airbags (Airbags)................................. 37
Starting the Engine.................................. 161
Does Not Start......................................... 250
Engine Switch Buzzer ................................ 94Jump Starting ......................................... 251
Steering Wheel........................................ 101
Adjusting ................................................ 101
Stopping................................................... 185
Summer Tires............................................ 230
Supplemental Restraint System (SRS)....... 37
Switches (Around the Steering
Wheel).............................................. 2, 3, 94
TTachometer................................................ 72
Tailgate....................................................... 88
Unable to Open ...................................... 266
Temperature
High Temperature Indicator ...................... 67
Low Temperature Indicator ....................... 67
Time (Setting)............................................. 76
Tire Pressure Monitoring System
(TPMS)..................................................... 178
Indicator ........................................... 69, 259
Tire Repair Kit.......................................... 245
Tires.......................................................... 222
Air Pressure..................................... 223, 269
Checking and Maintaining ...................... 222
Inspection ............................................... 222
Labeling .................................................. 223
Puncture (Flat Tire) .................................. 239
Regulations ............................................. 225
Rotation.................................................. 229
Spare Tire ....................................... 239, 269
