2013 VOLKSWAGEN TIGUAN Seats

x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
The passenger-side outside mirror automatically adjusts back from the position stored for backing up
when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob ⇒ fig. 95
is rotated from (R) into a different position.
Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is
switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate
memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position stored for backing
up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is
rotated from (R) into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory feature:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock button 0 on the vehicle key and then press the desired memory button
at the same time within about 3 seconds. A chime sounds to confirm activation.
To disable remote control vehicle key memory function:
x Press and hold the SET button.
x Press and hold the unlock button 0 on the remote control vehicle key within about 10 seconds. A
chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instructions, Assigning driver seat and outside mirror settings to a vehicle key to assign
the driver seat and outside mirror settings to the vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button 1 in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions
whenever the vehicle is unlocked with the vehicle key open button 0 and the driver door is opened. If 2
people use the vehicle, each of them should always use the key in which his or her personal settings
have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new
driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can
be reprogrammed and assigned to a remote control vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.

x Push the head restraint all the way down
x Unlock the front passenger backrest in the direction of the arrow ⇒ fig. 54 (1).
x Fold the front passenger backrest forward into the horizontal position in the direction of the arrow
(2).
x The front passenger backrest must be securely latched in the folded down position.
Folding the front passenger backrest into place
x Make sure that nobody is near the hinges when folding the backrest back into place.
x Unlock the front passenger backrest to fold it back ⇒ fig. 55.
x Fold the front passenger backrest into the upright position.
x The front passenger backrest must be securely latched in the upright position.
WARNING
Improper folding and improper latching of the front passenger backrest can cause serious
personal injury.
x Never fold the front passenger backrest forward or back when the vehicle is moving.
x Always make sure that the PASSENGER AIR BAG OFF  light is on and stays on
whenever the backrest of the front passenger seat is folded forward.
x Always keep hands, fingers, feet and other body parts out of the way of the seat hinges
and the seat locking mechanism when folding the backrest forward and back.
x Floor mats and other objects can get caught in the front passenger backrest hinges. This
can cause the front passenger backrest to incorrectly latch when folded back into the upright
position.
x When folded back into place, the front passenger backrest must be securely latched in the
upright position. An improperly latched front passenger backrest can suddenly move and
cause serious personal injury.
WARNING
Open seat mountings and hinges of the folded front passenger backrest can cause severe
injuries in the event of a braking maneuver or accident.
x Do not let passengers or children occupy the front passenger seat when the front
passenger backrest is folded forward.
x When the front passenger backrest is folded down, only the outer seat of the rear bench
behind the driver seat can be occupied. This also applies to children in child safety seats.

Fig. 60 Unbelted passengers in the rear seats are thrown forward on top of the belted driver.

Adjusting safety belt height
The safety belt position can be adjusted using the following features:
x Safety belt height adjusters for the front seats.
x Front seats with height adjustment.
WARNING
Improperly positioned safety belts can cause serious personal injury in an accident or a
sudden braking maneuver.
x Always make sure that all vehicle occupants are correctly restrained and stay in a correct
seating position whenever the vehicle is being used.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are
correctly positioned on the body.
x A loose-fitting safety belt can cause serious injuries by shifting its position on your body
from the strong bones to more vulnerable soft tissue and cause serious injury.
x The shoulder belt portion of the safety belt must be positioned over the middle of the
occupant's shoulder and never across the neck or throat.
x The safety belt must lie flat and snug on the occupant's upper body.
x Never wear the shoulder part of the safety belt under your arm or otherwise out of
position.
x The lap portion of the safety belt must be positioned as low as possible across the pelvis
and never over the abdomen. Make sure the belt lies flat and snug against the pelvis. Pull on
the safety belt to tighten if necessary.
x Expectant mothers must always wear the lap portion of the safety belt as low as possible
across the pelvis and below the rounding of the abdomen.
x Do not twist the belt when attaching it. If you cannot untwist a twisted safety belt, wear it
anyway, but make sure the twisted part is not in contact with your body. Have the problem
corrected right away by an authorized Volkswagen dealer or authorized Volkswagen Service
Facility.
x Never hold the safety belt away from your body with your hand.
x Never wear belts over rigid or breakable objects, such as eye glasses, pens or keys.
x Never modify the position of the belt using comfort clips, loops or similar devices.

x If you have a physical impairment or condition that prevents you from sitting properly on the seat
with the safety belt properly fastened, special modifications to your vehicle may be necessary.
x Contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility or call the
Volkswagen Customer CARE Center at 1- - - 7 for information about possible modifications to your
vehicle.

