2013 VOLKSWAGEN PASSAT ignition

(7) Windshield wiper and washer lever
– Windshield wiper ()'( – ,/7– /&&
– Intermittent operation for windshield wipers z
– “One-tap wiping” x
– Windshield wiper U
– Automatic wipe/wash for windshield W
– Lever with buttons for the Volkswagen Information System (Basic version) 42)0- , /+/2%3%4 24
(8) Ignition switch (vehicles without Keyless Access)
(9) Starter button (vehicles with Keyless Access locking and starting system)
(10) Pedals
(11) Driver front airbag
(12) Lever for adjustable steering wheel
(13) Horn (only works when the ignition is switched on)
(14) Storage compartment

Preparation for the anti-theft alarm system
If the vehicle is pre-equipped for installation of the anti-theft alarm system, the alarm system can be
retrofitted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
The anti-theft alarm system makes it more difficult for someone to break into or steal the vehicle.
The anti-theft alarm system is automatically activated when the vehicle is locked by pressing the lock
button on the remote control vehicle key.
When is the alarm triggered?
The anti-theft alarm system sounds for about 30 seconds and the turn signals flash for up to 5 minutes
if the following occurs with respect to the locked vehicle:
x Opening a door that has been mechanically unlocked without switching on the ignition within about
15 seconds.
x Forcibly opening a door.
x Forcibly opening the engine hood.
x Forcibly opening the luggage compartment lid.
x Switching on the ignition with an invalid key.
x Disconnecting the vehicle battery.
Deactivating the alarm
Unlock the vehicle with the unlock button on the remote control vehicle key and switch on the ignition
with a valid vehicle key.
For vehicles with Keyless Access, the alarm can be deactivated by grasping one of the door handles
when a valid remote control vehicle key is in range or by holding the remote control vehicle key to the
right of the steering column trim and pressing the starter button.
After the alarm has stopped and the vehicle is opened again in the same or a different area that
is protected by the alarm, the alarm is triggered again. For example, the alarm will sound again if the
luggage compartment lid is opened after one of the doors has been opened.
The anti-theft alarm system is not activated when the vehicle is locked with the power lock
switch W on the inside of the driver or front passenger doors.
If the driver door is mechanically unlocked using the vehicle key bit, only the driver door is un-
locked, but not the entire vehicle. Switching on the ignition deactivates the anti-theft alarm system and
activates the central locking button. To unlock the doors, use the central locking button or remote
control vehicle key.
If the vehicle battery is dead or weak, the anti-theft alarm system will not work properly.

Switches in the driver door
Key to fig. 45:
(1) For the windows in the front doors.
(2) For the windows in the rear doors.
(3) Safety switch.
Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch.
Stopping automatic
movement:
Press/pull the switch again.
_
The safety switch (3) deactivates the power windows
in the rear doors. The yellow indicator light in the
switch comes on.

You can still use the power windows for several minutes after the ignition is switched off as long as the
driver or front passenger door has not been opened. When the vehicle key has been removed from
the ignition and the driver door has been opened, the power windows cannot be opened or closed.
Power windows – features

WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-
dows for several minutes after the ignition is switched off as long as the driver or front pas-
senger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
If the power windows malfunction, the one-touch feature, as well as pinch protection will not work
properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.

WARNING
Careless or unsupervised use of the sunroof can cause serious injuries.
x Always make sure that no one is in the way of the power sunroof when it is closing.
x Always take all vehicle keys with you when leaving the vehicle.
x Never leave children or persons requiring assistance unattended in the vehicle, especially
if they have access to the vehicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and operate the sunroof.
x The sunroof can still be opened or closed for a short period after the ignition has been
switched off, as long as the driver or passenger door is not opened.
WARNING
Closing the sunroof without pinch protection can cause severe injuries.
x Always be careful when closing the sunroof.
x Always make sure that no one is in the way when overriding pinch protection to close the
sunroof.
x Pinch protection does not prevent fingers or other body parts from being pressed against
the roof frame, thereby causing injury.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Function Action for seat heating ⇒fig.65
Switch on: Press the A button. Seat heating is switched on to
maximum.
Adjust the heating
level:
Press the button A repeatedly until the desired
heating level is set.
Switch off: Press the button A repeatedly until all indicator
lights in the button are off.

Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the
ignition was switched off. However, this feature only works if the key is not taken out of the ignition
switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medica-
tion, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature ⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.

x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is
switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate
memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position stored for backing
up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is
rotated from R into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory function:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock button0on the vehicle key and then press the desired memory button at
the same time within about 3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
x Press and hold the SET button.
x Press and hold the unlock button 0 on the vehicle key and the desired memory button at the same
time within about 10 seconds. A chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instructions ⇒ page 120 to assign the driver seat and outside mirror settings to the
vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button 1 in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions
whenever the vehicle is unlocked with the vehicle key open button 0 and the driver door is opened. If
two people use the vehicle, each of them should always use the key in which his or her personal
settings have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new
driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can
be reprogrammed and assigned to a vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x The vehicle battery is weak or dead.

A warning chime also sounds.
The safety belt warning light ª comes on for 6 seconds when the ignition is switched on. A warning
chime also sounds for up to 6 seconds if the driver's safety belt is not buckled. The chime stops soon-
er if the driver buckles his or her safety belt. The warning light and the chime go out when both driver
and front passenger have bucked their safety belts.
If the driver and front seat passenger do not both fasten their safety belts within about 24 seconds
after the chime stops and the vehicle is moving at a speed of more than about 15 mph (25 km/h), the
chime will again sound for about 6 seconds, then go off for about 24 seconds, then sound again for
about another 6 seconds. The same thing happens if one of the safety belts is fastened and then
unfastened while the vehicle is moving. The safety belt warning light ª also flashes. The warning
chime continues to sound at 24 second intervals for up to 2 minutes. No chime sounds at speeds of
less than about 5 mph (8 km/h).
If the ignition is switched on, the safety belt warning light ª stays on until the driver and front passen-
ger have both buckled their safety belts.
WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of
severe personal injury or death. Safety belts offer optimum protection only when used cor-
rectly.
Frontal collisions and laws of physics

Fig. 68 A vehicle with passengers not wearing safety belts approaches a wall.

Fig. 69 A vehicle with passengers not wearing safety belts hits a wall.
