2013 VOLVO C70 TPMS

Contents
4* Option/accessory, for more information, see Introduction.
06
06 Starting and driving
General information................................140
Fuel requirements................................... 143
Ignition switch......................................... 146
Starting the vehicle................................. 147
Starting the vehicle with keyless drive*... 149
Automatic transmission..........................151
Shiftlock override.................................... 153
Brake system.......................................... 154
Parking brake.......................................... 157
Stability system....................................... 158
Towing.................................................... 160
Jump starting.......................................... 163
Towing a trailer....................................... 164
Detachable trailer hitch........................... 166
Transporting loads.................................. 167
Blind Spot Information System (BLIS)*. . . 168
Rear park assist*..................................... 172
07
07 Wheels and tires
General information................................176
Tire inflation............................................. 179
Inflation pressure ...................................181
Tire designations..................................... 182
Glossary of tire terminology.................... 184
Vehicle loading........................................ 185
Uniform tire quality gradings................... 187
Snow chains, snow tires, studded tires. . 188
Tire Sealing System* .............................. 189
Temporary spare..................................... 195
Spare tire and jack .................................196
Wheel nuts.............................................. 198
Changing a wheel................................... 199
Tire Pressure Monitoring System (TPMS) 201
08
08 Car care
Washing and cleaning the car................. 206
Paint touch up......................................... 210

174* Option/accessory, for more information, see Introduction.
General information............................................................................... 176
Tire inflation........................................................................................... 179
Inflation pressure ................................................................................. 181
Tire designations................................................................................... 182
Glossary of tire terminology.................................................................. 184
Vehicle loading...................................................................................... 185
Uniform tire quality gradings................................................................. 187
Snow chains, snow tires, studded tires................................................ 188
Tire Sealing System* ............................................................................ 189
Temporary spare................................................................................... 195
Spare tire and jack ............................................................................... 196
Wheel nuts............................................................................................ 198
Changing a wheel................................................................................. 199
Tire Pressure Monitoring System (TPMS).............................................201

07 Wheels and tires
Tire Sealing System*
07
192* Option/accessory, for more information, see Introduction.
NOTE
Be sure that none of the other 12-volt sock-
ets is being used while the compressor is in
operation.
9. Start the vehicle’s engine.
10. Start the tire sealing system’s compressor
by pressing the on/off switch to position I.
WARNING
•Never stand next to the tire being inflated
when the compressor is in operation.
•If cracks, bubbles, etc. form on the tire,
switch off the compressor immediately.
•If there is visible damage to the sidewall
or the rim, the tire cannot be repaired.
The vehicle should not be driven if this
occurs. Contact a towing service or
Volvo On Call Roadside Assistance if
applicable.
NOTE
The air pressure gauge will temporarily
show an increase in pressure to approxi-
mately 88 psi (6 bar) while the sealing com-
pound is being pumped into the tire. The
pressure should return to a normal level
after approximately 30 seconds.
11. Within seven minutes, inflate the tire to
between 22—44 psi (1.8—3.0 bar). Switch
off the compressor briefly to get a clear
reading from the pressure gauge.
CAUTION
The compressor should not be used for
more than 10 minutes at a time to avoid
overheating.
WARNING
If the pressure remains below 22 psi
(1.8 bar) after approximately seven minutes,
turn off the compressor. In this case, the
hole is too large to be sealed and the vehicle
should not be driven.
12. Switch off the compressor and disconnect
the electrical wire from the 12-volt socket.13. Unscrew the hose from the tire’s inflation
valve and reinstall the valve cap.
14. Immediately drive the vehicle for approxi-
mately 2 miles (3 km) at a maximum speed
of 50 mph (80 km/h) to distribute the seal-
ing compound in the tire.
CAUTION
If your vehicle is equipped with the Tire
Pressure Monitoring System (TPMS), the
use of the sealing compound may lead to
incorrect tire pressure readings or in rare
cases, damage to the tire pressure sensor.
Use the tire sealing system to check and
adjust the damaged tire's inflation pressure.
NOTE
•Safely stow the tire sealing system in a
convenient place as it will soon be used
again to check the tire’s inflation pres-
sure.
•The empty bottle of sealing compound
cannot be removed from the bottle
holder. Consult a trained and qualified
Volvo service technician to have the
bottle removed and properly disposed
of.

