¥ Properly fasten your safety belt before driving the vehicle and wear your safety belt properly at all
times while driving. Make sure that all passengers do the same
¥ Only transport as many passengers as there are seats and safety belts available.
¥ Never drive if your driving ability has been impaired, for example by medication, alcohol or illegal
drugs.
¥ Never let passengers or phone calls distract you while driving, and never take your attention off the
road while using vehicle software or adjusting vehicle equipment or accessories.
¥ Always adapt your speed and driving style to visibility, weather, road, and traffic conditions.
¥ Always obey traffic laws and speed limits.
¥ On long trips make frequent rest stops – at least once every 2 hours.
¥ Secure animals in the vehicle with a system that corresponds to weight and size.
WARNING
Always observe traffic rules and posted speed limits and use common sense. Your good
judgment can mean the difference between arriving safely at your destination and being se-
riously injured in a crash or other kind of accident.
Regular service and maintenance of your vehicle is important both for operational and driving
safety and to help prolong your vehicle's service life. Always follow the scheduled maintenance inter-
vals in the ⇒ Booklet Warranty and Maintenance, especially for changing the brake fluid. Hard use,
frequent stop-and-go driving, driving in very dusty areas, trailer towing, and other factors may make it
necessary to have the vehicle serviced more frequently. Ask an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility for more information.
Driving in other countries

Display text Proper response
Error:
Open convertible top!
Open the CSC roof
Error:
Close convertible top!
Close the CSC roof
Low voltage:
Please start engine!
The vehicle battery is drained to the point that it cannot provide
the power needed to completely open or close the CSC roof.
Start the engine, by jump-starting if necessary . Open or close
the CSC roof while the engine is running. Volkswagen
recommends taking a longer drive afterwards to recharge the
vehicle battery.
Temperature too high
Sliding roof! or
Temperature too high
Convertible top!
Wait for a short time until the hydraulic and electrical unit cool
down; they may have overheated. Opening and closing the
CSC roof with great frequency may cause the hydraulic and
electrical unit to overheat. Overload protection disables the roof
until the unit cools down.
Convertible top open The message and an acoustic signal confirm that the CSC roof
is completely open or closed. Convertible top closed
Convertible top not
functional.
Owners Manual!
Check the outside temperature shown in the instrument cluster
display. At temperatures below +5 °F (-15 °C) you can close
the CSC roof, but not open it.
Have the system checked by an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility. There is a
malfunction in an ECU. It is not possible to open or close the
roof. Use emergency procedure to close an open CSC roof if
necessary

The instrument cluster displays and their arrangement may vary depending on the vehicle model
and engine. For displays without warning and information messages, malfunctions are only signaled
with indicator lights.
General information

Fig. 31 The CSC roof folds down into the luggage compartment when you open the roof (put the roof down).

WARNING
Accidents and severe injuries can result if the CSC roof is opened or closed when someone
is in the way.
x Never open or close the CSC roof unless the vehicle is parked at a safe distance from
traffic.
x Do not open or close the CSC roof unless you have made sure that nobody is in the way
of the luggage compartment lid, the roof system, or other moving parts.
x Check to make sure that the closed CSC roof is securely latched.
x If CSC roof operation is interrupted, please note the following:
– The CSC roof may not stop moving immediately. Gravity may cause the CSC roof to
keep moving.
– Gradually (may take up to 8 minutes), the CSC roof will automatically lower itself into a
balanced position.
– The CSC roof is, however not latched in this position. Stop!
WARNING
If interruption of opening or closing process causes the roof to come to rest in its forward
position, the roof will not be latched.
x If you are unable to get the CSC roof to close “normally,” latch the roof using the
emergency closing procedure
x Watch for a message in the instrument cluster display indicating whether the roof has
been properly closed.
NOTICE
Frequent opening and closing of the CSC roof drains the vehicle battery. To help prevent the
battery from running down, you should keep the engine running if you need to open and close
the roof frequently.
NOTICE
If the CSC roof is open, rain could enter the vehicle and wet the interior, causing vehicle
damage.
x Always close the CSC roof and lock the doors and the luggage compartment before leaving
the vehicle.
NOTICE
The height of the vehicle changes when the CSC roof is moving. When there is not enough
room above the vehicle, for example in a garage, the CSC roof could hit something and be
damaged.
x Always make sure that there is enough room above the vehicle when opening or closing the
CSC roof.
If you park vehicle with the roof down, the passenger compartment can be damaged by rain or
snow, and it is also open to unauthorized persons. Volkswagen recommends closing the CSC roof

