2014 CHRYSLER 200 CONVERTIBLE glove box

▫To Resume Speed .....................191
▫ To Vary The Speed Setting ...............191
▫ To Accelerate For Passing ................191
 GARAGE DOOR OPENER — IF EQUIPPED . . .192
▫ Before You Begin Programming HomeLink® . .193
▫ Programming A Rolling Code .............194
▫ Programming A Non-Rolling Code .........196
▫ Canadian/Gate Operator Programming ......197
▫ Using HomeLink® .....................199
▫ Security ........................... .199
▫ Troubleshooting Tips ...................199
▫ General Information ....................200
 ELECTRICAL POWER OUTLETS ...........201
CIGAR LIGHTER AND ASH RECEIVER — IF
EQUIPPED .......................... .204
 CUPHOLDERS ....................... .204
▫ Front Seat Cupholder ...................204
▫ Rear Seat Cupholders ..................205
 STORAGE ........................... .206
▫ Glovebox Storage Compartment ...........206
 CONSOLE FEATURES ...................206
▫ Storage ............................ .206
 CARGO AREA FEATURES ................208
▫ Ski Pass-Through ..................... .210
 REAR WINDOW FEATURES ..............210
▫ Rear Window Defroster .................210
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

STORAGE
Glovebox Storage Compartment
The glovebox storage compartment is located on the right
side of the instrument panel. To open the glovebox, pull
outward on the latch handle located on the front of the
glovebox.
CONSOLE FEATURES
Storage
The center console is located between the front driver
and passenger seats. The center console armrest slides
forward from design position to provide added user
Glovebox Storage Compartment
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Protection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by authorized dealer or other
service facilities using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C system
sealers, stop leak products, seal conditioners, compressor
oil, and refrigerants.
A/C Air Filter – If Equipped
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
WARNING!
Do not remove the A/C air filter while the blower is
operating or personal injury may result.
The A/C Air Filter is located in the fresh air inlet behind
the glove box. Perform the following procedure to re-
place the filter: 1. Open the glove box and remove all contents.
2. Push in on the sides of the glove box and lower the
door.
3.
Disconnect the glove box door dampener from the slot
on the side of the box. This is done by grasping the
dampener connector (on the outside of the box) and the
end of the connector pin (on the inside of the box) with
your thumb and forefinger and pulling outward while
lightly lifting upward on the door with your other hand.
Once disconnected, the dampener will retract under-
neath the instrument panel if you release it.
4. Pivot the glove box downward.
5. Disengage the two retaining tabs that secure the filter cover to the HVAC housing and remove the cover.
436 MAINTAINING YOUR VEHICLE

6. Remove the A/C Air Filter by pulling it straight out ofthe housing. 7. Install the A/C Air Filter with the arrow on the filter
pointing toward the floor. When installing the filter
cover, make sure the retaining tabs fully engage the
cover.
CAUTION!
The A/C air filter is identified with an arrow to
indicate airflow direction through the filter. Failure
to install the filter properly will result in the need to
replace it more often.
8. Reinstall the glove box door dampener and glove box.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, sliding doors and hood hinges, should be lubri-
cated periodically with a lithium based grease, such as
A/C Air Filter Replacement
7
MAINTAINING YOUR VEHICLE 437

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days, you may want to take steps to preserve your
battery.
•Disengage the mini-fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
• Or disconnect the negative cable from the battery.
• Anytime you store your vehicle, or keep it out of
service (i.e., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Bulbs
Bulb Number
Front Courtesy/Reading
Lamp 578/W5W
Center Courtesy/Reading
Lamp 578/W5W
Visor Vanity Lamp A6220
Glove Box Lamp A6220
Shift Indicator Lamp IKLE14140
Rear Compartment
(Trunk) Lamp 579
NOTE: For lighted switches, see your authorized
dealer for replacement.
470 MAINTAINING YOUR VEHICLE
