▫Automatic Transmission — If Equipped .....378
▫ Appearance Care And Protection From
Corrosion .......................... .380
▫ Convertible Top Care – If Equipped ........386
 FUSES ............................. .388
▫ Interior Fuses ....................... .389
▫ Underhood Fuses ..................... .391
 VEHICLE STORAGE ....................394
 REPLACEMENT BULBS .................395
 BULB REPLACEMENT ..................396
▫ Headlamps Low Beam and High Beam ......396▫
Front Turn Signal, Parking And Daytime Running
Lamps ............................ .396
▫ Front Fog Lamps ..................... .397
▫ Front/Rear Side Marker Lamps ............397
▫ Rear Tail, Stop, Backup And Turn Signal
Lamps ............................ .397
▫ Center High Mounted Stop Lamp (CHMSL) . . .398
 FLUID CAPACITIES ....................399

FLUIDS, LUBRICANTS AND GENUINE PARTS . .400
▫ Engine ............................ .400
▫ Chassis ........................... .401
346 MAINTAINING YOUR VEHICLE

Cavity Vehicle Fuse Number Mini FuseDescription
1 F127.5 Amp Brown Right Low Beam
2 F32 5 Amp Tan Front and Rear Ceiling Lights Trunk and Door
Courtesy Lights
3 F53 5 Amp Tan Instrument Panel Node
4 F3820 Amp Yellow Central Door Locking
5 F36 10 Amp Red Diagnostic Socket, Car Radio, Climate Control
System
6 F4320 Amp Yellow Bi-Directional Washer
7 F4820 Amp Yellow Passenger Power Window
8 F137.5 Amp Brown Left Low Beam, Headlamp Leveling
9 F507.5 Amp Brown Airbag
10 F51 5 Amp Tan Car Radio Switch, Climate Control System,
Stop Light, Clutch
11 F37 5 Amp Tan Stop Light Switch, Instrument Panel Node
390 MAINTAINING YOUR VEHICLE

REPLACEMENT BULBS
Interior Bulbs
Bulb Number
Overhead Lamp C5W
Courtesy Lamp W5W
Exterior Bulbs
Bulb Number
Front Low and High
Beam Headlamp HIR2
Front Parking/Daytime
Running Lamps W21/5W
Front Fog Lamps H11
Front Side Marker Lamps W3W
Front Turn Signal Lamps WY21W
Bulb Number
Side Direction Lamps WY5W
Rear Turn Signal Lamps PY21W
Rear Side Marker Lamps W3W
Rear Tail and Stop
Lamps P21/5W
Rear Backup Lamps W16W
Center High Mounted
Stop Lamp W5W
License Plate Lamps LED (See Authorized dealer)
NOTE: Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
7
MAINTAINING YOUR VEHICLE 395

BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as atmospheric
conditions change to allow the condensation to change
back into a vapor. Turning the lamps on will usually
accelerate the clearing process.
Headlamps Low Beam and High Beam
1. Remove the plastic cap from the back of the headlamp housing.
2. Rotate the bulb counter-clockwise.
3. Remove the bulb and replace as needed.
4. Install the bulb and rotate clockwise to lock in place.
5. Reinstall the plastic cap.
Front Turn Signal, Parking And Daytime Running
Lamps
1. Turn the steering wheel completely to the left or right.
2. Open the wheel housing access door.
Wheel Housing Access Door
396 MAINTAINING YOUR VEHICLE
