2013 VOLVO S60 set clock

02 Locks and alarm
Locks
02
67
can be turned on or off by pressing MY CAR
and going to Car settings
Lock settings
Automatic door locking. See page 189 for
a description of the menu system.
Glove compartment
The glove compartment can only be locked
and unlocked using the detachable key blade
in the remote key. See page 57 for information
on removing the key blade from the remote
key.
Insert the key blade in the glove compart-
ment lock.
Turn the key blade 90 degrees clockwise.
Remove the key blade from the lock.
Opening the trunk manually
The trunk is held closed by an electronic lock-
ing mechanism. To open:
1. Press lightly on the rubberized plate under
the handle to release the lock.
2. Lift the handle to open the trunk lid.
CAUTION
•When pressing the rubberized plate,
only light pressure is necessary to
release the trunk's electronic locking
mechanism.
•When opening the trunk lid, pull it up
using the handle. Too much pressure on
the rubberized plate can damage its
electrical connections.
Locking/unlocking the trunk
Trunk unlock button on the remote key
Unlocking the trunk with the remote key–Press the trunk unlock button on the
remote.
Press once: This unlocks but does not open
the trunk. The trunk can then be opened by
pressing the rubber plate near the trunk lock. If
the trunk is not opened within two minutes it
will automatically relock and the alarm will be
rearmed.
Press twice: This both unlocks the trunk and
pops it open slightly.
NOTE
Any excess weight (snow, etc.) on the trunk
lid may prevent it from opening.

03 Your driving environment
Instruments and controls
03
82
Reminder – doors not closedIf one of the doors, the hood or trunk lid is not
closed properly, the information or warning
symbol comes on together with an explanatory
text message in the instrument panel. Stop the
vehicle in a safe place as soon as possible and
close the door, hood or trunk.
If the vehicle is driven at a speed
lower than approximately 5 mph
(7 km/h), the information symbol comes on.
If the vehicle is driven at a speed
higher than approximately 5 mph
(7 km/h), the warning symbol comes on.
Road Sign Information (RSI)Road Sign Information (RSI) is a feature that
helps the driver see road signs with information
such as current speed. See page 133 for
detailed information.
Trip odometers
Trip odometers and reset button
Odometer display
Button for toggling between T1 and T2,
and for resetting the odometer
The trip odometers are used to measure short
distances. The distance is shown in the dis-
play. A short press the button toggles between
the two trip odometers
T1 and T2. A long press
(more than 2 seconds) resets the currently dis-
played trip odometer to zero.
Clock
Clock and setting control
Display
Control for setting the clock
Turn the control clockwise/counterclockwise
to set the time. The set time is shown in the
information display.
The clock may be temporarily replaced by a
symbol in conjunction with a message, see
page 187.
Setting the clock in MY CARIn addition to setting the clock manually as
described above, it can also be set in the MY
CAR menu system. See page 189 for addi-
tional information about these menus.

05 Comfort and driving pleasure
Volvo Sensus
05
186* Option/accessory, for more information, see Introduction.
Introduction
Center console control panel
Volvo Navigation System (VNS)* – NAV:
see the separate VNS manual for operating
instructions.
Infotainment (RADIO, MEDIA, TEL): see
page 212 .
Vehicle-related settings - MY CAR: see
page 189.
Park assist camera - CAM*: see page 175.
Climate system: see page 195.
Volvo Sensus is the operating system in your
vehicle providing a coordinated interface for a
number of functions such as the individualized
settings that can be made in the MY CAR
menus, the climate and infotainment systemsas well as other options such as the park assist
camera(s), etc.
Volvo Sensus uses the screen in the center
instrument panel to display information and
selections are made using this panel’s controls
and buttons. Certain features can also be con-
trolled using the steering wheel keypad.
Press MY CAR to present all of the available
settings related to driving and/or controlling
the vehicle, such as City Safety, setting the
clock, lock settings, etc.
Press RADIO, MEDIA, TEL, NAV* and CAM*
to change a source and to activated systems
or functions such as AM, FM1, CD, DVD, Blue-
tooth, navigation* and the park assist camera
*.
See the respective sections in this manual for
more detailed information about your vehicle's
various features and functions.

