2013 VOLKSWAGEN GOLF warning light

Menu Function See
MFI Multi-Function Indicator (MFI) information.
Audio
Station indicator in radio mode.
Track display in CD mode.
Track display in media mode.
⇒ Booklet Radio or
⇒ Booklet Navigation
system
Navigation
Information displays on the navigation system (if applica-
ble):
When destination guidance is active, turn arrows and
proximity bars are shown. The illustration is similar to the
symbol display in the navigation system.
If destination guidance is inactive, driving direction (com-
pass function) and the current street name are displayed.
⇒ Booklet Navigation
system
Phone Information and settings of the mobile phone package. ⇒ Booklet Mobile
Phone Package
Assistants Turn the Adaptive Front Lighting System (AFS) on and off
(if applicable).
Vehicle
status
Current warning and information messages.
This menu item is only displayed when warning or infor-
mation messages are available. The number of available
messages is shown in the display. Example: 1/1 or 2/2.

Settings
Includes the Convenience and Lights & Vision submenus,
as well as many settings, such as time, speed warning for
winter tires, language, and units.


MFI menu (Multi-Function Indicator)

Closing the rear hatch
More information:
x Exterior views
x Power locking system
x Transporting
x Emergency closing and opening
WARNING
Accidents and severe personal injuries can result if you unlock, open, or close the rear hatch
when someone is in the way.
x Only open or close the rear hatch if no one is in the way.
x Never close the rear hatch by pushing on the rear window with your hand. The rear
window could break and cause injuries.
x After closing the rear hatch, always make sure that it is properly closed and locked so that
it cannot open suddenly when the vehicle is moving. The closed rear hatch must be flush
with the surrounding auto body parts.
x Always keep the rear hatch closed while driving to help keep poisonous exhaust gas from
being drawn into the vehicle.
x Never open the rear hatch when a luggage rack is installed and loaded. If, for example,
there are bicycles on a carrier on the rear hatch, it is possible that the rear hatch will be
difficult to open. An open rear hatch may fall on its own because of the additional weight. If
necessary, prop open the rear hatch. Remove the weight from the luggage rack first.
x Close and lock the rear hatch and all doors when the vehicle is not in use. First, make sure
that no one is left inside the vehicle.
x Never leave your vehicle unattended or let children play around your vehicle, especially
when the rear hatch is open. A child could crawl into the vehicle and pull the rear hatch shut,
becoming trapped and unable to get out. A closed vehicle can become very hot or very cold,
depending on the season. Particularly in the summer, heat build-up in the passenger and
luggage compartment of a parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures. Temperatures can quickly reach levels that can
cause unconsciousness and death, particularly to small children.
x Never leave children or anyone who cannot help themselves behind in the vehicle. They
may lock the vehicle with the vehicle key or the power locking button and lock themselves in.
NOTICE
Before opening or closing the rear hatch, make sure there is enough room to do so, as for
example when the vehicle has a trailer or is in a garage.
Warning light

Lights up Possible cause Proper response
OR
icon
appears in
the display

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
If the rear hatch is not closed properly, the red ² warning light comes on in the instrument cluster or
the vehicle icon appears in the instrument cluster display showing an open rear hatch.
Depending on your vehicle's equipment and options, the red warning light or icon may still be
displayed even after the ignition is switched off as long as the key has not been taken out of the
ignition. The icon in the instrument cluster display goes out about 15 seconds after the vehicle has
been locked.
WARNING
If the rear hatch is not closed properly, it may open suddenly when the vehicle is moving and
cause severe injuries.
x Stop immediately and close the rear hatch.
x Always make sure the rear hatch is securely latched after you close it.
Opening the rear hatch

Fig. 30 In the remote control vehicle key: button to unlock and open the rear hatch.

