2014 Acura MDX TPMS

365
uuWhen DrivinguTire Pressure Monitoring System (TPMS) - Required Federal Explanation
Continued
Driving
Tire Pressure Monitoring System (TPMS) - Required Federal ExplanationEach tire, including the spare (if provided), should be checked
monthly when cold and inflated to the inflation pressure
recommended by the vehicle manufacturer on the vehicle placard
or tire inflation pressure label.
(If your vehicle has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with
a tire pressure monitoring system (TPMS) that illuminates a low
tire pressure telltale
when one or more of your tires is significantly under-inflated.
Accordingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate
them to the proper pressure.
Driving on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle’s
handling and stopping ability.

366
uuWhen DrivinguTire Pressure Monitoring System (TPMS) - Required Federal Explanation
Driving
Please note that the TPMS is not a substitute for proper tire
maintenance, and it is the driver’s responsibility to maintain
correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction
indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire
pressure telltale. When the system detects a malfunction, the
telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.
When the malfunction indicator is illuminated, the system may
not be able to detect or signal low tire pressure as intended.
TPMS malfunctions may occur for a variety of reasons, including
the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly.
Always check the TPMS malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS to
continue to function properly.

423
uuChecking and Maintaining TiresuTire and Wheel Replacement
Maintenance
Tire and Wheel ReplacementReplace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a
different size or construction can cause the ABS and VSA® (vehicle stability assist)
system to work incorrectly.
It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.
If you replace a wheel, only use TPMS specified wheels approved for your vehicle.
Make sure that the wheel’s specifications match those of the original wheels.
1Tire and Wheel Replacement
3
WARNING
Installing improper tires on your vehicle can
affect handling and stability. This can cause
a crash in which you can be seriously hurt or
killed.
Always use the size and type of tires
recommended in this owner’s manual.

437
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools
Types of Tools .................................. 438
If a Tire Goes Flat
Changing a Flat Tire
*....................... 439
Temporarily Repairing a Flat Tire
*..... 446
Engine Does Not Start
Checking the Engine ........................ 457
If the Keyless Access Remote Battery is
Weak ............................................. 458
Emergency Engine Stop ................... 459
Jump Starting.................................... 460
Shift Lever Does Not Move.............. 462Overheating
How to Handle Overheating............. 463
Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes
On ............................................. 465If the Charging System Indicator Comes
On ................................................. 465
If the Malfunction Indicator Lamp Comes
On or Blinks ................................... 466If the Brake System Indicator (Red) Comes
On .................................................... 467
If the Speed-Sensitive Electric Power Steering
(EPS) System Indicator Comes On ........... 467If the Low Tire Pressure/TPMS Indicator
Comes On or Blinks ....................... 468
Fuses
Fuse Locations ................................. 469
Inspecting and Changing Fuses ........ 474
Emergency Towing........................... 475
When You Cannot Unlock the Fuel Fill
Door................................................. 476When You Cannot Open the Tailgate
.. 477
* Not available on all models

445
uuIf a Tire Goes FlatuChanging a Flat Tire
*
Handling the Unexpected
1.Remove the center cap and place the flat
tire face up under the hoist.
2.Insert the hoist bracket into the center hole
of the flat tire.
3.Turn the wheel nut wrench with the jack
handle bar clockwise until the flat tire rests
against the underbody of the vehicle and
you hear the hoist click.
4.Securely put the jack and wheel nut wrench
back in the tool case. Store the case in the
cargo area.
If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator
comes on while you are driving. After driving for a few miles (kilometers), the
indicator will start blinking for a short time and then stay on. Tire Pressure
Monitor Problem appears on the multi-information display (MID), but this is
normal.
If you replace the tire with a specified regular tire, the warning message on the MID
and the low tire pressure/TPMS indicator will go off after a few miles (kilometers).
■Storing the Flat Tire
1Storing the Flat Tire
3
WARNING
Loose items can fly around the interior in a
crash and can seriously injure the
occupants.
Store the jack and tools securely before
driving.
Wheel Nut WrenchJack Handle Bar■TPMS and the Spare Tire
1TPMS and the Spare Tire
The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.
Use the TPMS specific wheels. Each is equipped with
a tire pressure sensor mounted inside the tire behind
the valve stem.

