2013 VOLKSWAGEN EOS window

Buttons,
knobs
More information: Manual AC ⇒ fig. 140
and Climatronic ⇒ fig. 141.
Fan (2) Manual AC: Setting 0: the fan and manual AC are switched off.
Setting 4: highest fan speed.
e Climatronic: The fan speed is automatically controlled depending on the vehicle
speed in order to help prevent unnecessary noise. The fan can also be adjusted
manually.
Air
distribution
(3)
Manual AC: Direct airflow by turning knob to any setting (continuously adjustable).
Climatronic: Air flow is automatically adjusted to a comfortable level. It can also be
manually adjusted with buttons (3).
Displays (4) Climatronic: Left-side and right-side digital temperature displays.
< Manual AC: Defrost button. Airflow is directed to the windshield. Recirculation mode
switches off automatically in this position. Increases the fan speed to clear the
windshield as quickly as possible. The cooling system switches on automatically to
dehumidify the air.


Climatronic: Defrost button. The incoming outside air is directed to the windshield,
and air recirculation automatically switches off. To defrost the windshield as quickly as
possible, humidity is removed from the air at temperatures above about 35 °F
(+1.5 °C), and the blower is set to a high speed.
K Air distribution to the air vents in the instrument panel.
L Air distribution to the footwells.
u· Manual AC: Air distribution to the windshield and footwells.
Climatronic: Air is directed upward.
Rear window defroster: Works only when the engine is running and switches off
automatically after 10 minutes or less.
3 Manual AC: Air recirculation
Û

Cleaning wheel rims
Care of rubber door and window seals
Deicing door lock cylinders
Undercoating
Cleaning the engine compartment
Regular and expert care helps to preserve the value of your vehicle. Such expert care may also be
one of the requirements of your New Vehicle Limited Warranty if corrosion repair or repainting is
necessary.
Vehicle care products are available from your authorized Volkswagen dealer or authorized
Volkswagen Service Facility.
More information:
x CSC roof
x Preparations for working in the engine compartment
x Interior care and cleaning
x Parts, accessories, repairs and modifications
WARNING
Vehicle care products can be dangerous. Improper use can cause accidents, burns,
poisoning, or other serious personal injuries.
x Always store vehicle care products only in original containers that are securely closed.
x Always read and heed all the instructions and all WARNINGS on the package.
x To reduce the risk of poisoning, never use empty food or beverage containers that might
mislead someone into drinking from them.
x Always keep vehicle care products out of the reach of children.
x Always use such products outdoors or in well-ventilated areas, because harmful vapors
may be released when these products are used.
x Never use fuel, turpentine, engine oil, nail polish remover or other volatile fluids for
vehicle care. They are poisonous and highly flammable.
WARNING
Improper care and cleaning of vehicle components can impact the safety features of the
vehicle and cause severe injuries.
x Always clean and maintain vehicle components according to manufacturer's instructions.
x Only use approved or recommended cleaners.
NOTICE
Vehicle care products containing solvents can damage plastics and other vehicle the materials.
Wash the vehicle only at specifically designated wash locations to help prevent water
contaminated with oil, grease and fuel from entering the storm drain sewer system. In some areas it is
against the law to wash motor vehicles anywhere than other than at specified designated car washing
locations.

WARNING
After the vehicle has been washed, the wet brakes or, in winter, brake discs or pads coated
with ice, react slower and need longer stopping distances.
x Always dry the brakes and clean off any ice coatings with a few careful applications of the
brake. Make sure not to endanger other motorists or cyclists or disobey legal requirements.
NOTICE
Never wash the CSC roof with a power washer or use “brushless” automatic car washes. Water
that is sprayed under high pressure may cause leaks or may damage the rubber seals of the
CSC roof.
x Do not use any rubber care materials that contain silicone or any cleaners that contain
acids such as industrial dust remover or insect remover on the CSC roof seals.
NOTICE
x Water temperature should not be more than +140 °F (+60 °C).
x To help prevent damage to the paint, do not wash the vehicle in direct sunlight.
x In order for Park Distance Control to work correctly, the sensors in the rear bumper must be
kept clean and clear of snow and ice.
x When using a power washer or steam cleaner, only spray the sensors directly for a short
period of time and always keep the nozzle at least 4 inches (10 cm) from the sensor.
x Do not clean icy or snow-covered windows with a power washer.
x When washing or rinsing the vehicle in cold weather, do not let water get into the lock
cylinders or point the hose at gaps around the doors, hood, or luggage compartment lid. The
water could freeze on the locks and seals and make it difficult to open the vehicle!
Cleaning the wind deflector

Fig. 156 Wind deflector in the windshield frame.

