2014 DODGE CHALLENGER coolant level

you use the same engine coolant (OAT coolant conform-
ing to MS-12106) throughout the life of your vehicle.
Please review these recommendations for using Organic
Additive Technology (OAT) engine coolant (antifreeze)
that meets the requirements of Chrysler Material Stan-
dard MS-12106. When adding engine coolant (antifreeze):
•We recommend using MOPAR® Antifreeze/Coolant
10 Year/150,000 Mile Formula OAT (Organic Additive
Technology) that meets the requirements of Chrysler
Material Standard MS-12106.
• Mix a minimum solution of 50% OAT engine coolant
that meets the requirements of Chrysler Material Stan-
dard MS-12106 and distilled water. Use higher concen-
trations (not to exceed 70%) if temperatures below
34° F (37° C) are anticipated.
• Use only high purity water such as distilled or deion-
ized water when mixing the water/engine coolant (antifreeze) solution. The use of lower quality water
will reduce the amount of corrosion protection in the
engine cooling system.
Please note that it is the owner’s responsibility to main-
tain the proper level of protection against freezing ac-
cording to the temperatures occurring in the area where
the vehicle is operated.
NOTE:
• Some vehicles require special tools to add coolant
properly. Failure to fill these systems properly could
lead to severe internal engine damage. If any coolant is
needed to be added to the system please contact your
local authorized dealer.
• Mixing engine coolant (antifreeze) types is not recom-
mended and can result in cooling system damage. If
HOAT and OAT coolant are mixed in an emergency,
7
MAINTAINING YOUR VEHICLE 459

rules for your community. To prevent ingestion by ani-
mals or children, do not store ethylene glycol-based
engine coolant in open containers or allow it to remain in
puddles on the ground. If ingested by a child or pet, seek
emergency assistance immediately. Clean up any ground
spills immediately.
Coolant Level
The coolant bottle provides a quick visual method for
determining that the engine coolant (antifreeze) level is
adequate. With the engine OFF and cold, the level of the
engine coolant (antifreeze) in the bottle should be be-
tween the ranges indicated on the bottle.
The radiator normally remains completely full, so there is
no need to remove the radiator cap unless checking for
engine coolant (antifreeze) freeze point or replacing en-
gine coolant (antifreeze). Advise your service attendantof this. As long as the engine operating temperature is
satisfactory, the coolant bottle need only be checked once
a month.
When additional engine coolant (antifreeze) is needed to
maintain the proper level, it should be added to the
coolant bottle. Do not overfill.
Points To Remember
NOTE:
When the vehicle is stopped after a few miles/
kilometers of operation, you may observe vapor coming
from the front of the engine compartment. This is nor-
mally a result of moisture from rain, snow, or high
humidity accumulating on the radiator and being vapor-
ized when the thermostat opens, allowing hot engine
coolant (antifreeze) to enter the radiator.
If an examination of your engine compartment shows no
evidence of radiator or hose leaks, the vehicle may be
safely driven. The vapor will soon dissipate.
7
MAINTAINING YOUR VEHICLE 461

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate) All Engines 19 Gallons72 Liters
Engine Oil With Filter 3.6 Liter Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters
5.7 Liter Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters
Cooling System* 3.6 Liter Engine (MOPAR® Antifreeze/Engine
Coolant 10 Year/150,000 Mile Formula or equiva- lent) 11.1 Quarts
10.5 Liters
5.7 Liter Engine (MOPAR® Antifreeze/Engine
Coolant 10 Year/150,000 Mile Formula or equiva- lent) 14.7 Quarts
13.9 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
7
MAINTAINING YOUR VEHICLE 491

Severe Duty All Models
Change Engine Oil at 4000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment. This
type of vehicle use is considered Severe Duty
Once A Month Or Before A Long Trip:
•Check engine oil level
• Check windshield washer fluid level
• Check tire pressure and look for unusual wear or
damage. Rotate tires at the first sign of irregular wear,
even if it occurs before your next scheduled service.
• Check the fluid levels of the coolant reservoir, brake
master cylinder, and power steering and fill as needed.
• Check function of all interior and exterior lights Required Maintenance Intervals.
Refer to the maintenance schedules on the following
page for the required maintenance intervals.
At Every Oil Change Interval As Indicated By Oil
Change Indicator System:
•Change oil and filter
•
Rotate the tires.Rotate at the first sign of irregular
wear, even if it occurs before your next scheduled service
• Inspect battery and clean and tighten terminals as
required
• Inspect brake pads, shoes, rotors, drums, hoses
and park brake
•
Inspect engine cooling system protection and hoses
• Inspect exhaust system
• Inspect engine air cleaner if using in dusty or
off-road conditions8
M
A I
N T
E
N
A
N
C E
S
C
H E
D
U L
E
SMAINTENANCE SCHEDULES 497

Universal Consumer Interface (UCI)..........265
Conserving Fuel ......................... .227
Console ............................... .202
Console, Floor .......................... .202
Console, Overhead ....................... .184
Contract, Service ......................... .509
Coolant Pressure Cap (Radiator Cap) ...........460
Cooling System .......................... .456
Adding Coolant (Antifreeze) ...............458
Coolant Capacity ...................... .491
Coolant Level ......................... .456
Disposal of Used Coolant .................460
Drain, Flush, and Refill ...................457
Inspection ........................... .461
Points to Remember .....................461
Pressure Cap ......................... .460
Radiator Cap ......................... .460
Selection of Coolant (Antifreeze) .............457
Corrosion Protection ...................... .468Cruise Light
............................ .210
Cupholders ............................ .201
Customer Assistance ...................... .507
Data Recorder, Event .......................72
Daytime Brightness, Interior Lights .............168
Daytime Running Lights ....................163
Dealer Service ........................... .440
Deck Lid, Emergency Release .................44
Deck Lid, Power Release .....................43
Defroster, Rear Window .....................203
Defroster, Windshield .......................99
Delay (Intermittent) Wipers ..................169
Diagnostic System, Onboard .................438
Dimmer Switch, Headlight ...................166
Dipsticks Oil (Engine) .......................... .442
Disabled Vehicle Towing ................... .429
10
INDEX 519

DisposalAntifreeze (Engine Coolant) ................460
Door Locks Door Locks ............................33
KeyFob...............................33
Remote ...............................33
Remote Keyless Entry (RKE) ................33
Door Locks, Automatic ......................35
Door Opener, Garage ...................... .185
Driving Through Flowing, Rising, or Shallow Standing
Water ............................... .317
Driving to Achieve Maximum Fuel Economy ......227
Electrical Power Outlets .....................197
Electric Remote Mirrors .....................111
Electronic Brake Control System ...............327
Electronic Power Distribution Center (Fuses) ......478
Electronic Speed Control (Cruise Control) ........172Electronic Stability Control (ESC)
..............331
Electronic Throttle Control Warning Light ........211
Electronic Vehicle Information Center (EVIC) ......221
Emergency Deck Lid Release ..................44
Emergency, In Case of Freeing Vehicle When Stuck ................426
Hazard Warning Flasher ..................399
Jacking .............................. .412
Jump Starting ......................... .421
Overheating .......................... .399
Towing ............................. .429
Emergency Trunk Release ....................44
Emission Control System Maintenance ..........439
Engine ................................ .437
Air Cleaner .......................... .446
Block Heater ......................... .299
Break-In Recommendations .................96
Checking Oil Level ..................... .442
Compartment ......................... .436
520 INDEX
