Page 2 of 368
On-line owner's handbook
Referring to the owner's handbook on-line also gives you
access to the latest information available, easily identifi ed by
the bookmark, associated with this symbol:
If the "MyCitroën" function is not available on the CITROËN public
website for your country, you can fi nd your handbook at the following
address:
http://service.citroen.com
Select:
You can fi nd your handbook on the CITROËN website, under
"MyCitroën".
This personal and customisable space allows you to establish direct
and special contact with CITROËN.
The Vehicle documentation link in the home page (no registration is
needed),
the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of
registration of your vehicle.
You have access to your handbook on line, together with the latest
information, identifi ed by the symbol:
Page 50 of 368
48
Monitoring
The various menus may change between
the type 1 instrument panel and the type 2
instrument panel.
Adjusting vehicle settings
When the vehicle is
stationary
, it allows the
user to change the following
settings:
- the reinitialisation
mode for average
fuel consumption and
average speed,
)
Press and hold the INFO
button for a few
seconds to display the menu screen.
)
In the menu screen, press the INFO
button
to select a function from the list:
- the fuel consumption units,
- the temperature display unit,
- the display language,
- activation/deactivation of the sound when
pressing the INFO
button,
- the break (rest) reminder display inter val,
- restore the factory settings.
To change the settings, you must stop
the vehicle and switch on the ignition.
Apply the parking brake and place the
gear lever in neutral.
With the ignition on
, press the INFO
button
on the dashboard, to the left of the instrument
panel, several times in succession until the
"SETTINGS MENU" screen is displayed.
Operation
MENU
1/3
:
- 1 - 2, A - M, A - P
* (choice of the type of
reset of average fuel consumption and
average speed),
- AVG UN I T
(choice of the fuel consumption
units),
- choice of the temperature display unit
,
- LANGUAGE
(option of the display
language),
*
According to display language.
For your safety, when the vehicle is
moving
, the function settings are not
displayed when you press the INFO
button.
Page 51 of 368
1
49
Monitoring
MENU
2/3:
- a/b
(option of displaying a different
language in the instrument panel screen
and the navigation screen),
- activation / deactivation of the INFO
button sound
,
- ALERT
(changing of the "REST
REMINDER" display inter val),
- selection of the sound
of the direction
indicators,
- activation / deactivation of the current
fuel consumption
,
Press and hold the INFO
button for a
few seconds to return to the previous
screen.
When the menu screen is displayed,
if no operation is carried out within
15 seconds, the Settings Menu screen
is displayed.
MENU 3/3:
- RESET
(restore factory settings).
Choice of the reset mode for
average fuel consumption and
average speed
You can choose between two average fuel
consumption and average speed reset modes:
- automatic reset,
- manual reset.
In the menu screen:
)
press the INFO
button to select:
)
press and hold the INFO
button for a
few seconds to switch in succession from
reset mode 1
- A (automatic) *
to reset
mode 2 - M - P (manual) *
.
The mode selected is confirmed.
*
According to display language.
Page 53 of 368
1
51
Monitoring
If you select the "- - -" setting, no
message will be displayed in message
display situations.
If the battery is disconnected, the
settings memory is cleared and the
default language (ENGLISH) is restored
automatically.
)
press the INFO
button to scroll the
languages (Japonais, English, Deutsch,
Français, Espanol, Italiano, Russe "- - -" and
RETURN) in succession,
)
press and hold the INFO
button for a few
seconds to confirm your selection.
Choice of the display LANGUAGE
In the menu screen:
)
press the INFO
button to select
"LANGUAGE"
:
)
press and hold the INFO
button for a few
seconds to display the "LANGUAGE"
screen:
Page 61 of 368
1
59
Monitoring
System screen
Once in the " Tu n i n g …
" menu, select " System
"
to modify the time zone, the units, or the
display language (English, Dutch, Swedish,
French, Portuguese, Italian, German, Spanish,
Nor wegian, Flemish or Danish) and adjust
other settings.
"Settings" menu
Press the S
ETTINGS
button on the control
panel to open the menu.
Uses a soft clean cloth to clean the
screen.
Do not use pointed objects on the touch
screen.
Do not touch the screen with wet hands.
For reasons of safety, the driver
should only carry out operations that
require close attention with the vehicle
stationary .
In addition, some functions are not
accessible when driving.
For more information on these menus,
refer to the "Audio and telematics"
section.
Setting the time
The digital clock is set automatically
.
This mode enables the system to set the local
time automatically using the signal from the
RDS stations.
)
On the control panel, press the SETTINGS
button for access to settings.
Page 165 of 368
163
6
Safety
Deactivating the passenger's airbag
Passenger airbag OFF
The warning label present on both sides of
the passenger's sun visor repeats this advice.
In line with current legislation, the following
two pages contain this warning in all of the
languages required.
Never install a rear ward-facing child
restraint system on a seat protected by
an active front airbag. This could cause
the death of the child or serious injury.
For information on deactivating the
airbag, refer to the "Airbags" section.
Page 246 of 368
244
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
By default, the voice recognition system is in English.
Press this button.
Say " Setup
".
Say " Language
".
Say the language of your choice in English, example: say
" French
" for French.
Say " Ye s
" to start the change of language process
Say " No
" to return to steps 4 to 7.
The system says " Select a language: English, Spanish, French,
German or Italian
".
The system then says " French selected. Is this correct?
"
The system repeats the language chosen and completes the
change of language process.
If you do not start the training procedure within around 3 minutes of
pressing SPEAK, the process is cancelled.
If you press SPEAK within 5 seconds following the play of a voice
command, this command is saved again.
What is the Bluetooth
®
hands-free telephone with voice
recognition?
The system uses wireless communication technology known as
Bluetooth
®
which allows you to make hands-free telephone calls in
your vehicle via your Bluetooth ® compatible mobile telephone.
You can make telephone calls using a microphone located in
the courtesy lamp, making use of the simple steering mounted
controls or by the voice recognition function with voice commands.
Five languages are available: English (the default), Spanish,
French, German and Italian.
Change the voice command language
Page 247 of 368
245
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
Training the user's voice
You can use the user voice training function to create a voice model
for one person per language.
The characteristics of your voice and your pronunciation are saved
in this model to provide the best voice recognition.
The vehicle must be stationary with the parking brake applied.
Switch off your telephone during the operation to avoid any
interruption.
Press this button.
The system says the fi rst of 45 standard phrases.
Say " Word training
".
When you are ready to start, press and
hold this button.
Repeat each of the phrases in the table on the following
page.
The system saves your voice and moves on to the next
command.
Continue the process until all of the phrases have been
saved.
An explanation message is given.
After playing all the voice commands, the system says " The word
training
is complete
" and ends the process.
If you do not start the programming process within approximately
3 minutes after pressing the SPEAK button, the process is
cancelled.
If you press the SPEAK button within 5 seconds of the play of a
voice command, this command is saved again.
