2013 VOLKSWAGEN GOLF service

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static
cornering lights. On some models the static cornering lights may be integrated in the headlights. At
speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically
when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the O position or when the fog lights themselves have been
switched on 100.
Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistants menu in the instrument cluster display
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the O position or when the fog lights themselves have been
switched on
Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistants menu in the instrument cluster display
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Instrument panel lighting and headlight range adjustment

Fig. 87 To the left of the steering wheel: Thumbwheel to adjust instrument panel lighting 1.

Instrument cluster brightness
When the lights are on, the brightness of the instrument cluster lighting is adjusted by turning the
thumbwheel (1).
In some vehicles with daytime running lights (DRL), the instrument cluster lighting switches on
automatically when it is dark outside or when driving through tunnels, for example. You will need to
switch the headlights on manually when this happens, so that the vehicle's taillights will turn on
Dynamic headlight range adjustment
In vehicles with HID (Xenon) headlights, the headlight range is automatically adjusted to the vehicle
loading condition once the low beams are switched on ⇒ .
WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and
distract other drivers. This can lead to a crash and serious personal injuries.
x Always make sure the headlights are adjusted to loading conditions so that they do not
blind others.
WARNING
If dynamic headlight range adjustment does not work properly or at all, the headlights could
blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Have headlight range adjustment checked immediately by an authorized Volkswagen
dealer or an authorized Volkswagen Service Facility.
Interior and reading lights

Move the lever to the desired position ⇒:
(B) zº
Intermittent wiping for the windshield.
Adjust the interval settings with switch ⇒ fig. 90 (1).
(C) LOW Slow wiper speed.
(D) HIGH Fast wiper speed.
(E) 1x One-tap wiping – brief wiping. Hold the lever pressed down longer to wipe more
often.
(F) W Pull the lever toward the steering wheel to activate the front windshield washers, then
release.
(G) Z Intermittent wiping for the rear window. The wiper wipes about every 6 seconds.
(H) \ Press the lever forward as far as it will go to activate the rear window washers, then
release.

NOTICE
To help prevent damage to the wiper blades and the wiper motor when it is cold outside,
always make sure that blades are not frozen to the windshield before operating the wipers.
Using the service position can be helpful in cold weather so the wipers do not freeze to the
windshield
x If the ignition is switched off while the wipers are running, the wipers will continue at the
same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other
objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen
recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can
be scratched.
On some vehicles, the windshield wipers work only if the ignition is switched on and the engine
hood is closed. The windshield wipers turn off automatically when the engine hood is opened. The
rear window wiper turns off when the rear hatch is opened.
The intermittent wiping for the front windshield depends on the driving speed. The higher the
speed, the faster the wipers move.
If the front wipers are on, the rear wiper is switched on automatically when backing up.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends
using a deicing spray.

Windshield wiper service position

Fig. 92 Windshield wiper in service position.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment. Hooks on these straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from hooks when attaching them to the tie-
downs in the luggage compartment.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the
luggage compartment and then to the tie-downs near the loading edge of the luggage
compartment. This way, if one of the hooks on the elastic straps snaps back, it will move
away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 380 lbs. (172 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer
or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. 102 In the luggage compartment: Shopping bag hooks.

Maximum power consumption for the trailer
Do not exceed the power ratings listed in the chart below.

Electrical load Maximum power
Brake lights total 108 watts
Turn signals per side 54 watts
Side marker lights total 100 watts
Taillights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the
tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all
bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.
NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the
regular maintenance and inspection intervals because of the extra load it has to pull.
Hitching up and connecting a trailer

WARNING
Improper connections to the vehicle electrical system can cause malfunctions that affect the
entire vehicle electrical system, which can lead to accidents and serious personal injury.
x Have any work on the electrical system done by an authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
NOTICE
Never attach a trailer to the vehicle or leave it attached to the vehicle when the trailer is
supported by a trailer jack or blocks. Various things (such as a change in trailer or vehicle load
or a flat tire) can lower or raise the vehicle. This subjects the trailer hitch and the trailer to
strong forces that can damage the vehicle or the trailer.
If the engine is switched off and accessories in the trailer are on and use electricity from the
vehicle, the vehicle battery will be drained as long as the electrical systems of the vehicle and the
trailer are connected.
Loading the trailer
