09 Maintenance and specifications
Replacing bulbs 09
320* Option/accessory, for more information, see Introduction.
Introduction
All bulb specifications are listed on page 326.
The following bulbs should only be replaced by
a trained and qualified Volvo service techni-
cian:
•Dome lighting
•Reading lights
•Glove compartment lighting
•Footwell lighting
•Turn signals in the door mirrors
•Approach lighting in the door mirrors
•Brake lights
•Active Bending Lights and LED bulbs
NOTE
For information regarding any other bulbs
not mentioned in this section, please con-
tact your Volvo retailer or a trained and
authorized Volvo service technician.
WARNING
•The engine should not be running when
changing bulbs.
•If the engine has been running just prior
to replacing bulbs in the headlight hous-
ing, please keep in mind that compo-
nents in the engine compartment will be
hot.
WARNING
•Active Bending Lights* – due to the high
voltage used by these headlights, these
bulbs should only be replaced by a
trained and qualified Volvo service tech-
nician.
•Turn off the lights and remove the
remote key from the ignition before
changing any bulbs.
Headlight housing
G010325
The entire headlight housing must be lifted out
when replacing all front bulbs.
CAUTION
Never touch the glass of bulbs with your fin-
gers. Grease and oils from your fingers
vaporize in the heat and will leave a deposit
on the reflector, which will damage it.

09 Maintenance and specifications
Replacing bulbs09
321
NOTE
•Always switch off the ignition before
starting to replace a bulb.
•The optional Active Bending Light bulbs
contain trace amounts of mercury.
These bulbs should always be disposed
of by a trained and qualified Volvo serv-
ice technician.
Removing the headlight housing1. Switch off the ignition by briefly pressing
the START/STOP ENGINE button.
2. Remove the remote key from the ignition
slot
1.
3. (Upper illustration under "Headlight hous-
ing")
Withdraw the headlight housing's lock-
ing pins.
Pull the headlight housing straight out.
CAUTION
When disconnecting the connector, pull on
the connector itself and not on the wiring.
4. (Lower illustration under "Headlight hous-
ing")
Unplug the wiring connector by holding
down the clip with your thumb.
Pull out the connector with the other
hand.
5. Lift out the housing and place it on a soft
surface to avoid scratching the lens.
6. Replace the defective bulb(s).
Reinserting the headlight housing1. Plug in the connector until it clicks into
place.
2. Reinstall the headlight housing and locking
pins. Check that they are correctly
inserted. The headlight housing must be
properly inserted and secured in place
before the lighting is switched on or the
remote key is inserted into the ignition slot.
3. Check that the lights function properly.
Removing the cover to access the
bulbs
G021745
NOTE
Before starting to replace a bulb, see
page 320.
1. Open the retaining clamp by pressing it to
the side.
2. Press down the clips on the upper edge of
the cover and remove it.
Reinstall the cover in the reverse order.
1Does not apply to vehicles with the optional keyless drive.

09 Maintenance and specifications
Replacing bulbs 09
322
Low beam, Halogen
G021746
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the cover over the bulbs (see
page 321).
3. Unplug the connector from the bulb.
4. Remove the bulb by pressing the holder
downward.
5. Press the new bulb into the socket until it
snaps into place. It can only be secured in
one position.
6. Put the cover back into position and rein-
stall the headlight housing.
High beam, Halogen
G021747
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the cover over the bulbs (see
page 321).
3. Remove the bulb by turning it counter-
clockwise and pulling it straight out.
4. Remove the connector from the bulb.
5. Press the new bulb into the socket and turn
it clockwise to put it in place. It can only be
secured in one position.
6. Reinsert the bulb holder into the headlight
housing.
7. Put the cover back into position and rein-
stall the headlight housing.
Extra high beam2
G021748
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the cover over the bulbs (see
page 321).
3. Remove the bulb by pressing the holder
downward.
4. Remove the connector from the bulb.
5. Insert a new bulb in the connector until it
snaps in place. It can only be inserted in
one way.
6. Return the bulb holder into position in the
headlight housing.
7. Put the cover back into position and rein-
stall the headlight housing.
2Models with optional Active Bending Lights only.

09 Maintenance and specifications
Replacing bulbs09
323 Parking lights
G021749
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the cover over the bulbs (see
page 321).
3. To access the bulb, first remove the high
beam bulb.
4. Pull the wire to withdraw the bulb holder.
5. Remove the burned out bulb and install a
new one. It can only be secured in one
position.
6. Press the bulb holder into the socket and
press until it clicks into place.
7. Put the cover back into position and rein-
stall the headlight housing.
Turn signals
G021750
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the round cover by pulling the tab
until the cover comes off.
3. Pull out the holder to access the bulb.
4. Remove the burned out bulb by pressing it
in slightly and turning out before pulling it
out. Press a new bulb into the socket.
5. Press the bulb holder into the socket and
press until it clicks into place.
6. Press the cover until it clicks into position.
7. Reinstall the headlight housing.
Side marker lights
NOTE
Before starting to replace a bulb, see
page 320.
G021751
1. Remove the headlight housing from the
vehicle (see page 320).
2. Remove the round cover.
3. Pull the wire to withdraw the bulb holder.
4. Pull out the burned out bulb and install a
new one. It can only be secured in one
position.
5. Press the bulb holder into the socket and
press until it clicks into place.
6. Press the cover until it clicks into position.

