2014 FIAT SCUDO engine

As per Service
Schedule Synthetic-based engine oils, grade SAE 5W- 40,
FIAT 9.55535-N2 qualification
FLUIDS AND LUBRICANTSRECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS
Use Fluid and lubricant specifications Genuine fluids Change
for correct vehicle operation and lubricants intervals
Oils for
diesel engines
For proper and regular operation of Multijet versions with DPF, only use genuine lubricant. In an emergency, lacking the genuine
product, top up only once with max. 0.5 l and contact Fiat Dealership as soon as possible.
Should non-genuine SAE 5W-40 products be used, lubricants with minimum ACEA B4 properties for Diesel engines are tolerated;
in this event top engine performance is not guaranteed.
Using low-quality products, not compliant with ACEA B4 properties and specifications could cause engine damages not covered by
warranty.
For very cold temperatures, consult Fiat Dealership for the proper PETRONAS LUBRICANTSproduct to use. SELENIA WR
VEHICLE
MAINTENANCEIN AN
EMERGENCYCORRECT USE
OF THE VEHICLESAFETY
DEVICESDASHBOARD
AND CONTROLSINDEX WARNING
LIGHTS AND
MESSAGES
209
TECHNICAL
SPECIFICATIONS
179-214 SCUDO LUM GB 18/11/13 14.22 Pagina 209

211
WARNING
LIGHTS AND
MESSAGESINDEX DASHBOARD
AND CONTROLSSAFETY
DEVICESCORRECT USE
OF THE VEHICLEIN AN
EMERGENCYVEHICLE
MAINTENANCETECHNICAL
SPECIFICATIONS
❒
extra-urban cycle: frequent accelerat-
ing in all gears, simulating extraurban
use of the vehicle: speed varies between
0 and 120 km/h;
❒
combined consumption: is calculated
weighing about 37% of urban cycle con-
sumption and about 63% of extraurban
consumption.
FUEL CONSUMPTION The fuel consumption figures given in the
table below are determined on the basis
of the homologation tests set down by
specific European Directives.
The procedures below are followed for
measuring consumption:❒
urban cycle: cold starting followed by
driving that simulates urban use of the
vehicle;IMPORTANT The type of route, traffic
situations, weather conditions, driving
style, general conditions of the vehicle,
trim level/equipment/accessories, load, cli-
mate control system, roof rack, other sit-
uations that affect air drag may lead to dif-
ferent fuel consumption levels than those
measured.
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)Engine 90 Multijet (Euro 4)Model Combi VanSeats5 / 6 8 / 9 2 / 3
VersionLow roof Low roof Low roof Low roof Low roof Low roof High roof
Short wheelbase Long wheelbase Short wheelbase Long wheelbase Short wheelbase Long wheelbase Long wheelbase
Urban
consumption8.4 8.4 8.4 8.4 8.4 8.4 8.6
Extra-urbanconsumption6.6 6.6 6.6 6.6 6.6 6.6 6.8
Combined consumption7.2 7.3 7.3 7.3 7.2 7.2 7.5
179-214 SCUDO LUM GB 18/11/13 14.23 Pagina 211