x Position the wind blocker horizontally against the rear seat backrest.
x Fold out both tabs on the back of the wind blocker and push them into the slots until they latch
⇒ fig. 33 A (inset).
x Pull the handle B in the direction of arrow (1) and then slide the locking bolt in the direction of
arrow (2) into the retainer.
x Press the wind blocker down gently in the center until it clicks into place.
x Repeat this process for the passenger side.
x Raise the top part of the wind blocker until it latches.
Removing the wind blocker
Reverse the above steps to remove the wind blocker.
WARNING
Installing or removing the wind blocker by the side of the road near moving traffic can cause
accidents and serious personal injuries.
x Always park the vehicle a safe distance from moving traffic when installing or removing
the wind blocker.
WARNING
Incorrect seating positions in the vehicle increase the risk of serious of fatal injuries in the
event of an accident or sudden driving and braking maneuvers.
x Never let anyone sit on the rear seats when the wind blocker is installed.
WARNING
Unsecured or improperly secured objects can cause severe injuries during sudden braking
maneuvers or if the vehicle is involved in an accident while driving.
x Never place unsecured objects underneath the wind blocker.
x Never use the wind blocker as a storage shelf. Items on the wind blocker can be thrown
around inside the vehicle by the wind and cause injuries.
x Never use the wind blocker to secure objects.
WARNING
Always make sure that hands, fingers, and other parts of the body are out of the way when
moving the wind blocker up or down, or when folding it together.
x Never fold the wind blocker upward while driving.
NOTICE
x When moving a front seat forward or back, make sure the backrest does not press against
the wind blocker. This can damage the wind blocker, especially its locking mechanism.
x Always put the wind blocker back in its pouch when not in use.
x Never put objects (luggage, grocery bags, etc.) on top of the wind blocker.

WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of
severe personal injury or death. Safety belts offer optimum protection only when they are
used properly.
x Properly worn safety belts are the single most effective means of reducing the risk of
serious injury and death in a collision or other accident. For this reason, always wear your
safety belt properly and make sure all passengers wear their safety belts properly as well
whenever the vehicle is moving.
x The driver must always make sure that every person in the vehicle is properly seated on a
seat of his or her own, properly fastens the safety belts belonging to that seat before the
vehicle starts to move, and keeps the belts properly fastened while riding in the vehicle. This
applies even when just driving around town. Therefore, always wear your safety belts and
make sure that everybody in your vehicle is properly restrained.
x Always secure children in the vehicle with a restraint system appropriate for their age,
weight and height
x Always fasten safety belts correctly before driving off and make sure that all passengers
are properly restrained.
x Never attach the safety belt to the buckle of another seat. Attaching the safety belt to the
wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never let any objects or liquids get into the safety belt latch and prevent it from working
properly.
x Never remove a safety belt while the vehicle is moving. Doing so will increase your risk of
being injured or killed.
x Never strap more than one person, including small children, into any single safety belt.
x Never let children or babies ride sitting on your lap, and never place a safety belt over a
child sitting on your lap.
x Never wear belts over rigid or breakable objects in or on your clothing, such as
eyeglasses, pens, keys, etc., as these may cause injury.
x Several layers of heavy clothing (such as a coat worn over top of a sports jacket) may
interfere with proper positioning of the safety belt and reduce the overall effectiveness of the
system.
x Never use comfort clips or devices that create slack in the shoulder belt. However, special
clips may be required for the correct use of some child restraint systems.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are
correctly positioned on the body.

Fastening safety belts
Always buckle your safety belt before driving.
x Adjust the front seat and head restraint correctly
x Grasp the safety belt by the buckle tongue and pull it out of the belt guide ⇒ fig. 60 (B).
x Unsnap the safety belt loop on the front seat backrest (A) and guide the belt strap through the loop.
Close the snap.
x Hold the safety belt by the tongue and pull it slowly and evenly across the chest and pelvis. Do not
twist the safety belt webbing ⇒ .
x Insert the tongue into the correct buckle for your seat until you hear it latch securely ⇒ fig. 59 A.
x Pull on the safety belt to make sure that it is securely latched in the buckle.
Unfastening safety belts
Unfasten safety belts only when the vehicle is not moving ⇒ .
x Press the red button on the buckle B. The buckle tongue is ejected.
x Let the belt wind up on the retractor as you guide the belt tongue to its stowed position to help
prevent the safety belt from twisting and to help avoid damage to the interior trim.
WARNING
Improperly positioned safety belts can cause serious personal injury or death in an accident.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are
correctly positioned on the body.
x A person who is not properly restrained can be seriously injured by the safety belt itself if
it slips from the stronger parts of the body into sensitive areas like the abdomen.
x Unfastening safety belts while the vehicle is in motion can cause severe personal injury or
death in the event of an accident or braking maneuver!
Before getting in the vehicle, the driver and front passenger should run the safety belt through
the belt loop so that they can reach their belts more easily to attach them.
The safety belt loop helps prevent the safety belt from flapping in the wind when driving with
windows or the CSC roof down.