WARNING
Always adjust seat, safety belts, and head restraints properly before driving and make sure
that all passengers are properly restrained.
x Push the passenger seat as far back as possible. Always be sure that there are at least
10 inches (25 cm) between the front passenger's breastbone and the instrument panel.
x Always adjust the driver's seat and the steering wheel so that there are at least 10 inches
(25 cm) between your breastbone and the steering wheel.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor
while keeping your knee(s) slightly bent. The distance to the instrument panel in the knee
area must be at least 4 inches (10 cm).
x If these requirements cannot be met for physical reasons, contact an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility to see whether adaptive
equipment is available.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the
driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places
inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the
wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag
inflates.
x Pointing the steering wheel toward your face decreases the ability of the driver's airbag to
help protect you in a collision.
x Never drive with backrests reclined or tilted back farther than necessary to drive
comfortably. The farther back the backrests are tilted, the greater the risk of injury caused by
incorrect positioning of the safety belts and improper seating position.
x Never drive with the front seat passenger backrest tilted forward. If the front airbag
deploys, the front backrest can be forced backward and injure passengers on the rear seat.
x Sit as far back as possible from the steering wheel and the instrument panel.
x Always sit upright with your back against the backrest with the front seats properly
adjusted. Never lean against or place any part of your body too close to the area where the
airbags are located.
x Rear seat passengers who are not properly seated and restrained are more likely to be
seriously injured in a crash.
WARNING
Improper adjustment of the seats can cause accidents and severe injuries.
x Never adjust the seats while the vehicle is moving. Your seat may move unexpectedly and
you could lose control of the vehicle. In addition, you will not be in the correct seating
position while adjusting the seats.
x Adjust the front seat height, angle and longitudinal direction only if the seat adjustment
area is clear.
x The adjustment of the front seats must not be restricted by things in the footwell in front
or behind the seats.
Examples of improper seating positions

Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒  in Adjusting the front and rear head restraints. Recline the backrest with the head
restraint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 41 (1) to unlock the head restraint.
x Push the flat object (plastic card) in against the guide rod to depress a release button located
under the cap (not visible).
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same
guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The
right-hand guide rod is now released.
x To release the left-hand guide rod, press button (2) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (2).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Move the seat backrest into an upright position using the adjusting wheel.
x Adjust the head restraint according to the occupant's size
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 42 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are
properly protected.

x If the outside temperature or the temperature inside the passenger compartment is 77 °F (25 °C) or
more.

Function Action for seat heating ⇒fig.46
Switch on: Press the Aor ebutton. Seat heating is
switched on to maximum.
Adjust the heating level: Press the A or ebutton repeatedly until the
desired heating level is set.
Switch off: Press the A or ebutton repeatedly until all
indicator lights in the button are off.

Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the
ignition was switched off. However, this feature only works if the key is not taken out of the ignition
switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from
medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature
⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.

WARNING
Damage to safety belts reduces their overall effectiveness and increases the risk of serious
personal injury and death whenever the vehicle is being used.
x Never let safety belts become damaged by being caught in the door or seat hardware.
x Torn or frayed safety belts can tear, and damaged safety belt hardware can break in an
accident.
x Inspect belts regularly for damage. If webbing, bindings, buckles, or retractors are
damaged, have the belts replaced immediately with the correct replacement belts approved
by Volkswagen for your vehicle, model, and model year.
x Safety belts that were subject to stress in an accident and stretched must be replaced with
a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility.
x Replacement after a crash may be necessary even if a safety belt shows no visible
damage. Anchorages that have been loaded must also be inspected.
x Damaged safety belts must be replaced; they cannot be repaired.
x Never try to repair a damaged safety belt yourself. Never remove or modify the safety belts
in any way.
x Have safety belts, bindings, retractors and buckles replaced by an authorized Volkswagen
dealer or authorized Volkswagen Service Facility.
x Always keep the belts clean. Dirty belts may not work correctly and can impair the
function of the inertia reel.
Applicable only in the United States
Warning light

Fig. 47 Warning light in the instrument cluster.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
A warning chime also sounds.
The safety belt warning light ª comes on for 6 seconds when the ignition is switched on. A warning
chime also sounds for up to 6 seconds if the driver's safety belt is not buckled. The chime stops
sooner if the driver buckles his or her safety belt. The warning light and the chime go out when both
driver and front passenger have bucked their safety belts.
If the driver and front seat passenger do not both fasten their safety belts within about 24 seconds
after the chime stops and the vehicle is moving at a speed of more than about 15 mph (25 km/h), the
chime will again sound for about 6 seconds, then go off for about 24 seconds, then sound again for
about another 6 seconds. The same thing happens if one of the safety belts is fastened and then
unfastened while the vehicle is moving. The safety belt warning light ª also flashes. The warning
chime continues to sound at 24 second intervals for up to 2 minutes. No chime sounds at speeds of
less than about 5 mph (8 km/h).
If the ignition is switched on, the safety belt warning light ª stays on until the driver and front
passenger have both buckled their safety belts.
WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of
severe personal injury or death. Safety belts offer optimum protection only when used
correctly.
Applicable only in Canada
Warning light

Fig. 48 Warning light in the instrument cluster.
