2014.5 Citroen C5 RHD navigation system

04
271
NAVIGATION - GUIDANCE
Select:
-
"V
isual alert"
-

"Audible alert"
-


"Alert only in guidance"
-


"Overspeed alarm only".
The choice of time of notification defines
how long in advance that Risk area
warnings are given.
Select "

OK" to confirm the screen.
Select "Guidance options
" and confirm,
then select "Set parameters for risk
areas " and confirm. These functions are only available if risk areas have been
downloaded and installed on the system.
The detailed procedure for updating risk area POIs can be found at
http://citroen.navigation.com.
Press N AV
to display the "Navigation -
guidance" menu.
Settings for risk area / danger area alerts

04
273
Route options
Calculation criteriaSelect "Guidance options " and confirm.
Select "OK" and confirm to save
the
modifications.
Select "Define calculation criteria" and
confirm.
This function allows modification of:
-

the guidance criteria: ("Fastest
route

", "Shortest route",
"Distance/Time"),
-

the exclusion criteria: ("W

ith tolls"
or "With Ferry"),
-

traffic avoidance: ("
Traffic info").
Press N AV
to display the
"Navigation - guidance " menu.
If traffic avoidance (Traffic info) is selected, the system suggests
an alternative route if there is a delay on the guidance route.
NAVIGATION - GUIDANCE

04
274Press N AV
to display the
"Navigation - guidance " menu.
Map management
Selecting the points of interest displayed on the map
Select "Map management" and confirm. Select from the various categories
the
ones that you want to display on
the
screen.
Select "Map details" and confirm. Select "Default" to have only "Filling stations, garages
" and
"Risk areas " appear on the map (if installed in the system).
Select "OK" then confirm and select
"OK" again then confirm to save
the
modifications.
NAVIGATION - GUIDANCE

04
277
Male voice

/ Female voice
Press SETUP to display the
configuration menu.
Select "Select male voice" or "Select
female voice" then confirm "Ye s "
to activate a male or female voice.
The

system restarts.
Select "Voice synthesis" and confirm.
NAVIGATION - GUIDANCE

05
279
Configure the filtering and display of TMC messages
TMC (Traffic Message Channel) messages with GPS Navigation provide traffic information in real time.Press the TRAFFIC button to display the
"Traffic information" menu.
Select the "Geographic filter" function
and confirm. The system offers a choice of:
-

"
Retain all the messages",
or
-

"
Retain the messages"
●

"
Around the vehicle", (confirm
the mileage to modify and select
the distance),
●

"
On the route".
Confirm "OK" to save the modifications.
We recommend:
-

a filter on the route and
-


a filter around the vehicle of:
-


12 miles (20 km) in urban areas,
-


30 miles (50 km) on motorways.
TRAFFIC INFORMATION

306The following table groups together the answers to the most frequently asked questions concerning your audio system.
FREQUENTLY
ASKED QUESTIONS
QUESTION ANSWER SOLUTION
The route calculation is
not successful. The guidance criteria may conflict with the current location (exclusion of
toll roads on a toll motorway). Check the guidance criteria on the Navigation
Menu, "Guidance options"\ "Define calculation
criteria".
I am unable to enter my
post code. The system only accepts post codes of up to 7 characters.
The POIs do not appear. The POIs have not been selected. Select the POIs in the list of POIs.
The risk areas audible
warning does not work. The audible warning is not active.
Activate audible warnings in the Guidance options
menu, "Navigation - guidance", "Set parameters
for risk areas".
The system does not
suggest a detour around
an incident on the route. The guidance criteria do not take account of TMC messages.
Select the "Traffic info" function in the list of
guidance criteria.
I receive a Risk area alert
which is not on my route. Other than guidance, the system announces all Risk areas positioned in a
cone located in front of the vehicle. It may provide an alert for a Risk area
located on nearby or parallel roads. Zoom in on the map to view the exact position of
the Risk area. Select "On the route" to no longer
receive alerts other than guidance or to reduce the
time for the announcement.