11 Index
11
361
Bulbs
headlights...........................320, 321, 322
introduction......................................... 320
license plate lights.............................. 325
side marker lights...............................323
specifications...................................... 326
trunk lighting....................................... 325
C
Camera, Park Assist................................ 172
Capacity weight....................................... 293
Catalytic converter................................... 270
Cell phone, hands-free connection......... 239
Cell phone voice control.......................... 247
Central locking system, introduction......... 52
Chains...................................................... 296
Check engine light..................................... 76
Check Engine warning light....................... 77
Child restraints
recalls and registration......................... 38
Child restraint systems.............................. 39
booster cushions.................................. 45
convertible seats.................................. 43
infant seats........................................... 41ISOFIX/LATCH anchors........................ 46
top tether anchors................................ 47
Child safety................................................ 36
booster cushions.................................. 45
child restraint systems.......................... 39
convertible seats.................................. 43
infant seats........................................... 41
Child safety locks...................................... 48
City Safety™............................................ 148
Climate system........................................ 197
air distribution............................. 192, 198
air vents.............................................. 193
Interior Air Quality System.................. 192
introduction......................................... 191
passenger compartment filter............ 192
refrigerant........................................... 191
Clock, setting............................................. 80
Cold weather driving................................ 266
Collision warning system.................154, 155
Compass in rearview mirror..................... 105
Conserving electrical current................... 265
Controls, center console.......................... 211
Convertible seats....................................... 43
Coolant............................................318, 354
Cooling system, general information....... 265Courtesy lighting.................................. 97, 98
Crash event data......................................... 9
Crash mode............................................... 35
Cruise control..................................132, 133
adaptive.............................................. 134
Curb weight............................................. 293
Current, conserving................................. 265D
Defroster.................................................. 197
Detachable key blade..........................57, 60
Disconnecting the front passenger’s air-
bag....................................................... 26, 27
Dome lighting....................................... 97, 98
Door mirrors............................................. 103
Driver alert............................................... 162
Driver distraction warning.......................... 13
Driving economically................................ 264
Driving in cold weather............................ 266
Driving through water..............................265

11 Index
11
363
Headlights
Active Bending Lights........................... 94
active high beams................................. 93
changing bulbs...........................321, 322
high/low beams.................................... 91
high beam flash.................................... 92
tunnel detection.................................... 94
Headlight washers................................... 100
Headphones............................................ 252
Head restraints, rear seat.......................... 87
Heated front seats................................... 194
Heated oxygen sensors........................... 271
Heated rear seats.................................... 195
High beams................................................ 91
active.................................................... 93
indicator light........................................ 77
Hoisting the vehicle.................................313
HomeLink
® Wireless Control System...... 108
Home safe lighting..................................... 98
Hood, opening/closing............................315
Horn........................................................... 90
I
Ignition modes........................................... 82
Immobilizer................................................ 54
Important information.................................. 6
Indicator lights.........................75, 76, 77, 78
Infant seats................................................ 41
Inflatable Curtain........................................ 32
Inflation pressure..................................... 287
Inflation pressure table............................289
Information and warning symbols, table
of.............................................................. 356
Information lights.....................75, 76, 77, 78
Information symbol.................................... 77
Infotainment
Menu navigation................................. 214
Infotainment system................................ 210
AUX/USB sockets............................... 234
Bluetooth
Ÿ devices............................. 237
Bluetooth® hands-free system........... 239
getting started.................................... 211
media player....................................... 230
menus.........................................211, 214
radio functions.................................... 221
rear seat entertainment....................... 251rear seat entertainment system, remote
control................................................. 260
sound settings.................................... 216
voice control....................................... 247
Inspection readiness................................ 313
Instrument lighting..................................... 91
Instrument overview............................74, 75
Instrument panel...................................... 183
Interior Air Quality System....................... 192
Interior lighting..................................... 97, 98
iPodŸ connector (audio system)............. 234
ISOFIX/LATCH anchors............................. 46
J
Jack
attaching.............................................304
location of........................................... 304
Jump starting........................................... 114

11 Index
11
367
storing................................................. 286
studded............................................... 296
tire pressure monitoring system......... 307
tire sealing system.............................. 298
tread wear indicator............................ 285
uniform tire quality grading................. 295
Tire sealing system.................................. 298
Top tether anchors (child restraint sys-
tems).......................................................... 47
Touching up paint.................................... 343
Towing a trailer................................275, 276
trailer hitch.......................................... 276
Towing the vehicle................................... 278
Traction control........................................ 128
Trailer towing...................................275, 276
trailer hitch.......................................... 276
Transmission
general description.....................116, 117
oil........................................................ 354
shiftlock override................................ 118
Tread wear indicator................................ 285
Trip computer.......................................... 200
Trip odometers.......................................... 80
Trips, long distance................................. 265Trunk
changing bulbs................................... 325
driving with it open.............................264
Tunnel detection........................................ 94
Turn signals............................................... 96
changing bulbs................................... 323
indicator lights...................................... 77
U
Uniform Tire Quality Grading...................295
Unlocking the vehicle..........................55, 64
Upholstery care....................................... 341
V
Valet locking.............................................. 60
Vanity mirror............................................ 205
changing bulbs................................... 325
Vehicle Event Data....................................... 9
Vehicle loading................................272, 293
roof loads............................................ 274
Vehicle maintenance................................ 312
performed by the owner.....................313Vehicle weights........................................ 351
Ventilated seats....................................... 194
Voice control
cell phones......................................... 247
Volvo and the environment........................ 12
Volvo maintenance.................................. 312
Volvo On Call Roadside Assistance........ 359
Volvo programs.......................................359
Volvo Sensus........................................... 182
W
Warning flashers, hazard........................... 96
Warning lights.......................... 75, 76, 77, 78
Warning symbol......................................... 79
Warning system, collision................154, 155
Warranties................................................ 312
Washer fluid..................................... 328, 354
Washers
headlight............................................. 100
windshield............................................. 99
Water, driving through............................. 265
Waxing..................................................... 341