Using a safety belt extender
x Adjust both the seat and the head restraint properly
x Insert the buckle tongue on the safety belt extender ⇒ fig. 63 (2) into the vehicle belt buckle for the
seat where the safety belt extender is being used (1).
x Fastening or unfastening the vehicle safety belt
x Pull the belt to make sure that the tongues are securely locked in the buckles.
x Make sure that the safety belt is positioned properly , Safety belt position.
Properly using safety belt extenders:
x Use a safety belt extender only when the factory installed safety belt is too short when worn
properly by a person in proper seating position.
x Only use 1 safety belt extender per seat and vehicle safety belt.
x Always remove the safety belt extender when it is not needed.
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is
not needed and being used with the safety belt. Otherwise, the airbag control module will receive an
incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a
person who is not using the safety belt. Leaving the extender attached to the safety belt buckle when
the front seat is occupied and the safety belt is not being used will signal the airbag control unit during
a collision that the front passenger seat is occupied and that the safety belt is being used. The
electronic control unit for the airbag system will then receive incorrect information that will cause the
safety belt pretensioner to deploy unnecessarily and the front passenger airbag to deploy later in
collisions that would normally trigger the front airbag earlier in the collision to help protect an
unrestrained front seat occupant. The airbag will not be able to provide enough protection for an
occupant not wearing a safety belt.
x Only use the safety belt extender approved by Volkswagen for your vehicle.

WARNING
Improper use or positioning of a safety belt extender increases the risk of serious personal
injury and death.
x A driver or passenger who is not properly restrained can be seriously injured by striking
the interior of the passenger compartment or by the safety belt itself, which can be displaced
from stronger parts of the body into sensitive areas like the abdomen.
x Safety belt extenders offer optimum protection only when they are properly used.
x Only use the extender when the belt is not long enough to be worn low and snug and the
person is in the correct seating position. Remove and stow extender safely when not needed.
x Always make sure the safety belt tongue of the safety belt extender is securely inserted
into the buckle for the seating position that belongs to the seat where the safety belt extender
is being used. Attaching the safety belt to the wrong buckle will reduce safety belt
effectiveness and can cause serious personal injury.
x Never use the safety belt extender if you can properly attach the safety belt without it.
Using a safety belt extender when not needed can increase the risk of injury, especially in a
collision.
x Never use a safety belt extender if the distance (B) between the front edge of the safety
belt extender buckle (A) and the centerline of the person using the safety belt extender
⇒ fig. 64 (C) is less than 6 inches (15 cm).
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the
extender is not needed and being used with the safety belt. Otherwise, the airbag control
module will receive an incorrect signal from the safety belt buckle and this will prevent the
airbag from working properly for a person who is not using the safety belt.
x Never use more than 1 extender with a safety belt. Using more than 1 extender can change
the way the safety belt passes over the body and can cause serious injury.
x Never use the safety belt extender to secure a child restraint.
x Never use a safety belt extender on your Volkswagen that you got from another
automobile manufacturer or from an automotive parts store.
x Never use the safety belt extender you got for your vehicle for any other vehicle,
regardless of make, model, or model year.
NOTICE
x Leaving the extender attached to the safety belt buckle when the front seat is occupied and the
safety belt is not being used will signal to the airbag control unit that the front passenger seat is
occupied and that the safety belt is being used. The electronic control unit for the airbag system will
then receive incorrect information that will
– cause the safety belt pretensioner to deploy unnecessarily in collisions.
– cause the front passenger airbag to deploy later in collisions in which the front airbag
would otherwise be triggered earlier to help protect an unrestrained front seat passenger.
x A pretensioner that has deployed cannot be repaired. The entire safety belt must be
replaced.
NOTICE
If the safety belt extender is left attached to the safety belt buckle, the safety belt warning
system will sense that the safety belt for that seat is being used. The warning light will not
come on and the warning chime will not sound even though the seat is occupied and the safety
belt is not being used.
