2014 FIAT 500C key

xxx.x psi” text message will display when one or more of
the four active road tire pressures are low. Should this
occur, you should stop as soon as possible, check the
inflation pressure of each tire on your vehicle, and inflate
each tire to the vehicle’s recommended cold placard
pressure value. The system will automatically update
and the Tire Pressure Monitoring Light will extinguish
once the updated tire pressures have been received. The
vehicle may need to be driven for up to 20 minutes above
15 mph (24 km/h) to receive this information.
Check TPMS Warnings
The Tire Pressure Monitoring Telltale Light will flash on
and off for 75 seconds and remain on solid when a system
fault is detected, an audible chime will be activated and
the “Service Tire Pressure Monitoring System” text mes-
sage will display. If the ignition key is cycled, this
sequence will repeat providing the system fault still
exists. The Tire Pressure Monitoring Telltale Light willturn off when the fault condition no longer exists. A
system fault can occur with any of the following sce-
narios:
1. Jamming due to electronic devices or driving next to
facilities emitting the same radio frequencies as the
TPM sensors.
2. Installing some form of aftermarket window tinting that affects radio wave signals.
3. Snow or ice around the wheels or wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM sensors.
NOTE: Your vehicle may be equipped with a compact
spare wheel and tire assembly.
1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not moni-
tor the tire pressure in the compact spare tire.
5
STARTING AND OPERATING 287

2. If you install the compact spare tire in place of a roadtire that has a pressure below the low-pressure warn-
ing limit, upon the next ignition key cycle, a chime will
sound and the Tire Pressure Monitoring Telltale Light
will still turn ON due to the low tire.
3. However, after driving the vehicle for up to 20 min- utes above 15 mph (24 km/h), the Tire Pressure
Monitoring Telltale Light will flash on and off for 75
seconds and then remain on solid.
4. This occurs for each subsequent ignition key cycle, a chime will sound and the Tire Pressure Monitoring
Telltale Light will flash on and off for 75 seconds and
then remain on solid.
5. Once you repair or replace the original road tire and reinstall it on the vehicle in place of the compact spare
tire, the TPMS will update automatically and the Tire
Pressure Monitoring Telltale Light will turn OFF, as
long as no tire pressure is below the low-pressure warning limit in any of the four active road tires. The
vehicle may need to be driven for up to 20 minutes
above 15 mph (24 km/h) in order for the TPMS to
receive this information.
Enhanced System — If Equipped
When the vehicle is equipped with an enhanced TPM
system, the driver can view text messages showing the
actual tire pressure value by position by selecting the tire
pressure menu command in the instrument cluster. Refer
to the instrument panel features section of the owners
manual.
Premium TPM System
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels. Sensors, mounted to each
wheel as part of the valve stem, transmit tire pressure
readings to the receiver module.
288 STARTING AND OPERATING

HAZARD WARNING FLASHERS
The Hazard Warning flasher switch is located on the
instrument panel below the radio.Press the switch to turn on the Hazard Warning
flashers. When the switch is activated, all direc-
tional turn signals will flash on and off to warn oncoming
traffic of an emergency. Press the switch a second time to
turn off the Hazard Warning flashers.
Do not use this emergency warning system when the
vehicle is in motion. Use it when your vehicle is disabled
and it is creating a safety hazard for other motorists.
If it is necessary to leave the vehicle to go for service, the
Hazard Warning flashers will continue to operate with
the ignition key removed and the vehicle locked.
NOTE: With extended use, the Hazard Warning flashers
may wear down your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
• On the highways — slow down.
• In city traffic — while stopped, place the transmission
in NEUTRAL, but do not increase engine idle speed.
NOTE: There are steps that you can take to slow down
an impending overheat condition:
• If your air conditioner (A/C) is on, turn it off. The A/C
system adds heat to the engine cooling system and
turning the A/C off can help remove this heat.
• You can also turn the temperature control to maximum
heat, the mode control to floor and the blower control
to high. This allows the heater core to act as a
supplement to the radiator and aids in removing heat
from the engine cooling system.
6
WHAT TO DO IN EMERGENCIES 305

Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equip-
ment manufacturer ’s instructions. Use of safety chains is
mandatory. Attach a tow bar or other towing device to
main structural members of the vehicle, not to bumpers
or associated brackets. State and local laws regarding
vehicles under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the ON/RUN
position.
CAUTION!
•DO NOT flat tow any vehicle equipped with an
automatic transmission. Damage to the drivetrain
will result. If these vehicles require towing, make
sure all drive wheels are OFF the ground.
(Continued)
CAUTION! (Continued)
•Towing this vehicle in violation of the above re-
quirements can cause severe transmission damage.
Damage from improper towing is not covered un-
der the New Vehicle Limited Warranty.
Automatic Transmission
• Vehicle can be towed with the front wheels elevated.
• Vehicle can be towed on a flatbed truck (all wheels off
the ground).
If the ignition key is unavailable, or the battery is
discharged, see “Shift Lever Override” in “What To Do In
Emergencies” for instructions on shifting the automatic
transmission out of PARK for towing.
6
WHAT TO DO IN EMERGENCIES 341

