2014.5 Citroen C4 AIRCROSS RHD ECO mode

188
Changing a fuse
The extraction tweezer and spare fuses are
fitted in the engine compartment fusebox.
To gain access to them:
F
O
pen the bonnet (refer to the "Checks"
section).
F

U
nclip the and remove the cover.
F

R
emove the tweezer.
F

C
arefully close the cover to ensure correct
sealing of the fusebox.
Access to the tools
Before changing a fuse, the cause of the failure
must be identified and rectified.
F

C
heck that the switch is in the " LOCK"
position or that the vehicle mode is " OFF".
F

I
dentify the failed fuse by checking the
condition of its filament.
F

U
se the special tweezer to extract the fuse
from its location.
F
a
l
ways replace the faulty fuse with a fuse
of the same rating.
F

C
heck that the number etched on the box,
the rating etched on the top and the tables
below all agree.
Changing a fuse
Good Failed
CITR
oËn
will not accept responsibility
for the cost incurred in repairing your
vehicle or for rectifying the malfunctions
resulting from the installation of
accessories not supplied and not
recommended by CITROËN and
not installed in accordance with its
instructions, in particular when the
consumption of all of the additional
equipment connected exceeds
10
mil

liamperes.
Your vehicle's electrical system is
designed to operate with standard or
optional equipment.
Before installing other electrical
equipment or accessories in your
vehicle, contact a CITROËN dealer or a
qualified workshop. The replacement of a fuse not
mentioned in the following tables may
cause a serious fault on your vehicle.
Contact a CITROËN dealer or a
qualified workshop.
Practical information

198
Recovering the vehicle
Recovery of your vehicle
2 wheel drive (2WD) versions: towing
with the wheels on the ground
F Put the gear lever into neutral (position N
for the CVT gearbox).
F

U
nlock the steering by by turning the
ignition switch to the " ON" position (or
to " ON " mode for vehicle fitted with the
"Keyless Entry and Starting" system).
F

R
elease the parking brake.
F

S
witch on the hazard warning lamps on
both vehicles.
F

M
ove off gently and travel slowly for a short
distance only.
General recommendations
Observe the legislation in force in your
c o unt r y.
Ensure that the weight of the towing
vehicle is higher than that of the towed
vehicle.
The driver must remain at the wheel of
the towed vehicle and must have a valid
driving licence.
When towing a vehicle with all four
wheels on the ground, always use an
approved towing bar; rope and straps
are prohibited.
When towing a vehicle with the engine
off, there is no longer any power
assistance for braking or steering.
In the following cases, you must always
call on a professional recovery service:
-

v
ehicle broken down on a motor way
or fast road,
-

4 w
heel drive vehicle,
-

w
hen it is not possible to put the
gearbox into neutral, unlock the
steering, or release the parking
brake,
-

t
owing with only two wheels on the
ground,
-

w
here there is no approved towing
bar available... Towing with the wheels on the ground
is only possible on 2 wheel drive (2WD)
versions.
F

F
it the towing bar to the towing eye on the
chassis, located under the front bumper.
Practical information

199
Vehicles fitted with the 4 wheel drive
system must always be recovered on a
flatbed.Never have the vehicle towed with the
four wheels on the ground, this could
damage the transmission.
The vehicle must not be towed with the
front or rear wheels on the ground even
if it is in front "2WD" (2 wheel drive)
mode.
4 wheel drive (4WD) versions: recovery on a flatbed
7
Practical information

221
PETROL ENGINES1.6 litre 115
Gearboxes Manual (5-speed)
Model codes: BU... NKZ0

NKZ0/S
Transmission mode 2WD
-

U
nladen weight 1 310
-

K
erb weight 1 385
-

G
ross vehicle weight (GV W) 1 870
-

G
ross vehicle weight (GV W) when towing 1 925
-

G
ross train weight (GTW)
o

n a 12% gradient 3 025
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 1 100
-

U
nbraked trailer 685
-

R
ecommended nose weight 55
For zones: Europe, Turkey, French overseas dominions and territories.
9
Technical data

222
For: Russia, Ukraine, Morocco, Argentina, Chile, French overseas dominions and territories (2.0 litre 150 engine).
PETROL ENGINES1.6 litre 1152.0 litre 150
Gearboxes Manual
(5 - speed) Manual (5-speed)
CVT (6- speed)
Model codes: BU... NKZ7AFZ7AFZM AFZHAFZP
Transmission mode 2WD2WD 4WD2WD 4WD
-

U
nladen weight 1 3151 355 1 4201 385 1 450
-

K
erb weight 1 3901 4301 4951 460 1 525
-

G
ross vehicle weight (GV W) 1 8701 9701 9701 9701 970
-

G
ross vehicle weight (GV W) when towing 1 9252 035 2 0352 0352 035
-

G
ross train weight (GTW)
o

n a 12% gradient 3 025
3 335 3 3353 3353 335
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 1 100
1 300 1 3001 3001 300
-

U
nbraked trailer 68571574 5725 750
-

R
ecommended nose weight 5565656565
Technical data

223
For: Australia, New-Zealand.
PETROL ENGINES2.0 litre 150
Gearboxes Manual (5-speed)CVT (6- speed)
Model codes: BU... AFZ7AFZM AFZHAFZP
Transmission mode 2WD4WD2WD 4WD
-

U
nladen weight 1 3501 4151 380 1 445
-

K
erb weight 1 4251 490 1 455 1 520
-

G
ross vehicle weight (GV W) 1 9701 9701 9701 970
-

G
ross vehicle weight (GV W) when towing 2 0352 0352 0352 035
-

G
ross train weight (GTW)
o

n a 12% gradient 3 020
3 0203 0203 020
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 1 050
1 0501 0501 050
-

U
nbraked trailer 750750750750
-

R
ecommended nose weight 65656565
9
Technical data

224
For: South Africa.
PETROL ENGINES2.0 litre 150
Gearboxes Manual (5-speed)CVT (6- speed)
Model codes: BU... AFYRAFYV AFYTAFYW
Transmission mode 2WD4WD2WD 4WD
-

U
nladen weight 1 3501 4151 390 1 455
-

K
erb weight 1 4251 490 1 4651 530
-

G
ross vehicle weight (GV W) 1 9701 9701 9701 970
-

G
ross vehicle weight (GV W) when towing 2 0352 0352 0352 035
-

G
ross train weight (GTW)
o

n a 12% gradient 3 075
3 0752 760 2 760
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 1 050
1 050 750750
-

U
nbraked trailer 1 0501 050 750750
-

R
ecommended nose weight 65656565
Technical data

225
* Vehicle not for towing.
For other countries of sale.
PETROL ENGINES2.0 litre 150
Gearboxes Manual (5-speed)CVT (6- speed)
Model codes: BU... AFYR

AFZ7 AFYV

AFZM AFYT

AFZH AFYW

AFZP
Transmission mode 2WD4WD2WD 4WD
-

U
nladen weight 1 3401 405 1 3701 435
-

K
erb weight 1 4151 480 1 445 1 510
-

G
ross vehicle weight (GV W) 1 9701 9701 9701 970
-

G
ross vehicle weight (GV W) when towing 2 0352 0352 0352 035
-

G
ross train weight (GTW)
o

n a 12% gradient 2 655
2 655 -*-*
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 650
650 -*-*
-

U
nbraked trailer 650650 -*-*
-

R
ecommended nose weight 6565 -*-*
9
Technical data
