2013 VOLVO XC60 navigation

06 Infotainment
Introduction
06

* Option/accessory, for more information, see Introduction.215 Infotainment system overview
Sockets for external audio sources (AUX
and USB)
Steering wheel keypad
7" display
Center console control panel
Rear seat control panel with headphone
socket*
Not in use
Basic infotainment functions
Infotainment controls in the center console
Corresponding controls - keypad and center con-
sole
SOUND: press to access the menu for
adjusting bass, treble, etc., see page 220
for additional information.
VOL: turn to raise or lower the volume level.
ON/OFF/MUTE: short press - switch
the system ON. Press and hold (until the
screen turns black) - switch the system
OFF. A short press when the infotainment
system is on will mute/unmute the sound.
The entire infotainment system, including
the navigation* and telephone functions, is
switched on/off at the same time by using
this button.
Mode buttons: select a mode (e.g.,
RADIO, MEDIA, TEL, etc.) by pressing its
button on the center console. The most

06 Infotainment
Introduction
06
216* Option/accessory, for more information, see Introduction.
recent source in the selected mode (e.g.,
FM1) will be displayed. The location of
these buttons on the center console may
vary slightly from model to model.
OK/MENU: confirm a menu selection. This
leads to the selected mode’s (RADIO,
MEDIA) menu view. Arrows at the right of
the screen indicate submenus.
TUNE: turn to scroll among tracks/folders,
radio stations, phone contacts or to navi-
gate among the alternatives shown on the
screen.
EXIT: short press - go upward in the menu
system, cancel a current function, reject an
incoming phone call or erase characters
that have been entered on the screen.
Press and hold - from a mode’s main view
to come to the infotainment system's main
view, see page 218.
# INFO: if more information is available
than is currently displayed on the screen,
press # INFO to display the remaining
information.
Keypad (for preset stations, entering let-
ters or numbers, etc).
* FAV: this button can be used to store a
shortcut to a commonly used function in
AM/FM/SIRIUS/DISC, etc. See the section"* FAV—storing a shortcut" on page 220
for information on using this button.
Steering wheel keypad
The buttons on the right-hand steering wheel
keypad can be used in the same way as some
of the controls on the center console. There are
two versions of the keypad, depending on your
vehicle's specifications.
Left/right arrow keys: a short press moves
between preset radio stations or tracks on
a disc. Press and hold to search within
tracks or to tune to the next/previous
strong radio station.
Volume
EXIT: a short press takes you upward in
the menu system, cancels a current func-
tion, rejects an incoming phone call or era-
ses characters that have been entered on
the screen. Press and hold from a mode’s
main view to come to the infotainment sys-
tem's main view.
Thumb wheel: pressing functions in the
same way OK/MENU on the center con-
sole. Turning the thumb wheel functions in
the same way as TUNE on the center con-
sole.
Voice button: 2 press to voice-activate cer-
tain functions on a BluetoothŸ-connected
cell phone and the navigation system.
Main view
From a mode’s normal view, pressing and
holding EXIT will display the infotainment sys-
tem's main view, which enables you to select
a mode.
NAV: Navigation system*
RADIO
2Models with the optional navigation system only. On models without navigation, this button mutes/unmutes the infotainment system.

06 Infotainment
Introduction
06
218
Menu navigation
An example of menu navigation in MEDIA mode when a CD is playing

06 Infotainment
Introduction
06

223 MEDIA menus
Main CD Audio menuDisc menu
Random
Scan
Audio settings8
Main CD/DVD11 Data menuDisc menu
Play/Pause
Stop
Random
Repeat folder
Change subtitles
Change audio track
Scan
Audio settings8
Main DVD11 Video menuDVD Video Menu
DVD disc menu
Play/Pause/ContinueStop
Subtitles
Audio tracks
Advanced settings
Angle
DivX® VOD code
Audio settings8
Main iPod menuiPod menu
Random
Scan
Audio settings8
Main USB menuUSB menu
Play/Pause
Stop
Random
Repeat folder
Select USB device
Change subtitlesChange audio track
Scan
Audio settings8
Main AUX menuAUX menu
AUX input volume
Audio settings8
TEL menus
Main Bluetooth media menuBluetooth menu
Random
Change device
Remove Bluetooth device
Scan
Bluetooth software version in car
Audio settings8
8The audio settings are the same for all infotainment system modes11The media player can only play DVDs in models equipped with the optional navigation system.