•Flash hazard lights as long as the battery has power or
until the ignition key is turned off.
• Turn on the interior lights, which remain on as long as
the battery has power or until the ignition key is
removed.
• Unlock the doors automatically.
After the event occurs, when the system is active, the
message Fuel Cutoff See Handbook is displayed.
Carefully check the vehicle for fuel leaks in the engine
compartment and on the ground near the engine com-
partment and fuel tank before resetting the system and
starting the engine. System Reset Procedure
After an impact causing airbag deployment, the left and
right turn signal lights, located in the instrument panel
cluster, will both be blinking, until the ignition is turned
off.
In order to move your vehicle to the side of the road you
must follow the system reset procedure.
6
WHAT TO DO IN EMERGENCIES 343

Autostick.............................. .238
Battery ................................ .357
Jump Starting ......................... .332
Keyless Transmitter Replacement (RKE) ........18
Belts, Seat ...............................79
Body Mechanism Lubrication .................363
B-Pillar Location ......................... .264
Brake Assist System ...................... .250
Brake Fluid ............................ .401
Brake, Parking .......................... .244
Brakes ................................ .375
Brake System ........................... .248
Anti-Lock (ABS) ....................... .249
Master Cylinder ....................... .375
Parking ............................. .244
Warning Light ........................ .153
Brake/Transmission Interlock .................231
Bulb Replacement ........................ .395Bulbs, Light
..............................82
Capacities, Antifreeze (Engine Coolant) ..........399
Capacities, Fluid ......................... .399
Caps, Filler Fuel ................................ .298
Oil (Engine) .......................... .355
Carbon Monoxide Warning ...................78
Cargo Area Features ...................... .138
Car Washes ............................ .381
CD (Compact Disc) Player ...................177
Cellular Phone .......................... .206
Chains, Tire ............................ .281
Change Oil Indicator ...................... .404
Changing A Flat Tire ...................... .319
Chart, Tire Sizing ........................ .259
Check Engine Light (Malfunction Indicator Light) . .151
Checking Your Vehicle For Safety ...............78
Checks, Safety ............................78
10
INDEX 423

Passing..............................112
Switch ...............................112
Heated Mirrors ............................93
Heated Seats ............................ .105
Heater ................................ .207
Hill Start Assist .......................... .251
Holder, Cup ............................ .136
Hood Release ........................... .109
Ignition .................................11
Key..................................11
Ignition Key Removal .......................11
Immobilizer (Sentry Key) ....................13
Infant Restraint ...........................56
Information Center, Vehicle ..................158
Instrument Cluster ....................... .146
Instrument Panel and Controls ................143
Instrument Panel Cover .....................385
Instrument Panel Lens Cleaning ...............385Interior Appearance Care
....................383
Interior Lighting ..........................114
Introduction ..............................4
Jacking Instructions ....................... .324
Jack Location ........................... .320
Jack Operation .......................... .319
Jump Starting ........................... .332
Key-In Reminder ..........................13
Key, Replacement ..........................14
Keys ...................................11
Key, Sentry (Immobilizer) ....................13
Lane Change and Turn Signals ................147
Lane Change Assist ........................113
Lap/Shoulder Belts .........................29
Latches .................................82
Hood ............................... .109
428 INDEX

Recorder, Event Data.......................55
Recreational Towing ...................... .300
Reformulated Gasoline .....................294
Refrigerant ............................. .359
Release, Hood ........................... .109
Reminder, Seat Belt .........................37
Remote Keyless Entry (RKE) FCC General Information ..................20
Power Convertible Top Function .............16
Remote Sound System (Radio) Controls .........204
Replacement Bulbs ....................... .395
Replacement Keys .........................14
Replacement Parts ........................ .351
Replacement Tires ........................ .279
Reporting Safety Defects ....................415
Restraints, Child ...........................56
Rotation, Tires .......................... .282
Safety Checks Inside Vehicle ..................79Safety Checks Outside Vehicle
.................82
Safety Defects, Reporting ....................415
Safety, Exhaust Gas .........................78
Safety Information, Tire .....................257
Safety Tips ...............................78
Schedule, Maintenance .....................404
Seat Belt Maintenance ..................... .386
Seat Belt Reminder .........................37
Seat Belts ................................79
And Pregnant Women .....................39
Child Restraint ..........................56
Extender ..............................38
Front Seat .............................29
Inspection .............................79
Pretensioners ...........................37
Rear Seat ..............................29
Untwisting Procedure .....................34
Seat Belts (Sedan) ..........................26
Seats ................................. .101
432 INDEX
