2014 Acura TL display

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom mark to about the
middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to the
upper zone. If it reaches the red
(hot) mark, pull saf ely to the side of
the road. Turn to page for
instructions and precautions on
checking the engine cooling system. If the pointer of the temperaturegauge reaches to or above the red
mark, you will also see the ‘‘WATER
TEMP HOT’’ message on the multi-
inf ormation display. This will alert
you that the engine should be cooled
down.
593
Temperature Gauge
Gauges
Inst rument s and Cont rols
77
12/07/20 10:39:34 31TK4640_082

Î
ÎYou can select the displayed
language and also customize some
vehicle control settings to your liking
with the multi-information display
and the three buttons on the steering
wheel (see page ).
When you unlock and open the
driver’s door, the display shows
‘‘DRIVER 1’’ or ‘‘DRIVER 2’’
depending on which remote
transmitter/keyless access remoteyou use, and the driver’s seat and the
outside mirrors move to the position
stored in that remote transmitter/
keyless access remote (see page
).
The driver’s ID (1 or 2) is displayed
when the power mode is set to ON.
The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably. Others help to keep
you aware of the periodic
maintenance your vehicle needs f or
continued trouble-f ree driving.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pagesand .
There are three types of messages:
normal display messages, engine oil
lif e and maintenance messages, and
system messages. :
184 187 79
170
On models with keyless access system
Normal Display Messages
Multi-Inf ormation Display
78
Remote transmitter/keyless
access remote 1 is used.
Remote transmitter/keyless
access remote 2 is used.
12/07/20 10:39:41 31TK4640_083

ÎÎ
Î
ÛÝ
Î
ÛÝ
These messages go of f af ter several
seconds.
With the ignition switch in the ON
(II) position, the multi-inf ormation
display changes as shown on pageeach time you press the INFO
( / ) button or the SEL/RESET
button.
When you turn the ignition switch
to the ON (II) position, your last
selection is displayed.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
If you do not f asten your seat belt,
you will also see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
inf ormation display when you turn
the ignition switch to the ON (II)
position.
These messages go of f several
seconds af ter the key is inserted into
the ignition switch. :
184 187 81
CONT INUED
On models with keyless access system
Multi-Inf ormation Display
Inst rument s and Cont rols
79
SEL/RESET BUTTON
INFO BUTTONS ( / )
A/T model is shown.
12/07/20 10:39:49 31TK4640_084

ÎIn the multi-information display, the
system message is also displayed
(see page ) and you can
customize your vehicle control
settings (see page ).In the normal display mode, the
upper segment displays trip
computer inf ormation, such as f uel
economy or average speed. The
lower segment displays the
odometer/trip meter (A/B), outside
temperature, and engine oil lif e and
maintenance item code(s).
The multi-inf ormation display
consists of an upper segment and a
lower segment. You will see some keyless access
system messages until you select the
ON mode by operating the engine
start/stop button. These messages
canbecustomized(seepage ).
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
184 187 89
94
110
On models with keyless access system
Multi-Inf ormation Display
80
LOWER
SEGMENT
U.S. model is shown. UPPER
SEGMENT
12/07/20 10:39:55 31TK4640_085

ÛÝ
Î
Î
Î Î
CONT INUED
Multi-Inf ormation Display
Inst rument s and Cont rols
81
U.S. model is shown.: Press the INFO button ( / ).
1:
2 : SH-AWD models only On models without navigation system only
This display will be shown when theBluetoothHandsFreeLinkis activated.
HFL
(See page 88)
Customized Settings
(See page 94)Trip Computer (See page 84)
Tire Pressure for
Each Tire
(See page 87) SH-AWD Torque
Distribution Monitor
(See page 87)
1
2
12/08/03 20:54:54 31TK4640_086

ÎÎThe odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial/
territorial regulations to disconnect,
reset, or alter the odometer with the
intent to change the number of miles
or kilometers indicated.
With the ignition switch in the ON
(II) position, the lower part of the
multi-inf ormation display changes as
shown in the illustration, each time
you press the SEL/RESET button.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
184 187
Multi-Inf ormation Display
Odometer
82
Canada
U.S.
ODOMETER
U.S. model is shown. : Press the SEL/RESET button.
12/07/20 10:40:07 31TK4640_087

This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.In the customizing mode, you can set
Trip A and average f uel economy A
to reset when you ref uel your vehicle
(see page ).
To reset a trip meter, display it, and
then press and hold the SEL/RESET
button until the number resets to
‘‘0.0.’’
When you reset Trip A, average f uel
economy A is reset at the same time.
When you reset Trip B, average f uel
economy B is reset. 105
Multi-Inf ormation Display
Trip Meter
Inst rument s and Cont rols
83
TRIP METER AU.S. Canada
TRIP METER B
12/08/03 20:55:00 31TK4640_088

This shows your instant f uel
economy.
This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset Trip A or Trip B.
You can customize the Trip A and
Average Fuel Economy A reset
condition on the multi-information
display (see page ).
Along with the trip meter, the trip
computer calculates these values:
Average Fuel Economy
Instant Fuel Economy
Range
Elapsed Time
Average Vehicle Speed
105
Multi-Inf ormation Display
INST A NT FUEL MPG (U.S.models)/INST A NT FUEL L /100 km(Canadian models)
A verage Fuel Economy A /BTrip Computer
84
U.S. model is shown.
INSTANT FUEL AVERAGE FUEL
ECONOMY A