468
uuIndicator, Coming On/BlinkinguIf the Low Tire Pressure/TPMS Indicator Comes On or Blinks
Handling the Unexpected
If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
■Reasons for the indicator to come on or blink
A tire pressure is significantly low. If there is a problem with the TPMS or
the compact spare tire
* is installed, the indicator blinks for about one
minute, and then stays on.
■What to do when the indicator comes on
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.■What to do when the indicator blinks
Have the tire inspected by a dealer as soon as possible. If the compact
spare tire
* causes the indicator to blink, change the tire to a full-size tire.
The indicator goes off after driving for a few miles (kilometers).
1If the Low Tire Pressure/TPMS Indicator Comes On or BlinksNOTICEDriving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.
* Not available on all models

483Information
Devices that Emit Radio WavesThe following products and systems on your vehicle emit radio waves when in operation.Each of the above complies with the appropriate requirements or the required standards of
FCC (Federal Communications Commission) and Industry Canada Standard, described below:As required by the FCC:This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.This device complies with Industry Canada Standard RSS-Gen/210/310. Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.AcuraLinkAudio SystemBlind Spot Information SystemBluetooth® AudioBluetooth® HandsFreeLink®HomeLink® Universal TransceiverCollision Mitigation Braking System
TM
Immobilizer SystemRemote TransmitterKeyless Access SystemTire Pressure Monitoring System (TPMS)

495Index
Collision Mitigation Brake System
TM
(CMBS
TM) ................................................ 83
CRUISE CONTROL ............................. 78, 335
CRUISE MAIN.................................... 78, 334
Forward Collision Warning (FCW) ............. 80
High Beam ................................................ 76
Immobilizer System ................................... 77
Keyless Access System............................... 79
Lane Departure Warning (LDW) ................ 81
Lane Keeping Assist System (LKAS) ... 82, 354
Lights On .................................................. 77
Low Fuel ................................................... 73
Low Oil Pressure ............................... 71, 465
Low Tire Pressure/TPMS ............................ 76
Malfunction Indicator Lamp .............. 71, 466
Parking Brake and Brake System ....... 70, 467
Seat Belt Reminder.............................. 32, 73
Security System Alarm............................... 78
Shift Lever Position.................................... 72
Speed-sensitive Electric Power
Steering (EPS) System ...................... 76, 467
Super Handling-All Wheel Drive
TM
(SH-AWD®) ............................................. 79
Supplemental Restraint System ........... 51, 74
System Message ....................................... 78
Transmission ............................................. 72
Turn Signal ............................................... 76
Vehicle Stability Assist (VSA®)
System ............................................ 75, 358
VSA® OFF.......................................... 75, 359
Information.............................................. 479Instrument Panel........................................ 69
Brightness Control ................................... 153
Integrated Dynamics System (IDS)........... 333
IDS Button ............................................... 333
Interface Dial............................................ 203
Interior Lights........................................... 172
Interior Rearview Mirror.......................... 158
JJack (Wheel Nut Wrench)........................ 443
Jump Starting........................................... 460KKey Number Tag....................................... 116
Keyless Access System............................... 118
Keyless Lockout Prevention..................... 121
Keys........................................................... 115
Lockout Prevention .................................. 121
Number Tag ............................................ 116
Rear Door Won’t Open ............................ 126
Remote Transmitter ................................. 117
Two-way Keyless Access Remote ............. 115
Types and Functions ................................ 115
Kickdown (Automatic Transmission)....... 328LLane Departure Warning (LDW).............. 350
Indicator .................................................... 81Lane Keeping Assist System (LKAS)......... 353
Indicator.................................................... 82
Language (HFL)........................................ 269
LATCH (Child Seats).............................. 59, 62
LED Puddle Light...................................... 120
Lights................................................. 145, 407
Automatic ............................................... 146
Bulb Replacement ................................... 407
Daytime Running Lights........................... 148
High Beam Indicator .................................. 76
Interior .................................................... 172
Light Switches ......................................... 145
Lights On Indicator .................................... 77
Turn Signals ............................................ 144
LKAS (Lane Keeping Assist System)......... 353
Load Limits................................................ 307
Locking/Unlocking.................................... 115
Auto Door Locking/Unlocking.................. 127
Childproof Door Locks............................. 126
From Inside ............................................. 124
From Outside .......................................... 117
Keys ........................................................ 115
Using a Key ............................................. 121
Lockout Prevention System..................... 121
Low Battery Charge................................. 465
Low Fuel Indicator...................................... 73
Low Oil Pressure Indicator................. 71, 465
Lower Anchors...................................... 59, 62
Lubricant Specifications Chart................. 481
Luggage (Maximum Load Limit)............. 307
Lumbar Support....................................... 161