Safety belt height adjusters

Fig. 66 Next to the front seats: Safety belt height adjuster.

WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal
injury.
x Always make sure there are no people or animals in the area around the rear seat backrest
when folding it forward.
x Never fold the rear seat backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get
caught or damaged.
x Keep hands, fingers, feet and other body parts out of the away when folding the rear seat
backrest up and down.
x Each rear seat backrest must be securely latched into place in the upright position so that
the safety belts on the rear seats can provide protection. This is particularly the case for the
middle seat on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together
with the rear seat backrest during sudden braking, driving maneuvers, or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded
down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head
restraint or backrest cushion will not touch the front seats.
NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is
adjusted in the fore and aft direction.
Removing and installing the rear seat

Fig. 97 Front attachment of the rear seat.

7. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the
nuts by hand - do not tighten them with the lug wrench yet.
8. To align the seat rails, press the left rear seat all the way to the left in the vehicle.
9. To align the seat rails, press the right rear seat all the way to the right in the vehicle.
10. Tighten the hexagonal nuts in the luggage compartment (arrows) to 44 ft-lbs (60 Nm) using a
torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench
and have the torque checked at a qualified workshop as soon as possible.
11. Push the rear seats as far back as possible
12. Remove the hexagonal nuts in the rear of the footwell again, set the 3 plastic covers ⇒ fig. 97 on
the studs and screw on with the hexagonal nuts.
13. Tighten the hexagonal nuts (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque
wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked
at a qualified workshop as soon as possible.
14. Clip on the small covers (not pictured) on the hexagonal nuts (arrows).
15. Install the foam insert and spare wheel in the vehicle
16. Install the luggage compartment floor
17. Install the luggage compartment cover
18. Install all rear head restraints
WARNING
No one may ride in the back of the vehicle when the rear seat has been removed.
WARNING
An improperly installed rear seat can separate from its mountings during an accident.
x All securing bolts must be tightened to the specified torque after the rear seat has been
installed.
CAUTION
Sharp-edged parts are located on the underside of the rear seat.
x Protect your hands when you lift the rear seat in or out.
NOTICE
x Have at least one person help to lift the rear seat in or out. One person should be in the
vehicle and one outside.
x The lever ⇒ fig. 43 for the fore and aft adjustment of the rear seat must not be operated
while the seat is removed. If the position of the fore and aft adjustment is changed, the rear
seat can only be installed by a qualified workshop.

x To secure, push the retaining pin to the right.
x To close, push the retaining pin (1) to the left and guide the luggage compartment floor
downwards.
Extending the luggage compartment floor forward
x Remove the luggage compartment cover
x Remove the rear head restraints
x Push both sections of the rear seat forward
x Fold the rear backrests forward
x Fold the cover forward ⇒ fig. (1).
Extending the luggage compartment floor downward
x Remove the luggage compartment cover
x Raise the luggage compartment floor, pull from the side pins (2) and remove it from the vehicle to
the rear.
There may be a foam element with the spare wheel ⇒ fig. located beneath the variable luggage
compartment floor. If a spare wheel is present, remove it and remove the foam element from the
luggage compartment.
WARNING
During hard braking or an accident, loose objects can fly through the passenger
compartment and cause serious or even fatal injuries.
x Even if the luggage compartment floor panel is properly raised, it is still necessary to
secure all objects.
x Objects stowed between the rear seat bench and the luggage compartment floor panel
must never be more than 2/3 as high as the raised floor panel.
x Objects stowed between the rear seat bench and the raised luggage compartment floor
panel must never weigh more than about 16.5 lbs. (7.5 kg).
NOTICE
Do not let the luggage compartment floor fall freely when closing it. Always guide it down into
place. The trim or the luggage compartment floor could be damaged.
If you slide the rear seats forward, there is a gap between the luggage compartment floor and the
rear seats. Make certain there are no objects in this space before sliding the rear seats back again.