WARNING
Before using the emergency procedure to close the CSC roof, park the vehicle as far away
from moving traffic as possible. If necessary, switch on the emergency flashers and set up a
warning triangle. Obey all applicable legal requirements.
NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not
lowered when the door is opened or closed. Always close and open the door carefully to help
prevent damage to the window, the paint, or the rubber seal.
NOTICE
x Before using the emergency procedure to close the CSC roof and while doing it, check the
area behind the vehicle for possible obstacles and make sure there is enough room to avoid
damage. Rear lid assist does not work before and during the emergency closing procedure.
x Never close the CSC roof if the car is on a workshop hoist, parked with one side on a curb,
or raised on a car jack or jackstands.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency
locking or unlocking.
Manually unlocking and locking the driver door

Fig. 166 Door handle on driver door: Concealed lock cylinder.

x Within 2 seconds, pull the switch again and hold it until the sunroof closes completely. The sunroof
will close with extra force. Pinch protection will be disabled while the sunroof is closing!
In some cases, the emergency closing procedure for the CSC roof can be used to close the
power sunroof
Emergency closing of the CSC roof

Fig. 174 CSC roof switch in the center console.

Fig. 175 Driver's door control to open and close all windows.

Possible situations for emergency closing
Provided the preliminary requirements have been met, the CSC roof can be closed using the
emergency procedure if you have one or more of the following problems:
x The windows in the doors will not go down.
x The soft-close feature of the luggage compartment lid is not working.
x Sensors that determine the position of the CSC roof when it is opening and closing are not
working.
Emergency CSC roof closing
x Check whether there is enough room behind the vehicle for the luggage compartment lid to swing
out backwards.
x Open the driver and passenger door and leave the doors open.
x Press your thumb on the top part of the Volkswagen emblem on the luggage compartment lid, and
flip lower part of the emblem outward. This unlocks the rear lid. But do not lift the luggage
compartment lid.
x Switch the ignition off and back on again.
x Start the engine.
x Pull and hold the center console lever ⇒ fig. 174 for at least 30 seconds.
x Release the lever.
x Pull and hold the lever again and immediately pull back and hold the driver door switch ⇒ fig. 175
(1) until the CSC roof has completely closed and locked.
It takes a few seconds for the closing process to start after you pull both controls. A tone sounds and
the indicator light X in the instrument cluster display lights up during the emergency closing process.
There may also be a message in the instrument cluster display.
The closing process is immediately interrupted if you let go of the lever or the switch or if one of the
cancel conditions changes ( 324, Cancel conditions for emergency closing). The process can be
restarted by again pulling the center console lever and the switch in the driver door.
x After emergency roof closing is complete, continue to hold the lever and switch to close all
windows.
x OR: After emergency closing, pull switch (1).
x OR: Insert the key in the lock of the driver's door, turn in the closing direction, and hold until all
windows are closed.
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.
Cancel conditions for emergency closing
Emergency closing the CSC roof is canceled if any of the following situations occurs:
x The lever in the center console or the switch in the driver door is released.
x The ignition is switched off.
x Any door is shut.
x The vehicle battery voltage is less than 9 Volts.
x The luggage compartment lid is closed before the roof frames are locked into the mountings on the
windshield.
x The vehicle moves at a speed greater than about 0.6 mph (1 km/h).
x The outside temperature is below +5° F (- 15° C).
Emergency closing using the lever-switch combination is possible only if the CSC control unit has
detected a malfunction that is caused by one of the listed feasible problems 324, Possible situations
for emergency closing.

Before removing the jumper cables
x Switch off the headlights (if they are on).
x In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected.
Removing jumper cables
With the engine running, remove the jumper cables in reverse order to the way they were connected.
1. Disconnect the black (-) cable from the vehicle with the dead battery.
2. Disconnect the black (-) cable from the other vehicle (vehicle with the good battery).
3. Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
4. Disconnect the red (+) cable from the vehicle with the dead battery.
5. Close the battery cover.
6. If necessary, unscrew the towing eye on the front of the vehicle
WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety precautions before working on the batteries or the electrical system , Vehicle battery.
x Always wear proper eye protection. Never lean over the vehicle battery.
x Attach the jumper cables in the correct order: first the positive cable, then the negative cable.
x Never connect the negative cable from the vehicle providing starting assistance to parts of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Check the battery acid level indicator window on the vehicle battery. Use a flashlight, never a match, cigarette lighter, or other open flame. If you cannot see the color of the window clearly, or if it is light yellow or colorless, do not jump-start the vehicle. Get expert assistance.
x Avoid electrostatic discharge in the vicinity of the vehicle battery. Sparks may cause the hydrogen gas escaping from the vehicle battery to ignite.
x Never jump-start a vehicle with a battery that is damaged or frozen or that was frozen and has thawed. The battery can explode. Replace the battery instead.
x Always follow the instructions of the jumper cable manufacturer.
x Always make sure that the battery providing starting assistance has the same voltage as the dead battery (12 V) and about the same capacity (see battery label).
x Batteries give off explosive hydrogen gas. Always keep fire, sparks, open flame and smoking materials away from batteries.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery. The hydrogen gas from the battery is explosive.
x Never short out the battery terminals by connecting the positive (+) and negative (-) terminals with each other.