05 Comfort and driving pleasure
The MY CAR menus
05

189 Introduction
The menu system provides access to
menus for operating many of the vehi-
cle's functions, such as setting the
clock, door mirrors, locks, etc.
Navigating in the menus is done using the but-
tons on the center console control panel or with
the right-side steering wheel keypad.
Some of the features mentioned in this section
are optional.
Operation
Center console controls
Center console controls for menu navigation
Press MY CAR to access the My Car
menus.
Press OK/MENU to select a highlighted
selection or to store a certain function in
the system's memory.
Turn to navigate up/down among menu
selections.
EXIT
EXIT functionsThe results of a short press on EXIT vary,
depending on where the cursor is and where
you are in the menu structure.
•Reject and incoming phone call
•The current function will be cancelled
•Characters that have been entered will be
erased
•The most recent selection will be cancelled
•Go back (upward) in the menu system
A long press will take you to the highest menu
level (the main view), giving you access to all of
the vehicles/menus. See page 213 for addi-
tional information.
Steering wheel keypad
The keypad varies according to the vehicle's
equipment
Turn the thumb wheel to go up/down
among menu selections. Press the thumb

06 Infotainment
Bluetooth® hands-free connection
06

243
2. Dial the desired phone number using the
center console keypad or use the speed
dial function (see page 247). In normal
view (see page see page 213 for informa-
tion about the various display views), it is
also possible to turn TUNE clockwise to
access the phone book and then counter-
clockwise for the call list. See page 247 for
more information about the phone book.
3.
Press the thumb wheel or OK/MENU.
End or reject a call by pressing EXIT.
Disconnecting the cell phoneThe cell phone is automatically disconnected
from the infotainment system if it is moved out
of range.
The cell phone can be manually disconnected
from the hands-free system by pressing and
holding TEL or in phone mode, going to Phone
menu
Disconnect phone. See also page
244 for more information about connections.
The hands-free system is also deactivated
when the ignition is switched off (or if the
driver’s door is opened).
When the cell phone is disconnected from the
hands-free system, a call in progress can be
continued using the cell phone’s own speaker
and microphone.Even if the cell phone has been disconnected
manually, some phones may reconnect auto-
matically, for example when a new call is initi-
ated.
Removing a paired deviceA paired phone or device can be removed from
the list. To do so:
1.
Press TEL.
2.
Select Phone menu
Remove
Bluetooth device.
Handling calls
Incoming calls–
Press OK/MENU (or the thumb wheel on
the steering wheel keypad) to answer a
call, even if the infotainment system is cur-
rently in another mode (e.g.,
RADIO orMEDIA).
Press EXIT to reject a call.
Auto answerThis function means that incoming calls will be
answered automatically. Activate or deactivate
the function in the menu system under Phone
menu
Call optionsAuto answer.
Call settingsWhile a call is in progress, press OK/MENU or
the thumb wheel on the steering wheel keypad
to access the following functions:
•Mute: mute the infotainment system’s
microphone.
•Mobile phone: transfer the call from
hands-free to the cell phone. On certain
cell phones, the connection will be broken,
which is normal. The hands-free function
will ask if you would like to reconnect.
•Dial number: dial a third party during an
ongoing call using the keypad (the current
call will be put on hold).
Call listsCall lists are copied to the hands-free function
each time a cell phone is connected and the
lists are updated while the phone is connected.
In normal view, turn TUNE counter-clockwise
to see the
All calls list.
In phone mode, the various call lists can be
displayed in Phone menu
Call lists:
•All calls
•Missed calls
•Answered calls
•Dialled calls (certain cell phones show
this list in reverse order)
•Call duration

06 Infotainment
Bluetooth® hands-free connection
06
245
NOTE
Changes made from the infotainment sys-
tem to a contact in the cell phone's phone
book will result in a new contact being
added to the infotainment system's phone
book. However, this contact will not be
saved in the cell phone's phone book. The
infotainment system's display will show
duplicate contacts with different icons.
Please also note that if a speed dial number
is saved or if a contact's information is edi-
ted, this will result in a new contact in the
infotainment system's phone book.
The symbol must be displayed before
the phone book can be used and the hands-
free function must be in phone mode.
The infotainment system saves a copy of each
paired cell phone's phone book. This phone
book can be copied each time the phone is
connected.
–Activate/deactivate this function in phone
mode in Phone menu
Phone settings
Download phone book.
If the phone book contains information about
someone who is trying to call you, this infor-
mation will be shown in the display.
Contact shortcutsA quick way of searching the phone book for
contacts in normal view is to turn TUNE clock-
wise to access the phone book and then coun-
ter-clockwise to select a contact from the list.
Press OK/MENU to call.
Each name in the phone book has a default
phone number. If the
symbol is displayed to
the right of it, this indicates that there are addi-
tional phone numbers for this contact. To use
a phone number other than the default one,
press the
button on the center console
control panel. Turn TUNE to select a different
phone number and press OK/MENU to call.
It is also possible to search for a contact by
using the center console keypad to enter the
first letter(s) of the contact's name (see also the
following table "Buttons in the center console"
for each button's function).
The list of contacts can also be accessed from
normal view by pressing and holding the button
on the center console keypad with the first let-
ter of the contact's name. For example, press-
ing and holding button 6 would provide direct
access to the section of the list with contacts
whose names begin with M.
Buttons in the center console
ButtonFunction
Space . , - ? @ : ; / ( ) 1
A B C Å Ä Æ À Ç 2
D E F È É 3
G H I Ì 4
J K L 5
M N O Ö Ø Ñ Ò 6
P Q R S ß 7
T U V Ü Ù 8
W X Y Z 9
Shift between upper and lower
case
+ 0 p w
# *

