Page 50 of 368
48
Monitoring
The various menus may change between
the type 1 instrument panel and the type 2
instrument panel.
Adjusting vehicle settings
When the vehicle is
stationary
, it allows the
user to change the following
settings:
- the reinitialisation
mode for average
fuel consumption and
average speed,
)
Press and hold the INFO
button for a few
seconds to display the menu screen.
)
In the menu screen, press the INFO
button
to select a function from the list:
- the fuel consumption units,
- the temperature display unit,
- the display language,
- activation/deactivation of the sound when
pressing the INFO
button,
- the break (rest) reminder display inter val,
- restore the factory settings.
To change the settings, you must stop
the vehicle and switch on the ignition.
Apply the parking brake and place the
gear lever in neutral.
With the ignition on
, press the INFO
button
on the dashboard, to the left of the instrument
panel, several times in succession until the
"SETTINGS MENU" screen is displayed.
Operation
MENU
1/3
:
- 1 - 2, A - M, A - P
* (choice of the type of
reset of average fuel consumption and
average speed),
- AVG UN I T
(choice of the fuel consumption
units),
- choice of the temperature display unit
,
- LANGUAGE
(option of the display
language),
*
According to display language.
For your safety, when the vehicle is
moving
, the function settings are not
displayed when you press the INFO
button.
Page 246 of 368
244
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
By default, the voice recognition system is in English.
Press this button.
Say " Setup
".
Say " Language
".
Say the language of your choice in English, example: say
" French
" for French.
Say " Ye s
" to start the change of language process
Say " No
" to return to steps 4 to 7.
The system says " Select a language: English, Spanish, French,
German or Italian
".
The system then says " French selected. Is this correct?
"
The system repeats the language chosen and completes the
change of language process.
If you do not start the training procedure within around 3 minutes of
pressing SPEAK, the process is cancelled.
If you press SPEAK within 5 seconds following the play of a voice
command, this command is saved again.
What is the Bluetooth
®
hands-free telephone with voice
recognition?
The system uses wireless communication technology known as
Bluetooth
®
which allows you to make hands-free telephone calls in
your vehicle via your Bluetooth ® compatible mobile telephone.
You can make telephone calls using a microphone located in
the courtesy lamp, making use of the simple steering mounted
controls or by the voice recognition function with voice commands.
Five languages are available: English (the default), Spanish,
French, German and Italian.
Change the voice command language
Page 252 of 368
250
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
The system has its own phone book, independent of that of the
mobile telephone.
It can contain up to 32 names for each language.
Each name in the phone book is associated with 4 locations:
HOME, WORK, MOBILE and PAGER.
The system says " Select one of the following items: New Entry,
Change, List of names, Delete or Clear all, or say Cancel to
return to the main menu
".
Say " New entry
".
The system says " HOME, WORK, MOBILE OR PAGER
".
Give the location which corresponds to the number that
you wish to record.
The system asks you to confi rm the location.
Answer " Ye s
".
Say " No
" to return to step 7.
If a telephone number has already been recorded for this location,
the system says " The current number is -number-, number
please
".
Saving a name in the system phone book
Press this button.
Say " Phone book
".
The system says " Name please
".
Give the name of your choice.
If you do not wish to change the telephone number, repeat
the original number to retain it, otherwise say the new
number.
Answer " Ye s
".
Say " No
" to return to step 11.
The system asks you to confi rm the number.
Page 255 of 368
253
Voice commands (1/2)
Confi gure
Phone book
Dial
Call
Redial
Emergency number
Pairing options
Pair a telephone
Delete a telephone
List of paired telephones
Select a telephone
Previous
Press this button to start the voice recognition.
When the system is waiting for a voice command, say "Help" to obtain a list of commands which can be used in the current situation.
Divert the call
Add a location
Confi gure the confi rmation requests
Language
New entry
Delete
Change
Call this number
Change another entry
Try again
Clear all
List of names Home, at home
Work, at work
Mobile, on mobile
Pager, on pager
Help
Continue
All
Cancel
Mute
Deactivate mute
Yes
No
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
Page 256 of 368
254
Voice commands (2/2)
Press this button to start the voice recognition.
When the system is waiting for a voice command, say " Help
" to obtain a list of commands which can be used in the current situation.
Zero
One
Two
Three
Four
Five
Six
Seven
Eight
Nine
Star (*)
Hash (#) Word training
PIN
Repeat training
Activate
Deactivate
Incorporate the call
Send
English
Phone book New entry
Phone book Change
Phone book Delete
Phone book Clear All
Phone book List of names
Confi gure the confi rmation requests
Confi gure Select a telephone
Confi gure the pairing options
Delete a name
Confi gure the language
Confi gure the PIN
BLUETOOTH ®
TELEPHONE
WITH VOICE RECOGNITION
Page 326 of 368
324
04 RADIO
Changing the display language of the "PTY" programme
Functions setting mode
This permits activation or deactivation
of the functions below.
Press the SEL
knob repeatedly; the
setting mode for the functions changes
in the following order : GRACENOTE
DB / AF / REG / TP-S / PI-S / PTY
(languages) / PH setting / CT / OFF.
The functions setting mode is deactivated after approximately
10 seconds without any action.
Press the MENU
button.
Press the SEL
knob repeatedly to
select the PTY lang
mode.
Turn the SEL
knob to select the
language (ENGLISH, FRANCAIS,
DEUTSCH, SVENSK, ESPAGNOL,
ITALIANO).
Press then MENU
button.
Turn the SEL
knob to the left to
deactivate the function ("OFF") or to
the right to activate it ("ON").
