2014 CHRYSLER 300 fog light

LIGHTS ............................ .194
▫ Headlight Switch .....................194
▫ Automatic Headlights — If Equipped .......195
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) .............195
▫ Headlight Time Delay ..................195
▫ Automatic High Beam Headlamp Control —
If Equipped ........................ .196
▫ Adaptive Bi-Xenon High Intensity Discharge
Headlights — If Equipped ...............197
▫ Daytime Running Lights (DRL) ............198
▫ Lights-On Reminder ...................198
▫ Fog Lights — If Equipped ...............198
▫ Multifunction Lever ...................200 ▫
Turn Signals ........................ .200
▫ Lane Change Assist ...................201
▫ High/Low Beam Switch ................201
▫ Flash-To-Pass ....................... .201
▫ Front Map/Reading Lights — If Equipped . . .201
▫ Courtesy Lights ...................... .202
▫ Ambient Light — If Equipped ............203
▫ Interior Lights ...................... .203
 WINDSHIELD WIPERS AND WASHERS ......206
▫ Intermittent Wiper System ...............206
▫ Wiper Operation ..................... .206
▫ Mist Feature ........................ .207
▫ Windshield Washers ...................207
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107

LIGHTS
Headlight Switch
The headlight switch is located on the left side of
the instrument panel. This switch controls the
operation of the headlights, parking lights, instru-
ment panel lights, instrument panel light dimming, inte-
rior lights and fog lights.
Rotate the headlight switch clockwise to the first detent
for parking light and instrument panel light operation.
Rotate the headlight switch to the second detent for
headlight, parking light and instrument panel light op-
eration.
Headlight Switch
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•The Adaptive Headlight System is active only when
the vehicle is moving forward.
The Adaptive Headlight System can be turned On or Off
using the Uconnect® System, refer to “Uconnect® Set-
tings” in “Understanding Your Instrument Panel” for
further information.
Daytime Running Lights (DRL)
The LED Daytime Running Lights will come on when-
ever the ignition is placed in the RUN position, the
headlights are off, the transmission is moved out of
“PARK” position, and the parking brake is off. The
headlight switch must be used for normal nighttime
driving. NOTE:
If allowed by law in the country in which the
vehicle was purchased the Daytime Running Lights can
be turned on and off using the Uconnect® System, refer
to “Uconnect® Settings” in “Understanding Your Instru-
ment Panel” for further information.
Lights-On Reminder
If the headlights or parking lights are on after the ignition
is placed in the OFF position, a chime will sound to alert
the driver when the driver’s door is opened.
Fog Lights — If Equipped
Front Fog Lights — If Equipped
The front fog light switch is built into the headlight
switch.
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To activate the front fog lights, turn on the parking
lights or the low beam headlights and press the
headlight switch. To turn off the front fog lights, either
press the headlight switch a second time or turn off the
headlight switch. Rear Fog Lights — If Equipped
The rear fog light switch is built into the head-
light switch. To activate the rear fog lights, turn
the headlamp switch to the park lamp or head-
lamp position. Press the headlight switch once for front
fog lights, press the switch a second time for front and
rear fog lights. Pressing the switch a third time will
deactivate the rear fog lights, and a fourth time will
deactivate the front fog lights. Turning the headlight
switch off will also deactivate the fog lights.
An indicator light in the instrument cluster illuminates
when the fog lights are turned on.
NOTE: The fog lights will operate with the low beam
headlights or parking lights on. However, selecting the
high beam headlights will turn off the fog lights.
Fog Light Switch
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199

INSTRUMENT CLUSTER DESCRIPTIONS
1. Tachometer
This gauge measures engine revolutions-per-minute
(RPM x 1000).
2. Park/Headlight ON Indicator — If EquippedThis indicator will illuminate when the park
lights or headlights are turned on.
3. Turn Signal Indicators The arrow will flash with the exterior turn
signal when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle
is driven more than 1 mile (1.6 km) with either
turn signal on, a continuous chime will sound to alert
you to turn the signals off. If either indicator flashes at a
rapid rate, check for a defective outside light bulb. 4. Front Fog Light Indicator — If Equipped
This indicator will illuminate when the front
fog lights are on.
5. High Beam Indicator This indicator shows that the high beam head-
lights are on. Push the multifunction lever for-
ward to switch the headlights to high beam, and pull
toward yourself (normal position) to return to low beam.
6. Odometer Display/Electronic Vehicle Information
Center (EVIC) Display
•Odometer Display
The odometer display shows the total distance the
vehicle has been driven.
U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser
the correct mileage that the vehicle has been driven. If
304 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
CAUTION!
Do not use Alcohol and Alcohol-based and/or Keton
based cleaning products to clean leather seats, as
damage to the seat may result.
Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone break-
age than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPAR® Glass Cleaner, or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or the right rear
quarter window equipped with the radio antenna. Do
not use scrapers or other sharp instrument that may
scratch the elements.
546 MAINTAINING YOUR VEHICLE

Cooling System........................ .531
Engine Oil ........................... .517
Transfer Case ......................... .541
Fluids, Lubricants and Genuine Parts ...........567
Fog Lights ............................. .198
Folding Rear Seat ........................ .186
Forward Collision Warning ..................245
Freeing A Stuck Vehicle .....................498
Fuel .................................. .451
Additives ............................ .454
Clean Air ............................ .452
Conserving ........................... .325
Ethanol ............................. .452
Filler Door (Gas Cap) ....................308
Gasoline ............................. .451
Gauge .............................. .308
Light ............................... .319
Materials Added ....................... .454
Methanol ............................ .452Octane Rating
......................... .451
Requirements ......................... .451
Saver Mode .......................... .325
Specifications ......................... .567
Tank Capacity ......................... .566
Fuel, Flexible ........................... .456
Fuel Optimizer .......................... .325
Fuel Saver ............................. .325
Fuses ................................. .548
Garage Door Opener (HomeLink®) ............262
Gasoline, Clean Air ....................... .452
Gasoline (Fuel) .......................... .451
Conserving ........................... .325
Gasoline, Reformulated .....................452
Gauges Coolant Temperature .....................312
Fuel ................................ .308
Speedometer ......................... .308
10
INDEX 597

Keyless Entry System.......................22
Keyless Go ...............................12
Key, Replacement ..........................17
Keys ...................................12
Key, Sentry (Immobilizer) ....................16
Knee Bolster ..............................59
Lane Change and Turn Signals ................200
Lane Change Assist ....................... .201
Lap/Shoulder Belts .........................49
Latches ............................... .103
Hood ............................... .192
Latch Plate ...............................50
Lead Free Gasoline ....................... .451
Leaks, Fluid ............................ .103
Life of Tires ............................ .435
Light Bulbs ............................. .103
Lights ................................ .103
Airbag ................................67 Alarm
.............................. .309
Anti-Lock ............................ .309
Automatic Headlights ....................195
Brake Assist Warning ....................413
Brake Warning ........................ .310
Bulb Replacement ...................... .561
Daytime Running ...................... .198
Dimmer Switch, Headlight .................200
Electronic Stability Program (ESP) Indicator .....413
Exterior ............................. .103
Fog ................................ .198
Hazard Warning Flasher ..................481
Headlights ........................... .194
Headlights On Reminder ..................198
Headlights On With Wipers ................195
Headlight Switch ...................... .194
High Beam ........................... .201
High Beam Indicator .....................304
High Beam/Low Beam Select ...............201
600 INDEX
