2014 CHRYSLER 200 CONVERTIBLE check engine light

result in unsatisfactory engine coolant (antifreeze)
performance, poor gas mileage, and increased emis-
sions.
Brake System
In order to assure brake system performance, all brake
system components should be inspected periodically.
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
WARNING!
Riding the brakes can lead to brake failure and
possibly a collision. Driving with your foot resting or
riding on the brake pedal can result in abnormally
high brake temperatures, excessive lining wear, and
possible brake damage. You would not have your full
braking capacity in an emergency.
Master Cylinder – Brake Fluid Level Check
Check the fluid level in the master cylinder immediately
if the brake system warning light indicates system fail-
ure.
Check the fluid level in the master cylinder when per-
forming underhood services.
Clean the top of the master cylinder area before removing
the cap. If necessary, add fluid to bring the fluid level up
to the requirements described on the brake fluid reser-
voir.
Overfilling of fluid is not recommended because it may
cause leaking in the system.
Fluid level can be expected to fall as the brake pads wear.
Brake fluid level should be checked when pads are
replaced. However, low fluid level may be caused by a
leak and a checkup may be needed.
448 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Operating conditions
such as frequent short-trips, trailer tow, extremely hot or
cold ambient temperatures, and E85 fuel usage will
influence when the “Oil Change Required” message is
displayed. Severe Operating Conditions can cause the
change oil message to illuminate as early as 3,500 miles
(5,600 km) since last reset. Have your vehicle serviced as
soon as possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other thanyour authorized dealer, the message can be reset by refer-
ring to the steps described under “Electronic Vehicle Infor-
mation Center (EVIC)/Oil Change Required” in “Under-
standing Your Instrument Panel” for further information.
NOTE:
Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km) or twelve months,
whichever comes first.
Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
• Check the fluid levels of the coolant reservoir, brake
master cylinder, power steering and transmission
(four-speed only) and fill as needed
• Check function of all interior and exterior lights
8
M
A I
N T
E
N
A
N
C E
S
C
H E
D
U L
E
S482 MAINTENANCE SCHEDULES

Automatic Transmission....................303
Adding Fluid ......................... .451
Fluid and Filter Changes ..................453
Fluid Level Check ...................... .451
Fluid Type ........................... .450
Gear Ranges .......................... .306
Special Additives ...................... .450
Autostick .............................. .320
Auto Unlock, Doors ........................34
Battery ................................ .433
Keyless Transmitter Replacement (RKE) ........27
Location ............................. .433
Belts, Seat ...............................44
Body Mechanism Lubrication .................437
B-Pillar Location ......................... .344
Brake Assist System ...................... .333
Brake, Parking .......................... .327
Brake System ........................... .448Anti-Lock (ABS)
....................... .329
Fluid Check .......................... .448
Master Cylinder ....................... .448
Parking ............................. .327
Warning Light ........................ .221
Brake/Transmission Interlock .................305
Bulb Replacement ........................ .470
Bulbs, Light ..............................96
Calibration, Compass ..................... .240
Capacities, Fluid ......................... .477
Caps, Filler Fuel ................................ .379
Oil (Engine) .......................... .423
Power Steering ........................ .326
Radiator (Coolant Pressure) ................445
Carbon Monoxide Warning ...................92
Car Washes ............................ .454
Cellular Phone .......................... .128
10
INDEX 501

Certification Label........................ .382
Chains, Tire ............................ .360
Changing A Flat Tire ...................... .400
Chart, Tire Sizing ........................ .339
Check Engine Light (Malfunction Indicator Light) . .426
Checking Your Vehicle For Safety ...............92
Checks, Safety ............................92
Child Restraint ............................70
Cigar Lighter ........................... .204
Clean Air Gasoline ....................... .371
Cleaning Wheels .............................. .456
Climate Control ......................... .283
Clock ................................. .247
Cold Weather Operation ....................302
Compact Disc (CD) Maintenance ..............282
Compact Spare Tire ....................... .355
Compass .............................. .233
Compass Calibration ...................... .240Compass Variance
........................ .241
Computer, Trip/Travel ..................... .239
Connector UCI................................ .273
Universal Consumer Interface (UCI) ..........273
Console ............................... .206
Console, Floor .......................... .206
Contract, Service ......................... .493
Convertible ............................ .101
Convertible Top ......................... .101
Coolant Pressure Cap (Radiator Cap) ...........445
Cooling System .......................... .442
Adding Coolant (Antifreeze) ...............444
Coolant Capacity ...................... .477
Coolant Level ......................... .442
Disposal of Used Coolant .................446
Drain, Flush, and Refill ...................443
Inspection ........................... .446
Points to Remember .....................447
502 INDEX

