NOTICE
Always insert and remove lamps carefully to help prevent damage to the vehicle paint or to
other parts of the vehicle.
Changing headlight bulbs
Fig. 193 In the engine compartment: Covers in the left headlight assembly. 1 Low beam, 2 Turn signal
indicator, 3 High beam and parking light as well as daytime running light.
Please carry out each step only in the order specified:
⇒ fig. 193 (1) (2) (3) (3)
Low beam
headlights
Front turn signals High beam
headlights /
daytime running
lights
Parking lights (small
bulb holder)
7. Insert the bulb holder in the headlight and turn it
clockwise all the way.
Insert the bulb holder in
the headlight and slide it
all the way in.
8. Install the rubber or plastic cover.
Press the clip down, if necessary.
The illustrations show the left headlight assembly from the rear. The right headlight assembly is
the mirror image of the left headlight assembly.
Different models may have different lights, and the location and design of covers, bulb holders,
and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized
Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Changing taillight bulbs in the rear hatch
Fig. 196 In the rear hatch: Removing cover.
