2013 VOLKSWAGEN JETTA window

Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Roof antenna (if equipped)
(2) High-mounted brake light
(3) Rear window
– Rear window defroster
(4) Luggage compartment release
(5) Taillights
(6) Rear license plate bracket
(7) Luggage compartment lid
(8) Threaded hole for the rear towing eye (behind cover)
(9) License plate lights

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Indicator light for anti-theft alarm system (if equipped)
(2) Door handle
(3) Power locking button for locking and unlocking the vehicle 0 – 1
(4) Switch for adjusting the outside mirror (equipment varies)
– Adjusting outside mirrors , – / – 2
– Outside mirror heating ?
(5) Lever for releasing the engine hood
(6) Luggage compartment release
(7) Bottle holder
(8) Storage compartment
(9) Reflector
(10) Buttons for operating the power windows
– Power windows
– Safety switch for rear power windows _

Power windows

Switches in the driver door
Key to ⇒fig. 30:
(1) For the windows in the front doors.
(2) For the windows in the rear doors.
(3) Safety switch.
Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch.
Stopping automatic
movement:
Press/pull the respective switch again.
_¦ The safety switch (3) deactivates the power windows
in the rear doors. The yellow indicator light in the
switch comes on.

You can still use the power windows for several minutes after the ignition is switched off as long as
the driver or front passenger door has not been opened. When the vehicle key has been removed
from the ignition and the driver door has been opened, the power windows cannot be opened or
closed.
A separate button for controlling the window is located in the front passenger door.
Power windows – features

x Close all windows and doors.
x Pull up the switch for the respective window and hold it for at least 2 seconds in this position.
x Release the switch, pull up and hold again. The one-touch feature is now reactivated.
The one-touch feature can be reactivated for one or more windows at the same time.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power
windows for several minutes after the ignition is switched off as long as the driver or front
passenger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
If the power windows malfunction, the one-touch feature, as well as pinch protection may not
work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right
away.

Windshield made of heat-insulating glass

Fig. 75 Heat-reflective windshield with communications window (blue shaded area).

WARNING
Driving with an open luggage compartment lid can cause poisonous carbon monoxide in the
engine exhaust to get into the passenger compartment.
x Carbon monoxide causes drowsiness, inattentiveness, poisoning, and loss of
consciousness. It can lead to accidents and severe personal injuries.
x Always keep the luggage compartment lid closed while driving to help keep poisonous
exhaust fumes from being drawn into the vehicle.
x Never transport objects that are too large to fit completely into the luggage area, because
then the luggage compartment lid cannot be fully closed.
x If you absolutely must drive with an open luggage compartment lid, do the following to
reduce the risk of carbon monoxide poisoning:
– Close all windows and the power sunroof.
– Switch off the climate control system's air recirculation feature.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.

NOTICE
The open luggage compartment lid changes the vehicle height.
Driving a loaded vehicle

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal
injury during hard braking or sharp steering or in an accident. Loose items can also be
struck and thrown through the passenger compartment by the front airbags if they inflate. To
help reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in
the luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so
that they cannot move into the deployment zone of a side or front airbag during sudden
braking, in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on
the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle
interior and stow them securely in the luggage compartment.

WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and
increases braking distances. Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by
shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle
capacity weight figures apply when the load is distributed evenly in the vehicle (passengers
and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the
rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings,
which are printed on the Safety Compliance Certification Label located on the door jamb of
the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave
differently.
x Always adapt your speed and driving style to accommodate your payload and its weight
distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid
sudden braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.

NOTICE
The defroster heating wires or antenna in the rear window can be damaged by objects that rub
against them.
The ventilation slots between the rear window and the shelf behind the rear seat backrest must
not be blocked so that stale air can escape from the vehicle.