Exterior Lights............................96
Fabric Care ............................. .457
Filler Location Fuel ....................... .218
Filters Air Cleaner .......................... .432
Air Conditioning ...................... .295
Automatic Transmission ..................453
Engine Oil ........................... .432
Engine Oil Disposal .....................432
Flashers ............................... .398
Hazard Warning ....................... .398
Turn Signal ............................96
Flash-To-Pass ........................... .181
Flexible Fuel Vehicles Cruising Range ........................ .378
Engine Oil ........................... .377
Fuel Requirements ..................... .375
Maintenance .......................... .378Replacement Parts
...................... .378
Starting ............................. .378
Fluid Capacities ......................... .477
Fluid Leaks ..............................96
Fluid Level Checks Automatic Transmission ..................451
Brake ............................... .448
Cooling System ........................ .442
Engine Oil ........................... .429
Power Steering ........................ .326
Fluids, Lubricants and Genuine Parts ...........478
Fog Lights ............................. .181
Fog Light Service ........................ .475
Freeing A Stuck Vehicle .....................416
Fuel .................................. .370
Adding ............................. .379
Additives ............................ .373
Clean Air ............................ .371
Ethanol ............................. .371
10
INDEX 505

Fog .................................181
Headlights ........................... .178
Headlights On With Wipers ................179
Headlight Switch ...................... .178
High Beam ........................... .180
High Beam Indicator .....................232
High Beam/Low Beam Select ...............180
Illuminated Entry ........................21
Instrument Cluster ..................... .178
Interior ............................. .183
License ............................. .477
Lights On Reminder .....................179
Low Fuel ............................ .219
Malfunction Indicator (Check Engine) .........230
Map Reading ......................... .183
Oil Pressure .......................... .220
Passing ............................. .181
Seat Belt Reminder ..................... .219
Security Alarm (Theft Alarm) ................19Service
.............................. .471
Theft Alarm (Security Alarm) ...............227
Tire Pressure Monitoring (TPMS) ............229
Traction Control ....................... .336
Turn Signal ............................96
Voltage ............................. .219
Warning (Instrument Cluster Description) ......218
Loading Vehicle ......................... .382
Capacities ........................... .383
Tires ............................... .344
Locks ..................................32
Automatic Door .........................33
Auto Unlock ...........................34
Door .................................32
Power Door ............................33
Low Tire Pressure System ...................362
Lubrication, Body ........................ .437
Lumbar Support ......................... .170
10
INDEX 509

Maintenance Free Battery....................433
Maintenance Procedures ....................428
Maintenance Schedule ..................... .482
Malfunction Indicator Light (Check Engine) .......230
Manual, Service ......................... .496
Map/Reading Lights ...................... .183
Master Cylinder (Brakes) ....................448
Memory Feature (Memory Seat) ...............171
Methanol .............................. .371
Mini-Trip Computer ...................... .233
Mirrors ............................... .124
Automatic Dimming .....................125
Electric Powered ....................... .126
Electric Remote ........................ .126
Heated .............................. .127
Outside ............................. .127
Rearview ............................ .124
Vanity .............................. .128
Modifications/Alterations, Vehicle ...............7Monitor, Tire Pressure System
................362
Mopar Parts ............................ .427
MTBE/ETBE ........................... .371
New Vehicle Break-In Period ..................91
Occupant Restraints ........................40
Occupant Restraints (Sedan) ..................60
Octane Rating, Gasoline (Fuel) ................370
Odometer .............................. .222
Trip ................................ .222
Oil Change Indicator ...................... .225
Oil Change Indicator, Reset ..................225
Oil, Engine ............................. .429
Capacity ............................ .477
Change Interval ....................... .225
Checking ............................ .429
Dipstick ............................. .429
Disposal ............................. .432
510 INDEX
