WARNING!
•Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combinations
of unapproved tires and wheels may change sus-
pension dimensions and performance characteris-
tics, resulting in changes to steering, handling, and
braking of your vehicle. This can cause unpredict-
able handling and stress to steering and suspen-
sion components. You could lose control and have
a collision resulting in serious injury or death. Use
only the tire and wheel sizes with load ratings
approved for your vehicle.
• Never use a tire with a smaller load index or
capacity, other than what was originally equipped
on your vehicle. Using a tire with a smaller load
index could result in tire overloading and failure.
You could lose control and have a collision.
(Continued)
WARNING! (Continued)
•Failure to equip your vehicle with tires having
adequate speed capability can result in sudden tire
failure and loss of vehicle control.
CAUTION!
Replacing original tires with tires of a different size
may result in false speedometer and odometer read-
ings.
TIRE CHAINS (TRACTION DEVICES)
Due to limited clearance, tire chains or traction devices
are not recommended.
CAUTION!
Damage to the vehicle may result if tire chains are used.
5
STARTING AND OPERATING 353

WARNING!
•Never have any smoking materials lit in or near the
vehicle when the gas cap is removed or the tank is
being filled.
• Never add fuel when the engine is running. This is
in violation of most state and federal fire regula-
tions and doing so may cause the MIL to turn on.
• A fire may result if gasoline is pumped into a
portable container that is inside of a vehicle. You
could be burned. Always place gas containers on
the ground while filling.
NOTE:
• When the fuel nozzle “clicks” or shuts off, the fuel tank
is full. •
Tighten the gas cap until you hear a “clicking” sound.
This is an indication that the gas cap is tightened
properly. The MIL in the instrument cluster may turn
on if the gas cap is not secured properly. Make sure
that the gas cap is tightened each time the vehicle is
refueled.
Loose Filler Cap Message
If the vehicles diagnostic system determines that the fuel
filler cap in loose, improperly installed, or damaged, a
“gASCAP” message will be displayed in the instrument
cluster. Tighten the gas cap until a “clicking” sound is
heard. This is an indication that the gas cap is properly
tightened. Press the trip odometer reset button to turn off
the message. If the problem persists, the message will
appear the next time the vehicle is started. This might
indicate a damaged cap. If the problem is detected twice
in a row, the system will turn on the MIL. Resolving the
problem will turn the MIL off.
374 STARTING AND OPERATING

NOTE:There are steps that you can take to slow down
an impending overheat condition:
• If your air conditioner (A/C) is on, turn it off. The A/C
system adds heat to the engine cooling system and
turning the A/C off can help remove this heat.
• You can also turn the temperature control to maximum
heat, the mode control to floor and the blower control
to high. This allows the heater core to act as a
supplement to the radiator and aids in removing heat
from the engine cooling system.
WARNING!
You or others can be badly burned by hot engine
coolant (antifreeze) or steam from your radiator. If
you see or hear steam coming from under the hood,
do not open the hood until the radiator has had time
to cool. Never try to open a cooling system pressure
cap when the radiator or coolant bottle is hot.
Engine Oil Overheating (2.4L Engine Only) — If
Equipped
During sustained high-speed driving or trailer tow up
long grades on a hot day, the engine oil temperature may
become too hot. If this happens, the “HOTOIL” message
flashes in the odometer and the vehicle speed will be
reduced to 48 mph (77 km/h) until the engine oil
temperature is reduced.
NOTE: The vehicle speed is reduced to a maximum of
48 mph (77 km/h). You may of course, reduce your
vehicle speed further if needed.
6
WHAT TO DO IN EMERGENCIES 393

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light” (MIL). It
will also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your authorized dealer for service as
soon as possible.
CAUTION!
•Prolonged driving with the MIL on could cause
further damage to the emission control system. It
could also affect fuel economy and driveability.
The vehicle must be serviced before any emissions
tests can be performed.
• If the MIL is flashing while the engine is running,
severe catalytic converter damage and power loss
will soon occur. Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is possibly loose or
improperly installed. A “gASCAP” message will be dis-
played in the instrument cluster. Tighten the gas cap until
a clicking sound is heard. This is an indication that the
gas cap is properly tightened. Press the trip odometer
“Reset” button to turn off the message. If the problem7
MAINTAINING YOUR VEHICLE 421

