Dear Customer,We would like to congratulate and thank you for choosing an Alfa Romeo. We have written this handbook to help you get to know all the
features of your car and use it in the best possible way. You should read it right through before taking to the road for the first time.
Here you will find information, advice and important warnings regarding use of your car and how to achieve the best performance from the
technological features of your Alfa Romeo. It also provides a description of special features and essential information for the care and
maintenance of your Alfa Romeo over time as well as for safe driving.
We urge you to read the warnings and indications found throughout the text with care, marked with the following symbols:
personal safety;car safety;environmental protection.
NOTE These symbols, when necessary, are indicated at the end of each paragraph and are followed by a number. This number
recalls the corresponding warning at the end of the relevant section.
In the attached Warranty Booklet you will also find a description of the Services that Alfa Romeo offers to its customers, the Warranty
Certificate and the detail of the terms and conditions for maintaining its validity.
We are sure that these will help you to get in touch with and appreciate your new car and the service provided by the people at Alfa Romeo.
Enjoy reading and happy motoring!
This Owner Handbook describes all versions of the Alfa Giulietta; please consider only the information relevant to your
car’s trim level, engine and version. All data contained in this publication is purely indicative. Fiat Group Automobiles can
modify the specifications of the vehicle model described in this publication at any time, for technical or marketing
purposes. For further information, contact an Alfa Romeo Dealership.

Warning lights on
panelWhat it means What to do
amberiTPMS SYSTEMIMPORTANT Do not continue driving with one or
more flat tyres as handling may be
compromised. Stop the car, avoiding sharp
braking and steering. Repair immediately using
the dedicated kit (see the "Repairing a wheel"
paragraph in the "In an emergency" chapter)
and contact an Alfa Romeo Dealership as soon
as possible.
iTPMS failure
The warning light switches on when a fault is
detected in the iTPMS.
Should one or more wheels be fitted without
sensors, the display will show a warning message
until initial conditions are restored.In this case, contact an Alfa Romeo Dealership
as soon as possible.
Low tyre pressure - See manual
The warning light switches on, together with a
dedicated message on the display, to indicate that
the tyre pressure is lower than the recommended
value and/or that slow pressure loss is occurring. In
these circumstances, optimal tyre duration and fuel
consumption may not be guaranteed.
Should two or more tyres be in the condition
mentioned above, the display will show the
indications corresponding to each tyre in
sequence.In any situation in which the message on the
display is "See manual", it is ESSENTIAL to refer
to the contents of the "Wheels" paragraph in the
"Technical data" chapter, strictly complying with
the indications that you find there.
125

❒inflate the tyre to the pressure
indicated in the “Wheels” paragraph
in the “Technical data” chapter. In
order to obtain a more precise
reading, check the pressure value on
pressure gauge B fig. 153 with the
compressor off;
❒if after five minutes it is still impossible
to reach at least 1.8 bar, disengage
the compressor from the valve and
power socket, then move the car
forwards by approx. ten metres
in order to distribute the sealing fluid
inside the tyre evenly, then repeat
the inflation operation;
❒if you still cannot obtain a pressure of
at least 1.8 bar within 5 minutes from
the compressor switching on, do
not drive off and contact an Alfa
Romeo Dealership;❒after having driven for about 10
minutes, stop and recheck the tyre
pressure; remember to engage
the handbrake;
❒if a pressure value of at least 1.8 bar
is detected, restore the correct
pressure (with the engine running and
the handbrake engaged), resume
driving and drive with great care to an
Alfa Romeo Dealership.
CHECKING AND
RESTORING TYRE
PRESSURE
The compressor can also be used to
check and, if necessary, adjust the tyre
pressure.
Release quick coupling A fig. 157 and
connect it directly to the valve of the
tyre to be inflated.
152
A0K0518
153
A0K0519
154
A0K0520
155
A0K0128
156
A0K0521
177

TECHNICAL SPECIFICATIONS
Everything you may find useful for
understanding how your car is made
and works is contained in this chapter
and illustrated with data, tables and
graphics. For the enthusiasts and the
technician, but also just for those who
want to know every detail of their
car.IDENTIFICATION DATA....................224
ENGINE CODES - BODYWORK
VERSIONS ......................................22
ENGINE ..........................................227
FUEL SUPPLY .................................231
TRANSMISSION .............................232
BRAKES .........................................233
SUSPENSION .................................23
STEERING SYSTEM .......................235
WHEELS .........................................236
DIMENSIONS ..................................240
PERFORMANCE .............................241
WEIGHTS .......................................242
REFUELLING ..................................244
FLUIDS AND LUBRICANTS ............247
FUEL CONSUMPTION ....................25
CO2 EMISSIONS ............................252
PRESCRIPTIONS FOR HANDLING
THE VEHICLE AT THE END OF ITS
LIFE ................................................253
223
5
4
1

IDENTIFICATION
DATAThe identification data of the car are:
❒V.I.N. plate;
❒Chassis marking;
❒Body paintwork identification plate;
❒Engine marking.
V.I.N. PLATE
This plate is fitted to the engine
compartment front crossmember and
contains the following data fig. 195:BType-approval number.CVehicle type identification codeDChassis serial number.EMaximum authorised weight of
vehicle fully ladenFMaximum authorised weight of
vehicle fully laden plus trailer.
GMaximum permitted weight on first
(front) axleHMaximum permitted weight on
second (rear) axleIEngine type.LBodywork version code.M
Spares number.
NCorrect value of smoke coefficient
(for diesel engines)
CHASSIS MARKING
This is printed on the passenger
compartment floor, near the front right
seat.
Slide the flap A fig. 196 forward to
access.
The marking includes:
❒vehicle type (ZAR 940000);
❒chassis serial number.BODYWORK PAINT
IDENTIFICATION PLATE
It is applied under the bonnet and
shows the following data fig. 197:
APaint manufacturer.
BColour name.
CFiat colour code.
DRespray and touch up code.
ENGINE MARKING
This is stamped on the cylinder block
and gives the model and the chassis
serial number.
195
A0K0024
197
A0K0025
224
TECHNICAL SPECIFICATIONS
196
A0K0750
