2014 DODGE DURANGO transmission

CAUTION!
•When “rocking” a stuck vehicle by shifting be-
tween DRIVE and REVERSE, do not spin the
wheels faster than 15 mph (24 km/h), or drivetrain
damage may result.
• Revving the engine or spinning the wheels too fast
may lead to transmission overheating and failure.
It can also damage the tires. Do not spin the wheels
above 30 mph (48 km/h) while in gear (no trans-
mission shifting occurring).
MANUAL PARK RELEASE
WARNING!
Always secure your vehicle by fully applying the
parking brake, before activating the Manual Park
Release. Activating the Manual Park Release will
allow your vehicle to roll away if it is not secured by
the parking brake or by proper connection to a tow
vehicle. Activating the Manual Park Release on an
unsecured vehicle could lead to serious injury or
death for those in or around the vehicle.
In order to move the vehicle in cases where the transmis-
sion will not shift out of PARK (such as a dead battery),
a Manual Park Release is available.
Follow these steps to use the Manual Park Release:
1. Firmly apply the parking brake.
6
WHAT TO DO IN EMERGENCIES 551

4. While the metal latch is in the open position, simulta-neously pull upwards on the tether strap until the
lever clicks and latches in the released position. The
transmission is now out of PARK and the vehicle can
be moved.CAUTION!
Closing the armrest while the Manual Park Release is
activated may damage the Manual Park Release
mechanism, the transmission and the armrest.
NOTE: To prevent the vehicle from rolling unintention-
ally, firmly apply the parking brake.
Released Position
6
WHAT TO DO IN EMERGENCIES 553

TOWING A DISABLED VEHICLE
This section describes procedures for towing a disabled
vehicle using a commercial wrecker service. If the trans-
mission and drivetrain are operable, disabled vehiclesmay also be towed as described under “Recreational
Towing” in the “Starting and Operating” section.
Towing Condi-
tion Wheels
OFF the Ground Rear-Wheel
Drive Models All-Wheel Drive Mod-
els With Single-Speed Transfer Case All-Wheel Drive Models With
Two-Speed Transfer Case
Flat Tow NONE If Transmission
Is Operable:
• Transmission
inNEUTRAL
• 30 mph
(48 km/h)
• 30 miles (48
km) max dis-
tance
NOT ALLOWED See Instructions:
•Transmission in PARK
• Transfer case in NEUTRAL
(N)
• Tow in forward direction
6
WHAT TO DO IN EMERGENCIES 555

Towing Condi-tion Wheels
OFF the Ground Rear-Wheel
Drive Models All-Wheel Drive Mod-
els With Single-Speed Transfer Case All-Wheel Drive Models With
Two-Speed Transfer Case
Wheel Lift or Dolly Tow Front
NOT AL-
LOWED NOT ALLOWED
NOT ALLOWED
Rear OKNOT ALLOWED NOT ALLOWED
Flatbed ALL BEST METHOD BEST METHOD BEST METHOD
Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equip-
ment manufacturer ’s instructions. Use of safety chains is
mandatory. Attach a tow bar or other towing device to
main structural members of the vehicle, not to bumpers
or associated brackets. State and local laws regarding
vehicles under tow must be observed. If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the ON/RUN
position, not the ACC position.
If the key fob is unavailable or the vehicle’s battery is
discharged, refer to “Manual Park Release” in this section
for instructions on shifting the transmission out of PARK
for towing.
556 WHAT TO DO IN EMERGENCIES

CAUTION!
Do not use sling type equipment when towing.
When securing the vehicle to a flat bed truck, do not
attach to front or rear suspension components. Dam-
age to your vehicle may result from improper towing.
Rear Wheel Drive Models
The manufacturer recommends towing your vehicle with
all four wheelsOFFthe ground using a flatbed.
If flatbed equipment is not available, and the transmis-
sion is operable, the vehicle may be towed (with rear
wheels on the ground) with the transmission in NEU-
TRAL. Speed must not exceed 30 mph (48 km/h) and the
distance must not exceed 30 miles (48 km).
CAUTION!
Towing the vehicle with the rear wheels on the
ground at more than 30 mph (48 km/h) or for more
than 30 mi (48 km), can cause severe transmission
damage. Such damage is not covered by the New
Vehicle Limited Warranty.
If the transmission is not operable, or the vehicle must be
towed faster than 30 mph (48 km/h) or farther than 30
miles (48 km), tow with the rear wheels OFFthe ground.
Acceptable methods are to tow the vehicle on a flatbed,
or with the front wheels raised and the rear wheels on a
towing dolly, or (when using a suitable steering wheel
stabilizer to hold the front wheels in the straight position)
with the rear wheels raised and the front wheels on the
ground.
6
WHAT TO DO IN EMERGENCIES 557

All-Wheel Drive Models
The manufacturer recommends towing with all wheels
OFFthe ground. Acceptable methods are to tow the
vehicle on a flatbed or with one end of the vehicle raised
and the opposite end on a towing dolly.
If flatbed equipment is not available, and the transfer
case is operable, the vehicles with a two-speed transfer
case may be towed (in the forward direction, with ALL
wheels on the ground), IFthe transfer case is in NEU-
TRAL and the transmission is in PARK. Refer to “Recre-
ational Towing” in “Starting and Operating” for detailed
instructions.
Vehicles equipped with a single-speed transfer case have
no NEUTRAL position, and therefore mustbe towed will
all four wheels OFFthe ground.
CAUTION!
•Front or rear wheel lifts must not be used. Internal
damage to the transmission or transfer case will
occur if a front or rear wheel lift is used when
towing.
• Towing this vehicle in violation of the above re-
quirements can cause severe transmission and/or
transfer case damage. Damage from improper tow-
ing is not covered under the New Vehicle Limited
Warranty.
558 WHAT TO DO IN EMERGENCIES

▫Front/Rear Axle Fluid ..................592
▫ Transfer Case ....................... .593
▫ Automatic Transmission ................594
▫ Appearance Care And Protection From
Corrosion .......................... .596
 FUSES ............................. .602
▫ Power Distribution Center ...............603
 VEHICLE STORAGE ....................611
 REPLACEMENT BULBS .................612
 BULB REPLACEMENT ..................614
▫ High Intensity Discharge Headlamps
(Bi-Xenon) — If Equipped ...............614 ▫
Bi-Halogen Headlamps — If Equipped ......614
▫ Front Turn Signal .....................615
▫ Front Fog Lamps .....................616
▫ Rear Tail, Stop And Turn Signal Lamps ......617
▫ Rear Liftgate Mounted Back-up Lamps ......617
▫ Center High-Mounted Stop Lamp (CHMSL) . .617
▫ Rear License Lamp ....................617
 FLUID CAPACITIES ....................618

FLUIDS, LUBRICANTS AND GENUINE PARTS . .619
▫ Engine ............................ .619
▫ Chassis ............................ .621
560 MAINTAINING YOUR VEHICLE

ONBOARD DIAGNOSTIC SYSTEM (OBD II)
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light (MIL).” It
will also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your authorized dealer for service as
soon as possible.
CAUTION!
•Prolonged driving with the MIL on could cause
further damage to the emission control system. It
could also affect fuel economy and driveability.
The vehicle must be serviced before any emissions
tests can be performed.
• If the MIL is flashing, while the engine is running,
severe catalytic converter damage and power loss
will soon occur. Immediate service is required.
Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines
that the fuel filler cap is loose, improperly
installed, or damaged, a loose gascap indicator
will display in the EVIC telltale display area.
Refer to “Electronic Vehicle Information Center (EVIC) in7
MAINTAINING YOUR VEHICLE 563