07 Wheels and tires
Tire Pressure Monitoring System (TPMS)
07
201 Introduction
The tire pressure monitoring system1 uses sen-
sors mounted in the tire valves to check infla-
tion pressure levels. When the vehicle is mov-
ing at a speed of approximately 20 mph
(30 km/h) or faster, these sensors transmit
inflation pressure data to a receiver located in
the vehicle.
NOTE
USA – FCC ID: KR5S122780002
This device complies with part 15 of the
FCC rules. Operation is subject to the fol-
lowing conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
When low inflation pressure is detected, TPMS
will light up the tire pressure warning light
(also referred to as a telltale) in the instrument
panel and will display one of the following mes-
sages in the text window:
LOW TIRE PRESS.
CHECK TIRES or TIRE PRESSURE LOW.
NOTE
If a fault occurs in TPMS, the tire pressure
warning light will flash for approximately
1 minute and
TIRE PRESS SYST
SERVICE REQUIRED will be displayed.
Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. (If your
vehicle has tires of a different size than the size
indicated on the vehicle placard or tire inflation
pressure label, you should determine the
proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has
been equipped with a tire pressure monitoring
system (TPMS) that illuminates a low tire pres-
sure telltale when one or more of your tires is
significantly under-inflated. Accordingly, when
the low tire pressure telltale illuminates, you
should stop and check your tires as soon as
possible, and inflate them to the proper pres-
sure. Driving on a significantly under-inflated
tire causes the tire to overheat and can lead to
tire failure. Under-inflation also reduces fuel
efficiency and tire tread life, and may affect the
vehicle's handling and stopping ability.Please note that the TPMS is not a substitute
for proper tire maintenance, and it is the driv-
er's responsibility to maintain correct tire pres-
sure, even if under-inflation has not reached
the level to trigger illumination of the TPMS low
tire pressure telltale.
Your vehicle has also been equipped with a
TPMS malfunction indicator to indicate when
the system is not operating properly. The
TPMS malfunction indicator is combined with
the low tire pressure telltale . When the system
detects a malfunction, the telltale will flash for
approximately one minute and then remain
continuously illuminated. This sequence will
continue upon subsequent vehicle start-ups as
long as the malfunction exists. When the mal-
function indicator is illuminated, the system
may not be able to detect or signal low tire
pressure as intended. TPMS malfunctions may
occur for a variety of reasons, including the
installation of replacement or alternate tires or
wheels on the vehicle that prevent the TPMS
from functioning properly. Always check the
TPMS malfunction telltale after replacing one
or more tires or wheels on your vehicle to
ensure that the replacement or alternate tires
and wheels allow the TPMS to continue to
function properly.
1U.S. models only

07 Wheels and tires
Tire Pressure Monitoring System (TPMS)
07
202
NOTE
•TPMS indicates low tire pressure but
does not replace normal tire mainte-
nance. For information on correct tire
pressure, please refer to the table on on
page 181, or consult your Volvo retailer.
•The tire pressure warning light will not
identify which tire is underinflated. Be
sure to check all four tires.
•A certain amount of air seepage from
the tires occurs naturally and tire pres-
sure fluctuates with seasonal changes
in temperature. Always check tire pres-
sure regularly.
Erasing warning messagesWhen a low tire pressure warning message has
been displayed, and the tire pressure warning
light has come on:
1. Use a tire pressure gauge to check the
inflation pressure of all four tires.
2. Re-inflate the tire(s) to the correct pressure
(consult the tire pressure placard or the
table, see page 181 ).
3. In certain cases, it may be necessary to
drive the vehicle for several minutes at a
speed of 20 mph (30 km/h) or faster. Thiswill erase the warning text and the warning
light will go out.
WARNING
Incorrect inflation pressure could lead to tire
failure, resulting in a loss of control of the
vehicle.
Changing wheels with TPMSPlease note the following when changing or
replacing the factory installed TPMS wheels/
tires on the vehicle:
•Only the factory-mounted wheels are
equipped with TPMS sensors in the valves.
•If the vehicle is equipped with a temporary
spare tire, this tire does not have a TPMS
sensor.
•If wheels without TPMS sensors are moun-
ted on the vehicle, TIRE PRESS SYST
SERVICE REQUIRED will be displayed
each time the vehicle is driven above
25 mph (40 km/h) for 10 minutes or more.
•Once TPMS sensors are properly installed,
the warning message should not reappear.
If the message is still displayed, drive the
vehicle for several minutes at a speed of
20 mph (30 km/h) or faster to erase the
message.
•Volvo recommends that TPMS sensors be
fitted on all wheels used on the vehicle.Volvo does not recommend moving sen-
sors back and forth between sets of
wheels.
NOTE
•If you change to tires with a different
recommended inflation pressure, the
TPMS system must be recalibrated to
these tires. This must be done by an
authorized Volvo retailer or workshop.
•If a tire is changed, or if the TPMS sen-
sor is moved to another wheel, the sen-
sor's seal, nut, and valve core should be
replaced.
•When installing TPMS sensors, the
vehicle must be parked for at least
15 minutes with the ignition off. If the
vehicle is driven within 15 minutes, a
TPMS error message will be displayed.
CAUTION
When inflating tires with TPMS valves, press
the pump's mouthpiece straight onto the
valve to help avoid bending or otherwise
damaging the valve.

