2013 VOLKSWAGEN TIGUAN turn signal

x Light switch in position  if the vehicle has no orientation lighting
WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be
seen by others when it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the / position or when the fog lights themselves have been
switched on
Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistant menu
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistant menu
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

Electrical load Maximum power
Turn signals per side 54 watts
Side marker lights total4 watts
Taillights lights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the
tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all
bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.
NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the
regular maintenance and inspection intervals because of the extra load it has to pull.
In some countries an additional fire extinguisher must be carried if the total weight of the trailer
exceeds 5, lbs. (2, kg).
Hitching up and connecting a trailer

If there is a malfunction in the Park Distance Control, a brief continuous warning tone will sound. Have
it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control interprets water and ice on the sensors as an obstacle.
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on again automatically if the vehicle approaches the obstacle again.
x For vehicles with automatic transmissions, there is no beeping when the transmission is in Park
(P).
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an
authorized Volkswagen Service Facility.
WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
If you hear a long beep lasting about 3 seconds when you first turn PDC on, this means there is a
malfunction in the Park Distance Control system. Have it immediately checked by an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.

Checklist
For your own safety and that of your passengers, carry out the following steps in the order listed ⇒ :
1. Park the vehicle at safe distance from traffic and on a suitable surface ⇒ .
2. Switch on emergency flashers by pressing the  switch ⇒ fig. .
3. Apply the electronic parking brake to help prevent the vehicle from moving
4. Shift the transmission into Park (P) (automatic) or Neutral (manual only)
5. Stop the engine and remove the key from the ignition switch
6. Have all passengers exit and go to a safe location away from moving traffic, such as behind a
guard rail.
7. Take all vehicle keys with you when leaving your vehicle.
8. Set up a warning triangle or other warning device in order to alert other motorists and cyclists.
9. Let the engine cool down and get expert assistance if necessary.
If the emergency flashers are on, use the turn signal lever to indicate a direction or lane change, for
example when the vehicle is being towed. This temporarily interrupts the emergency flashers.
Switch on the emergency flashers when:
x Traffic suddenly slows down or stops in front of you to warn those approaching from behind.
x In any emergency situation.
x If the vehicle breaks down.
x When being towed.
Always obey traffic laws that govern the use of emergency flashers where you are driving.
If the emergency flashers are not working, a different method – as permitted by law – must be used to
alert other motorists and cyclists to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common
sense.
WARNING
The vehicle exhaust system and the catalytic converter or diesel particulate filter get very hot.
They can cause fires and serious personal injury.
x Never park where parts of the hot exhaust system or catalytic converter could ignite
flammable materials, such as dry grass, brush, leaves, spilled fuel, etc.
The vehicle battery will be drained if the emergency flashers are on for a long time – even if the
ignition is switched off.

NOTICE
Always insert and remove lamps carefully to avoid damage to the vehicle paint or to other
parts of the vehicle.
Replacing light bulbs in the Halogen headlight

Fig. In the engine compartment: Cover 1 on the left headlight for the low beam bulb holder 3 and cover 2 for
the parking light bulb holder 4, turn signal bulb holder 5 and high beam or daytime running light bulb 6.

Only perform these steps in the specified order:
fig. Low beam
headlight
Parking light Turn signal High beam
headlight or
daytime running
light
5. If necessary, press the locking mechanism on the bulb holder
and pull the bulb straight out of the bulb holder.

6. Replace the burned out light bulb with a new bulb of the same type.
7. Reinsert the bulb
holder (3) B into
the headlight and
turn it clockwise
until it stops.
Reinsert the bulb
holder (4) B into
the headlight and
clip it into the
guide.
Reinsert the turn
signal bulb holder
(5) B into the
headlight and turn it
clockwise until it
stop.
Insert the parking
light bulb holder (4)
B into the headlight
and clip it into the
guide.
Reinsert the bulb (6)
B into the headlight
and turn it clockwise
until it stops.
8.
Install the cover (1)
A on the back of
the headlight
(retainer vertical)
and turn it
clockwise until it
stops.
Install the rubber cover (2) A.

The illustrations show the left headlight assembly from the rear. The right headlight assembly is
the mirror image of the left headlight assembly.
Different models may have different lights, and the location and design of covers, bulb holders,
and bulbs may be in a different location than shown in the illustrations.
Replacing light bulbs in the Xenon headlight

Fig. In the engine compartment: cover 1 on the left headlight for the turn signal bulb holder 2 and the
cornering light bulb holder 3.