07 During your trip
Refueling
07
260
Opening/closing the fuel cap
Fuel vapor expands in hot weather. Open the
filler cap slowly.
After refueling, close the fuel filler cap by turn-
ing it clockwise until it clicks into place.
CAUTION
•Do not refuel with the engine running2.
Turn the ignition off or to position I. If the
ignition is on, an incorrect reading could
occur in the fuel gauge.
•Avoid overfilling the fuel tank. Do not
press the handle on the filler nozzle
more than one extra time. Too much fuel
in the tank in hot weather conditions can
cause the fuel to overflow. Overfilling
could also cause damage to the emis-
sion control systems.
Emission controls
Three-way catalytic converter
•Keep your engine properly tuned. Certain
engine malfunctions, particularly involving
the electrical, fuel or distributor ignition
systems, may cause unusually high three-
way catalytic converter temperatures. Do
not continue to operate your vehicle if you
detect engine misfire, noticeable loss of
power or other unusual operating condi-
tions, such as engine overheating or back-
firing. A properly tuned engine will helpavoid malfunctions that could damage the
three-way catalytic converter.
•Do not park your vehicle over combustible
materials, such as grass or leaves, which
can come into contact with the hot exhaust
system and cause such materials to ignite
under certain wind and weather condi-
tions.
•Excessive starter cranking (in excess of
one minute), or an intermittently firing or
flooded engine can cause three-way cata-
lytic converter or exhaust system over-
heating.
•Remember that tampering or unauthorized
modifications to the engine, the Engine
Control Module, or the vehicle may be ille-
gal and can cause three-way catalytic con-
verter or exhaust system overheating. This
includes: altering fuel injection settings or
components, altering emission system
components or location or removing com-
ponents, and/or repeated use of leaded
fuel.
NOTE
Unleaded fuel is required for vehicles with
three-way catalytic converters.
2If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's
performance will not be affected. Use only Volvo original or approved fuel filler caps.

11 Index
11
355
Bulbs
headlights...........................312, 313, 314
introduction......................................... 312
license plate lights.............................. 316
specifications...................................... 317
trunk lighting....................................... 316
C
Camera, Park Assist................................ 175
Capacity weight....................................... 283
Catalytic converter................................... 260
Cell phone, hands-free connection......... 240
Cell phone voice control.......................... 248
Central locking system, introduction......... 52
Chains...................................................... 286
Check engine light..................................... 78
Check Engine warning light....................... 79
Child restraints
recalls and registration......................... 39
Child restraint systems.............................. 40
booster cushions.................................. 46
convertible seats.................................. 44
infant seats........................................... 42ISOFIX/LATCH anchors........................ 47
top tether anchors................................ 48
Child safety................................................ 37
booster cushions.................................. 46
child restraint systems.......................... 40
convertible seats.................................. 44
infant seats........................................... 42
Child safety locks...................................... 49
City Safety™............................................ 151
Climate system........................................ 200
air distribution............................. 196, 202
air vents.............................................. 197
Interior Air Quality System.................. 196
introduction......................................... 195
passenger compartment filter............ 196
refrigerant........................................... 195
Clock, setting............................................. 82
Cold weather driving................................ 256
Collision warning system.................157, 158
Compass in rearview mirror..................... 107
Conserving electrical current................... 255
Controls, center console.......................... 213
Convertible seats....................................... 44
Coolant............................................310, 347
Cooling system, general information....... 255Corner Traction Control........................... 130
Courtesy lighting........................................ 99
Crash event data......................................... 9
Crash mode............................................... 36
Cruise control..................................135, 136
adaptive.............................................. 137
Curb weight............................................. 283
Current, conserving................................. 255
D
Defroster.................................................. 200
Detachable key blade..........................57, 60
Disconnecting the front passenger’s air-
bag....................................................... 27, 28
Dome lighting............................................. 99
Door mirrors............................................. 105
Driver alert............................................... 165
Driver distraction warning.......................... 13
Driving economically................................ 254
Driving in cold weather............................ 256
Driving through water..............................255