07 Wheels and tires
Tire Pressure Monitoring System (TPMS)
07
* Option/accessory, for more information, see Introduction.203 Self-supporting run flat tires (SST)*
Self-supporting run flat tires are available as
optional equipment. The vehicle must be
equipped with the Tire Pressure Monitoring
System (TPMS) if tires of this type are installed.
Tires of this type have specially reinforced
sidewalls that make it possible to continue
driving to a limited extent even though the tire
has lost some or all of its inflation pressure.
These tires are mounted on special rims (nor-
mal tires can also be mounted on these rims).
If an SST tire loses inflation pressure, the yel-
low TPMS symbol illuminates in the instrument
panel and a text message is also displayed. If
this happens, reduce speed to not more than
50 mph (80 km/h). The tire should be replaced
as soon as possible.
Drive carefully; it may be difficult to determine
which tire is damaged. To find the damaged
tire, check the inflation pressure in all four tires.WARNING
•SST tires should only be mounted by
service technicians who are familiar
with tires of this type.
•SST tires may only be mounted on vehi-
cles equipped with TPMS.
•Do not drive faster than 50 mph
(80 km/h) if TPMS indicates that a tire
has lost inflation pressure.
•Do not drive farther than 50 miles
(80 km) before replacing a damaged
SST tire.
•Drive carefully and avoid e.g., hard
braking or fast turns.
•SST tires must be replaced if they are
damaged. A tire of this type cannot be
repaired.

12 Index
12
291
Reporting safety defects
Canada................................................. 19
USA....................................................... 18
Roll-over protection system (ROPS).......... 37
S
Safety, occupant........................................ 18
Safety defects, reporting
Canada................................................. 19
USA....................................................... 18
Seat belt
reminder................................................ 22
Seat belts................................................... 20
Automatic locking retractor/Emergency
locking retractor.................................... 40
buckling................................................ 20
guides...................................................21
maintenance......................................... 23
pretensioners........................................ 20
unbuckling............................................ 21
use during pregnancy........................... 22
Seats, front................................................ 98
Shiftlock.....................................................11
override............................................... 153Side door mirrors....................................... 79
Side impact airbags................................... 32
Side impact protection (SIPS) airbags....... 32
SiriusXM
E satellite radio......................... 255
Ski hatch.................................................. 118
Snow chains............................................ 188
Snow tires................................................ 188
Sound control, automatic........................249
Sound settings, audio system................. 248
Spare tire.........................................195, 196
Stability system....................................... 158
Dynamic Stability Traction Control
(DSTC)................................................ 158
Starting the engine..................................147
with keyless drive...............................149
Start inhibitor (immobilizer)..............122, 147
Steering wheel
adjusting............................................... 76
keypad................................................ 245
Storage compartments............................ 112
Studded tires........................................... 188
Subwoofer............................................... 248
Supplemental restraint system.................. 24
Symbols, overview................................... 282
T
Tachometer................................................ 54
Temporary spare tire.......................195, 196
Three-way catalytic converter................. 281
Tire inflation............................................. 179
Tire inflation pressure..............................181
Tire Pressure Monitoring System (TPMS) 201
Tires.........................................................176
age...................................................... 176
changing..................................... 196, 199
changing from summer to winter........ 177
designations....................................... 182
glossary of terms................................ 184
improving economy............................ 177
inflation............................................... 179
inflation pressure, checking................ 179
inflation pressure table.......................181
load ratings......................................... 180
rotation............................................... 176
Self-supporting run flat tires (SST)..... 203
snow...................................................188
spare................................................... 195
spare tire (location)............................. 196
speed ratings...................................... 180
storing................................................. 178
studded............................................... 188