Additives............................ .366
Clean Air ............................ .364
Ethanol ............................. .365
Filler Cap (Gas Cap) .....................208
Filler Door (Gas Cap) ....................208
Gasoline ............................. .364
Gauge .............................. .208
Light ............................... .209
Materials Added ....................... .366
Methanol ............................ .365
Octane Rating ......................... .364
Requirements ......................... .364
Tank Capacity ......................... .471
Fuel, Flexible ........................... .368
Fueling ............................... .372
Fuel System Caution ...................... .373
Fuses ................................. .456Garage Door Opener (HomeLink®)
............178
Gas Cap (Fuel Filler Cap) ...................372
Gasoline, Clean Air ....................... .364
Gasoline, Reformulated .....................364
Gauges Coolant Temperature .....................208
Fuel ................................ .208
Odometer ............................ .212
Tachometer ........................... .212
Gear Ranges ............................ .299
Gear Select Lever Override ..................413
General Information ...................... .140
Glass Cleaning .......................... .455
Gross Axle Weight Rating ...................375
Gross Vehicle Weight Rating ..................375
GVWR ................................ .375
500 INDEX

Lumbar Support......................... .153
Maintenance Free Battery ....................429
Maintenance Procedures ....................424
Maintenance Schedule ..................... .476
Malfunction Indicator Light (Check Engine) .......220
Manual, Service ......................... .490
Map/Reading Lights ...................... .168
Master Cylinder (Brakes) ....................444
Methanol .............................. .365
Mini-Trip Computer ...................... .222
Mirrors ............................... .105
Automatic Dimming .....................106
Electric Powered ....................... .107
Heated .............................. .109
Outside ............................. .108
Rearview ............................ .105
Vanity .............................. .109
Modifications/Alterations, Vehicle ...............7Monitor, Tire Pressure System
................355
Mopar Parts ............................ .423
MTBE/ETBE ........................... .365
New Vehicle Break-In Period ..................94
Occupant Restraints ........................65
Occupant Restraints (Sedan) ..................41
Octane Rating, Gasoline (Fuel) ................364
Odometer .............................. .212
Trip ................................ .212
Oil Change Indicator ...................... .214
Oil Change Indicator, Reset ..................214
Oil, Engine ............................. .425
Capacity ............................ .471
Change Interval ....................... .214
Checking ............................ .425
Dipstick ............................. .425
Disposal ............................. .428
504 INDEX

Trailer and Tongue Weight.................381
Wiring .............................. .386
Trailer Towing Guide ...................... .380
Trailer Weight ........................... .380
Transaxle Automatic .............................12
Autostick ............................ .314
Transmission ........................... .446
Automatic ........................... .295
Transmitter Battery Service (Remote Keyless Entry) . .26
Transporting Pets ..........................94
Tread Wear Indicators ..................... .350
Trip Computer .......................... .222
Trip Odometer .......................... .212
Trip Odometer Reset Button ..................215
Trunk Lid (Deck Lid) .......................40
Trunk Release, Emergency ....................41
Trunk Release Remote Control .................40Turn Signals
............................ .165
UCI Connector .......................... .263
Uconnect® Advanced Phone Connectivity ..............127
Operation .............................112
Phone Call Features ......................119
Phone Features ........................ .122
Things You Should Know About Your Uconnect®
Phone .............................. .129
Uconnect® 130 Operating Instructions Auxiliary Mode ........246
Operating Instructions CD Mode ............241
Operating Instructions Radio Mode ..........237
Playing MP3 Files ...................... .243
Uconnect® 130 With Satellite Radio Multimedia Satellite Radio .................259
Operating Instructions CD Mode ............253
Playing MP3 Files ...................... .255
510 INDEX