05
320
USB PLAYER
The system puts together playlists (temporary memory) created
over a period which depends on the capacity of the USB device.
The other sources are available during this time.
The playlists are updated each time the ignition is switched off or
each time a USB memory stick is connected.
When connecting for the first time, the classification suggested
is by folder. When you reconnect, the classification selected
previously is retained.Connect the memory stick to the port, directly or
using a lead. If the audio equipment is switched
on, the USB source is detected as soon as it
is connected. Play begins automatically after a
delay which depends on the capacity of the USB
memory stick.
The file formats supported are .mp3

(mpeg1 layer 3 only) and .wma (standard 9 only,
128 kbits/sec compression).
Certain playlist formats are supported (.m3u, ...)
On reconnection of the previous memory stick
used, play is resumed automatically with the last
track played.
This unit consists of a USB port and an auxiliary
Jack socket*. The audio files are transmitted
from a portable device - digital player or a USB
memory stick - to your Audio system and heard
via the vehicle's speakers.
USB memory stick or Apple
® player of
generation 5 or later:
-

Use only USB memory sticks formatted
F

AT32 (File Allocation Table),
-

the

Apple
® player lead is essential,
-

navigation through the file database is also
possible by means of the steering mounted
controls.
Using the USB BOX
Connecting a USB memory stick
o

ther
a
pple
® players of earlier generations and
players using the MTP protocol*:
-

play via Jack-Jack lead only (not supplied),
-


navigation through the file database is from
the portable device. * Depending on vehicle.

334
Keeping children safe ..................16 2, 168 -182
Key in ignition warning ..................................99
K
ey with remote control
.................... 3
9 - 43, 97
Jack
........

.....................................................
192
JACK socket
................. 8
8, 298, 299, 320, 322
Identification plates
.....................................
25
6
Ignition
................
...........................................
97
Indicators, direction
.................................... 15
4
Inflating tyres
..............................
.......... 13, 256
Inputs for audio system
................
........ 88, 298, 299, 320, 322
Instrument panel lighting
..............................
25
In
strument panels
...............................
..........
15
Instrument panel screen
....................... 1
5, 120
Interior fittings
............................................... 86
I
nterior mood lighting
....................................
84
I
SOFIX mountings
....................................... 178
I
K
J
L
Labels, identification ...................................25 6
Lamps, warning and indicator ................26
-33
Lane Departure Warning System (LDWS)

....13

4Level, brake fluid

.........................................
2
37
Level, headlamp wash
................................
23
8
Level, power steering fluid
..........................
2
37
Levels and checks
..............................
.
2 3 2 - 2 41
Lighting
................
..........................................
84
Lighting bulbs (replacement)
..............
19
9 -209
Lighting control stalk
...................................
14
2
Lighting dimmer
..............................
..............
25
Lighting, guide-me home
....................
14
5, 146
Lighting, interior
............................................ 83
L
ighting on reminder
...................................
14
4
Loading
..............................
...........................
13
Load space cover
...............................
...........
93
Locating your vehicle
....................................
42
L
ocking from the inside
.................................
49
M
Main beam .............................. ............ 142, 199
Maintenance .............................. ...................13
Maintenance (advice)
.................................. 2

27
Map reading lamps

....................................... 83
M

arkings, identification
............................... 25

6
Massage function

...............................
..........60
Mat
.......

......................................................... 87
Menu, main

..............................
.............16, 316
Mirror, rear view

............................................ 64
M

irrors, door.................................................. 63
Misfuel prevention
...............................

........18 4
Mountings for ISOFIX seats
...............

.......................................... 178
MP3 CD

................
............................... 295, 319 Multifunction screen
......................................
34
M
usic media players
...................................
29
4
Navigation
...............................
....................
265
Number plate lamps
....................................
2
07
N
Oil change ...............................
....................235
Oil consumption .......................................... 23
5
oil

filter
...............
......................................... 239
oi

l level ..................................................23, 235
Oil temperature indicator

..............................24
O

pening the bonnet
.................................... 2

31
Opening the boot

..............................
............40
Opening the doors

...............................
... 39, 49
Opening the fuel filler flap

...........................18

3
Opening the panoramic sunroof blind

....5
5, 56
Opening the sunroof

..................................... 55
O

peration indicator lamps
......................26

-33
O
P
Paint colour code ........................................25 6
Paintwork, matt ........................................... 2
27
Panoramic glass sunroof

..............................56
alphabetical index