06 Infotainment
Radio
06
* Option/accessory, for more information, see Introduction.225 General functions
RADIO button for selecting the AM, FM1,
FM2, SAT1* or SAT2* wavebands.
Keypad (buttons 0-9)
Navigate among the menu alternatives in
the display by turning TUNE or the thumb
wheel on the steering wheel keypad.
Confirm your selection or access the radio
menus by pressing OK/MENU or the
thumb wheel on the steering wheel key-
pad.
Left/right arrow keys: Press and hold to go
to the next/previous strong station, press
briefly to tune to a preset station.
Menu navigationRADIO menu selections can be made from the
center console or the steering wheel keypad,
see page 216 for more information.
Selecting a station (in wavebands AM/
FM1/FM2)
Automatic tuning
1.
Press RADIO, turn TUNE to toggle to the
desired waveband (AM, FM1, etc.) and
press OK/MENU or the thumb wheel on
the steering wheel keypad.
2.
Press
/ keys on the center console
control panel or steering wheel keypad to
search for the next available station.
List of stations (in wavebands FM1/FM2
only)
The radio automatically compiles a list of the
strongest FM stations whose signals are cur-
rently being received. This enables you to find
stations when driving in areas where radio sta-
tions and their frequencies are unfamiliar.
To access this list:
1.
Select the desired waveband (
FM1 orFM2).
2.
Turn TUNE slightly in either direction. This
displays the list of stations in the area. Thecurrently tuned station will be indicated in
the list by magnified text.
3.
Turn TUNE again in either direction to
select a station on the list.
4.
Confirm by pressing OK/MENU or the
thumb wheel on the steering wheel key-
pad.
NOTE
•This list will only display the frequencies
of the stations currently being received,
not a complete list of all radio frequen-
cies on the currently selected wave-
band.
•If the signal from the currently tuned
station is weak, this may prevent the
radio from updating the list of stations.
If this occurs, press
while the list
of stations is displayed to switch to
manual tuning mode and select a sta-
tion. If the list of stations is no longer
displayed, turn TUNE in either direction
to display the list again and press
.
The list will disappear from the display after
several seconds.
If the station list is no longer displayed, turn
TUNE in either direction and press
on the

06 Infotainment
Media player
06
234
CD/DVD1 functions
Center console control panel
Disc slot
MEDIA button, the most recently used
active source will start when MEDIA is
pressed. Pressing this key from Media
mode's main view will display a shortcut
menu.
Eject
Keypad
TUNE:Turn to navigate among menu
selections/folders/tracks (or turn the
thumb wheel on the steering wheel key-
pad).
OK/MENU: Press to confirm your selec-
tion or access the menus for the currently
selected source (e.g.,
Disc) or press the
thumb wheel on the steering wheel key-
pad.
Left/right arrow keys: Fast back/forward
and change track or chapter2.
The media player supports and can play the
following main types of discs and files:
•Purchased CDs (CD Audio)
•Home-burned CDs with audio and /or
video files
•Home-burned DVDs with audio and /or
video files
•Purchased DVDs
For a list of compatible formats, see
page 237.
Media menu selections can be made from the
center console or the steering wheel keypad.
For more information about the infotainment
menu system, see page 216.
For general information regarding menu navi-
gation, see page 218 and menu overview see
page 222.
Playing a disc
Press MEDIA ans scroll to Disc. Press OK/
MENU or the thumb wheel on the steering
wheel keypad. If there is a disc in the player, it
will begin playing automatically. Otherwise,
Insert disc will be displayed. Insert the disc
into the slot with the text side upward and it will
begin playing automatically.
If a disc with audio/video files is inserted, its
folder structure will be read by the system. It
may take several seconds until the disc begins
playing, depending on its quality and the
amount of information it contains.
Disc ejectFor reasons of traffic safety, an ejected disc
must be removed within 12 seconds or it will
be automatically drawn back into the slot.
PauseWhen the infotainment system volume is
turned off completely or the sound is muted,
the player will pause. It will resume playing
when the volume is turned up again or if the
sound is unmuted. Pause is also available via
the menu system, select
Play/Pause.
1The media player can only play DVDs in models equipped with the optional navigation system.2DVDs only

