Tires and wheel rims approved by Volkswagen have been matched precisely to your vehicle model
and contribute considerably to good handling and safe vehicle performance.
Tightening Torque
Wheel bolts must always be installed with the correct tightening torque. The required tightening torque
for your vehicle's wheel bolts is ft lbs ( Nm) for front-wheel drive vehicles and 88 ft lbs ( Nm) for
vehicles with four-wheel drive (4MOTION). After changing a wheel, the bolt torque must be checked
as soon as possible with an accurate torque wrench. See an authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
Wheel rims with bolted rim rings
Wheel rims with bolted rim rings have several parts. The parts are bolted together with special screws
in a special process. This helps to ensure that they will work properly, prevent leaks, run true and
safely. Damaged wheel rims must be replaced, and you must never take them apart or try to repair
them yourself. Have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
repair them for you ⇒ .
Wheel rims with bolted decorative covers
Light-alloy wheels may have interchangeable decorative covers attached to the rim with self-locking
screws. If you want to replace damaged wheel covers, contact your authorized Volkswagen dealer or
authorized Volkswagen Service Facility ⇒ .
WARNING
Using improper or damaged wheel rims can affect driving safety, cause accidents and severe
personal injuries.
x Use only wheel rims approved for the vehicle.
x Regularly check wheel rims for damage and replace them if necessary.
WARNING
Improper loosening and tightening of the bolts on wheel rims with bolted rim rings can cause
accidents and severe personal injury.
x Never loosen bolted connections on wheel rims with bolted rim rings.
x Have all work on wheel rims with bolted rim rings performed by an authorized Volkswagen
dealer or authorized Volkswagen Service Facility.

Stowing the replaced wheel
One of the vehicles normal wheels will not fit in the well for the compact spare wheel in the floor of the
luggage compartment. Therefore, in the event of a flat tire, the wheel which was changed must be
secured, for example, with suitable straps in the luggage compartment.
Open the rear hatch, raise the entire luggage compartment floor, press the retaining pin (1) to the right
and slowly lower the luggage compartment floor.
Put the wheel you took off the vehicle into the spare wheel well so that the center hole of the rim is
aligned with the threaded pin.
Turn the threaded retainer in the center of the compact spare wheel (2) clockwise until the wheel
replaced is securely in place.
If necessary, return the vehicle tool kit to its location in the luggage compartment.
Raise the floor covering and release the retaining pin, then fold the floor covering back down onto the
floor of the luggage compartment.
Close the rear hatch.
Differences between the road tires and the compact spare
The compact spare is different in design from the road tires and must be used only in the event of a
flat tire, only for a brief time, and only when driving with extra caution ⇒ .
Replace it with a tire matching the others on your vehicle as soon as possible.
Please heed the following:
x Do not drive faster than 50 mph (80 km/h)!
x Avoid full-throttle acceleration, hard braking and fast cornering!
x Do not use snow chains on the compact spare wheel
x After installing the compact spare tire, check the tire pressure as soon as possible
Check the tire inflation pressure of the compact spare whenever you check the tire pressure of the
road wheels, at least once a month. Inflate a compact spare tire to the cold tire pressure specified for
the compact spare on the tire pressure label or on a separate label for the compact spare, if there is
one.

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting
an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find
helpful information under “Characteristics” and “Checklist” in the index.

Description Possible causes among
others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump start
– Charge vehicle battery
The wrong remote control
vehicle key is used.
Use a valid remote control vehicle key

Fuel level too low. Refuel
Vehicle cannot be locked
or unlocked using remote
control vehicle key.
– Battery in remote control
vehicle key dead.
– Too far away from vehicle.
– Buttons pressed outside
operating range.
– Replace battery in the remote control
key
– Move closer to vehicle.
– Synchronize remote control vehicle
key
– Lock or unlock vehicle manually
Unusual noises.
Cold engine, braking support
systems, electronic parking
brake.
Check the “Noises” entry in the
keyword index.
Driver seat and outside
mirrors when vehicle is
unlocked.
Convenience settings are
stored. Correct convenience settings
Memory-seat settings are
stored.
– Reassign seat setting
– Clear memory-seat memory
Front seats cannot be
adjusted with power
controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
Features do not work as
described in this manual.
Settings were adjusted in the
Volkswagen Information
System.
Check and reset to factory settings if
necessary
Headlights do not light up
the road as they should.
– Headlights incorrectly
adjusted.
– Light bulbs burned out.
– Low beams not switched on.
Have the headlight range adjusted by
an authorized Volkswagen dealer or an
authorized Volkswagen Service
Facility. Adjust headlight range .
– Change light bulbs
– Switch on low beams
Electrical consumers do
not work.
Vehicle battery charge too low. Charge vehicle battery
Remaining fuel level too low. Refuel .
Fuse blown. Check fuse and replace if necessary

Fuel consumption higher
than indicated.
– Short hauls.
– “Jumpy gas pedal”.
– Avoid short distance driving.
– Drive defensively.
– Accelerate smoothly.
Electrical loads switched on. Switch off unnecessary loads.
Engine control malfunctioning. Have the malfunction corrected

Manually unlocking and locking the driver door

Fig. Door handle on driver door: Concealed lock cylinder.

Manually locking the passenger door and rear doors

Fig. On the front side of the right rear door: Emergency lock, covered by a rubber seal.

Fig. On the front side of the right rear door: Manual vehicle locking with the key bit in the vehicle key.

Emergency unlocking of the rear hatch

Fig. View from luggage compartment: Emergency unlocking rear hatch with the remote control vehicle key.

Fig. Releasing the selector lever lock.

using this number. Record the code number of the wheel bolt lock and store it separate from
the vehicle.
(3) Screw-in towing eye.
(4) Hubcap puller clips for removing hubcaps, full wheel covers or wheel bolt caps.
(5) Jack. Before putting the jack back, be sure to completely crank the jack down to its original
position. Then the crank must be clamped against the side of the jack.
(6) Lug wrench.
(7) Folding chocks
Folding chocks

Fig. Unfolding the folding chock.