06 Infotainment
BluetoothŸŸ media
06
241 Introduction
The vehicle's media player is equipped with
BluetoothŸ and can play streaming audio files
from a BluetoothŸ device such as a cell phone
or mp3 player. Navigation and control of the
device can be done through the vehicle's cen-
ter console control panel or the steering wheel
keypad. On certain external devices, it is also
possible to change tracks from the device.
NOTE
Any Bluetooth cell phones used must sup-
port Audio/Video Remote Control Profile
(AVRCP) and Advanced Audio Distribution
Profile (A2DP). The phone must use AVRCP
version 1.3 and A2DP 1.2. If older versions
of these standards are used, certain fea-
tures (e.g., scan or random) may not func-
tion.
Not all cell phones are fully compatible with
the vehicle's Bluetooth system. A list of
compatible phones is available at you Volvo
retailer or at www.volvocars.us.
Menu navigation
Choices can be made in the Bluetooth menus
from the center console control panel or the
steering wheel keypad. For additional informa-
tion about navigating the various menus, see
page 216.The vehicle's media player can only play audio
files through the Bluetooth
Ÿ function.
Overview
Center console control panel
VOL: Volume control
MEDIA button, the most recently used
active source will start when MEDIA is
pressed. Pressing this key from Media
mode's main view will display a shortcut
menu.
TUNE: Turn to navigate among menu alter-
natives and folders shown in the display.
OK/MENU: Press to confirm your selec-
tion or access the menus.
EXIT: Press to go back in the menu struc-
ture or cancel a function.
Left/right arrow keys: Short press: change
tracks. Long press: fast forward/reverse
within a track. The arrow keys on the steer-
ing wheel keypad can be used in the same
way.
Pairing and connecting an external
device
Before an external device can be connected, it
must be paired to the infotainment system. The
procedure for connecting an external device
varies, depending whether or not the device
has previously been paired to the infotainment
system. A maximum of 10 external devices can
be paired and each device only needs to be
paired once. To pair a device, see page 244.
Automatic connection
When the BluetoothŸ function is active and the
most recently used device is within range, it is
automatically connected. When the infotain-
ment system searches for the most recently
used device, its name is shown in the display.
To connect another paired device, press EXIT.
See the following section for information about
switching to another device.

06 Infotainment
Bluetooth® hands-free connection
06
243 Introduction
This feature makes it possible to set up a wire-
less connection between a BluetoothŸ-ena-
bled cell phone or other device and the vehi-
cle’s infotainment system. This enables the
infotainment system to function as a hands-
free connection and allows you to remote-con-
trol a number of the phone’s functions. The
microphone used by this system is located
near the driver's side sun visor (2). The buttons
and other controls on the cell phone can
always be used regardless of whether or not
the phone is connected to the hands-free sys-
tem.
NOTE
Not all cell phones are fully compatible with
the hands-free system. A list of compatible
phones is available at your Volvo retailer or
at www.volvocars.us
WARNING
Never use the hands-free feature or any
other device in your vehicle in a way that
distracts you from the task of driving safely.
Distraction can lead to a serious accident.
Compliance
FCC/IC common sentence
This device complies with Part 15 of FCC Rules
and RSS-Gen of IC Rules. Operation is subject
to the following two conditions: (1) this device
may not cause interference, and (2) this device
must accept any interference, including inter-
ference that may cause undesired operation of
this device.
USA: FCC ID A269ZUA130
FCC WARNING
Changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user’s authority to operate
the equipment.
IC RSS-GenThis equipment complies with FCC/IC radia-
tion exposure limits set forth for uncontrolled
equipment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to
OET65 and RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment has very
low levels of RF energy that it deemed to com-
ply without maximum permissive exposure
evaluation (MPE). But it is desirable that it
should be installed and operated with at least
8 in. (20 cm) and more between the radiator
and person’s body (excluding extremities:
hands, wrists, feet and ankles).Canada: IC 700BIAM2101
Menu navigationTEL menu selections can be made from the
center console or the steering wheel keypad.
For additional information about navigating the
various menus, see page 216.
System overview
Cell phone
Location of the microphone
Steering wheel keypad
Center console control panel and display
